Products Under 3999
-
HT5B/2 LEUZE
Series 5B Operating principle Diffuse reflection principle with background suppression Black-white error < 15% up to 200 mm Operating range Guaranteed operating range Operating range, white 90% 0.002 ... 0.4 m Operating range, gray 18% 0.005 ... 0.3 m Operating range, black 6% 0.01 ... 0.2 m Operating range limit 0.002 ... 0.4 m (typical operating range) Adjustment range 20 ... 400 mm Beam path Focused Light source LED, Red Wavelength 645 nm Transmitted-signal shape Pulsed LED group Exempt group (in acc. with EN 62471) Type of light spot geometry Round Focus Fixed Focal distance 200 mm Protective circuit Polarity reversal protectionShort circuit protected Supply voltage UB 10 ... 30 V, DC, Incl. residual ripple Residual ripple 0 ... 15 %, From UB Open-circuit current 0 ... 15 mA Number of digital switching outputs 1 Piece(s) Type Digital switching output Switching element Transistor, NPN Switching principle Light switching(dark switching by reversing polarity of UB) Switching frequency 1,000 Hz Response time 0.5 ms Readiness delay 300 ms Number of connections 1 Piece(s) Function Signal OUTVoltage supply Type of connection Cable Cable length 2,000 mm Sheathing material PVC Cable color Black Number of conductors 3 -wire Wire cross section 0.14 mm² Dimension (W x H x L) 11 mm x 32.4 mm x 20 mm Housing material Plastic Plastic housing PC-ABS Lens cover material Plastic / PMMA Net weight 44 g Housing color BlackRed Type of fastening Two M3 threaded sleevesVia optional mounting device Recommended tightening torque for M3 fastening 0.9 N·m Compatibility of materials ECOLAB Type of display LED Number of LEDs 2 Piece(s) Operational controls Multiturn potentiometer Function of the operational control Range adjustment Ambient temperature, operation -40 ... 60 °C Ambient temperature, storage -40 ... 70 °C Degree of protection IP 67 Protection class III Approvals c UL US Standards applied IEC 60947-5-2 Customs tariff number 85365019 ECLASS 5.1.4 27270904 ECLASS 8.0 27270904 ECLASS 9.0 27270904 ECLASS 10.0 27270904 ECLASS 11.0 27270904 ECLASS 12.0 27270903 ECLASS 13.0 27270903 ECLASS 14.0 27270903 ECLASS 15.0 27270903 ECLASS 16.0 27270903 ETIM 5.0 EC002719 ETIM 6.0 EC002719 ETIM 7.0 EC002719 ETIM 8.0 EC002719 ETIM 9.0 EC002719 ETIM 10.0 EC002719
Rs. 0.00
-
IS C12MM/2NO-8N0-M12 LEUZE
Series C12 type. operating range limit Sn 8 mm Operating range Sa 0 ... 6.4 mm MTTF 326 years Protective circuit Inductive protectionPolarity reversal protectionShort circuit protected Supply voltage UB 10 ... 30 V, DC Residual ripple 0 ... 10 %, From UB Open-circuit current 0 ... 15 mA Temperature drift, max. (in % of Sr) 15 %, Over the entire operