Products Under 3999
-
MODEL-XEN-G1191 -MAKE SCHNEIDER MAKE PENDENT SWITCH
Main Range of product Harmony XAC Product or component type Contact block Component name XENG Electrical circuit type Control circuit Contact block application 2-speed Contact block type Single Type of operator Spring return Product compatibility XACAXACA9...head Contacts type and composition 1 NC + 2 NO Mounting of block Front mounting Contact operation Slow-breakStaggered Complementary Connections - terminals Screw clamp terminals, 1 x 0.5...1 x 2.5 mm² without cable endScrew clamp terminals, 1 x 0.5...2 x 1.5 mm² with cable end Mechanical durability 1000000 cycles Contact code designation A600 AC-15, Ue = 240 V, Ie = 3 A conforming to IEC 60947-5-1 appendix AA600 AC-15, Ue = 600 V, Ie = 1.2 A conforming to IEC 60947-5-1 appendix AQ600 DC-13, Ue = 250 V, Ie = 0.27 A conforming to IEC 60947-5-1 appendix AQ600 DC-13, Ue = 600 V, Ie = 0.1 A conforming to IEC 60947-5-1 appendix A [Ithe] conventional enclosed thermal current 10 A [Ui] rated insulation voltage 600 V (pollution degree 3) conforming to IEC 60947-1 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-1 Maximum resistance across terminals 25 MOhm Operating force 18 N Short-circuit protection 10 A fuse protection by cartridge fuse type gG Rated operational power in W 40 W DC-13 for 1000000 cycles, operating rate <60 cyc/mn at 120 V, load factor = 0.5 (inductive load) conforming to IEC 60947-5-1 appendix C48 W DC-13 for 1000000 cycles, operating rate <60 cyc/mn at 48 V, load factor = 0.5 (inductive load) conforming to IEC 60947-5-1 appendix C65 W DC-13 for 1000000 cycles, operating rate <60 cyc/mn at 24 V, load factor = 0.5 (inductive load) conforming to IEC 60947-5-1 appendix C Terminals description ISO n°1 (21-22)NC(33-34)NO_CL(13-14)NO Net weight 0.04 kg Main Range of product Harmony XAC Product or component type Contact block Component name XENG Electrical circuit type Control circuit Contact block application 2-speed Contact block type Single Type of operator Spring return Product compatibility XACAXACA9...head Contacts type and composition 1 NC + 2 NO Mounting of block Front mounting Contact operation Slow-breakStaggered Complementary Connections - terminals Screw clamp terminals, 1 x 0.5...1 x 2.5 mm² without cable endScrew clamp terminals, 1 x 0.5...2 x 1.5 mm² with cable end Mechanical durability 1000000 cycles Contact code designation A600 AC-15, Ue = 240 V, Ie = 3 A conforming to IEC 60947-5-1 appendix AA600 AC-15, Ue = 600 V, Ie = 1.2 A conforming to IEC 60947-5-1 appendix AQ600 DC-13, Ue = 250 V, Ie = 0.27 A conforming to IEC 60947-5-1 appendix AQ600 DC-13, Ue = 600 V, Ie = 0.1 A conforming to IEC 60947-5-1 appendix A [Ithe] conventional enclosed thermal current 10 A [Ui] rated insulation voltage 600 V (pollution degree 3) conforming to IEC 60947-1 [Uimp] rated impulse withstand voltage 6 kV conforming to IEC 60947-1 Maximum resistance across terminals 25 MOhm Operating force 18 N Short-circuit protection 10 A fuse protection by cartridge fuse type gG Rated operational power in W 40 W DC-13 for 1000000 cycles, operating rate <60 cyc/mn at 120 V, load factor = 0.5 (inductive load) conforming to IEC 60947-5-1 appendix C48 W DC-13 for 1000000 cycles, operating rate <60 cyc/mn at 48 V, load factor = 0.5 (inductive load) conforming to IEC 60947-5-1 appendix C65 W DC-13 for 1000000 cycles, operating rate <60 cyc/mn at 24 V, load factor = 0.5 (inductive load) conforming to IEC 60947-5-1 appendix C Terminals description ISO n°1 (21-22)NC(33-34)NO_CL(13-14)NO Net weight 0.04 kg Environment Standards UL 508IEC 60947-5-1CSA C22.2 No 14 Ambient air temperature for operation -25…70 °C Ambient air temperature for storage -40…70 °C Vibration resistance 15 gn (f= 10…500 Hz) conforming to IEC 60068-2-6 Shock resistance 100 gn conforming to IEC 60068-2-27 Overvoltage category Class II conforming to IEC 61140 Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 3.0 cm Package 1 Width 4.0 cm Package 1 Length 5.5 cm Package 1 Weight 42.0 g Unit Type of Package 2 S02 Number of Units in Package 2 100 Package 2 Height 15.0 cm Package 2 Width 30.0 cm Package 2 Length 40.0 cm Package 2 Weight 4.55 kg Unit Type of Package 3 P06 Number of Units in Package 3 1600 Package 3 Height 77.0 cm Package 3 Width 80.0 cm Package 3 Length 60.0 cm Package 3 Weight 81.3 kg Contractual warranty Warranty (in months) 18
Rs. 1,553.50
-
MODEL-DC VOLT METER 0-50V YOKINS DC DIGI
Dimension 70x41mm Warranty No Warranty Type LED Shape Rectangle I Deal In New Only Display Digit 3 Availability In Stock DD7041 series digital Voltmeter is an intelligent meter used to measure DC Voltage. It is cost-effective, miniature, flexible, and is useful for machines and other devices for measuring DC voltage, and so on. Voltages: 0-50V DC Auxiliary Power: 9V AC/DC+/-10%, <2VA Resolution to 0.1V; Accuracies to +/-1%,+/-2LSB Reliable, long life, Mcu measuring Sample Speed: about 10 times/sec. LED Size/ Color: 3 digit, 0.56',Red Maximum Display: 50.0 Over Range: Display 'H' Dimension: 70*41mm Mounting Size : 68*38mm
Rs. 991.20
-
Model-Cooling Fan SPM Control MMF-12C24DH-F02
Condition New – Open box: An item in excellent, new condition with no functional defects. The item may be ... Read moreabout the condition Model Mitsubishi MMF-12C24DH-FO2 MPN Does Not Apply Brand Mitsubishi MMF-12C24DH-FO2 UPC Does not apply
Rs. 3,186.00
-
MODEL-MC-22B-MAKE LS METASOL KONTAKTOR 22A 220V AC
Item specifics Condition Used Seller Notes “USED BUT NEW WORKING CONDITION” Country of Origin Korea, Republic of Mounting Style Panel Mount Maximum Amperage 22A Number of Phases 3 Current Rating 22A MPN MC-22B Brand LS Type Definite Purpose Contactor Current Type AC Coil Voltage 208/240 V Number of Poles 3-Pole IEC Utilization Category AC-3
Rs. 1,829.00
-
MODEL-MC-9B-AC240 CONTACTOR
Description:METASOL CONTACTOR 3P 9A 1A1B AC240V 50/60HZ SCREW 100% insured shipping: A guarantee for your purchases Express delivery: Worldwide delivery by DHL express courier
Rs. 1,003.00
-
Model-GIC 110-240 VAC/DC Dual ACTING PID Temperature Controller 2 Relay 1 Analog Output With RS485
Flush Mounting Version 96×96 mm with Dual Line Digital Seven Segment Display Universal Input Configurable Output combination Configurable: Band, Deviation, Sensor break & Loop break alarms Single/Dual acting PID controllers with 5 Control modes Analog Voltage / Current Inputs (0-5 V, 1-5 V, 0-10 V / 4-20 mA) and Outputs (0-10 V / 4-20 mA) 188 Auto-tuning PID with provision for Soft-Start 6 Segment Ramp & Soak profile with Power Failure resumption modes Rapid Set Point change feature RS 485 Communication Bumpless Auto-Manual transfer IP 20 (for Terminals & Enclosure) IP 54 (for Front Panel only)
Rs. 3,186.00
-
Model-Rotary Shaft Seal 60*75*9
Description TC oil seal 60x75x9 mm made from NBR with a spring-loaded double lip for tight sealing. Built to block oil, grease, and dirt in rotating shafts for smooth, long-lasting performance. Type: TC (rubber covered, double lip, garter spring) ✔️ Inside Diameter: 60mm ✔️ Outside Diameter: 75mm ✔️ Width: 9mm ✔️ Material: NBR (Nitrile Butadiene Rubber) ✔️ Temp Range: -30°C to +100°C ✔️ Applications: gearboxes, pumps, small mo to rs, au to motive machinery and pressure
Rs. 271.40
-
Model-Metallic Dust Seal 40*80*10-Make Maxx
Material Synthetic Rubber Nominal Inside Diameter 40 Millimetres Brand EAI Colour Black Temperature Range 226 Degrees Fahrenheit About this item SUPERIOR QUALITY and DURABILITY: EAI oil seals are engineered with sturdy carbon steel spring and high strength nitrile rubber for reliable and long-lasting performance. This 40mm ID rubber cover seal is lightweight and not easy to age. SEAL OFF LEAKAGE and DIRT: No more getting stressed up by spills from your rotary elements! Crafted with rubber, garter spring, and inner metal case, this metric nitrile oil seal effectively prevents the leakage of lubricants and prevents the entry of dust and dirt into your precious machine. GREAT FIT: 40mmx80mmx10mm size. The perfect double lip oil seal for automotive, motorcycle crankshafts, differentials, camshafts, axle shafts, machinery, water pumps, valves, front and rear wheels, and vehicle engines. Our oil seal will fit perfectly everywhere you need it. HIGH-TEMPERATURE RESISTANCE: With its 70A Nitrile Butadiene Rubber cover material design, this spring loaded metric rotary shaft will withstand temperatures from -40℉ to 226℉ HYDROCARBON FLUIDS: Engineered for the hydrocarbon fluids sealing environment, this 40x80x10mm TC oil seal boosts a good resistance to grease, mineral oil, hydraulic fluids, and petroleum oil. What more, this seal has low swelling in water, ensuring long term use.
Rs. 290.20
-
Model-PU Seal 25*33*5.70-Make Maxx
25 MM ID X 33 MM OD X 5.7 MM THICKNESS PROFILE TYPE-UR COLOUR - GREEN , BLUE AVAILABLE COLOUR AND PROFILE OF SELECTED SIZE ARE PROVIDED PACK OF 1 PCS MATERIAL - POLYURETHANE RUBBER
Rs. 57.80
-
Model-PU Seal 32*40*6-Make Kastas
he K33 rod seal is and single-acting seal with an extra lip designed for and wide range of hydraulic applications. The K33 blade design offers an optimal oil film, while the secondary blade provides additional scraping performance for system safety. Detailed information ? Inner diameter of the seal: 32 ? Outer diameter of the seal: 40 ? Seal height: 6 ? Seal model: K33 ? Seal material: PU Úroveň kvality: výkon
Rs. 171.10
-
Model-GIC 110-240 VAC/DC Dual ACTING PID Temperature Controller 2 Relay 1 Analog Output With RS485
VARIOFACE module, for 8 plug-in miniature relays or miniature solid-state relays, with LED, negative switching, 24 V DC input voltage
Rs. 2,967.00
-
MODEL-E2B-S08KS02-WP-C1 2M
Specifications Size M8 Mounting type Flush Sensing distance 2 mm Output type NPN Operation mode NO Connection method Cable Material housing Stainless steel Cable specifications PVC Cable length 2 m Overall length of sensor 42 mm Thread length 27 mm Degree of protection (IP) IP67
Rs. 641.94
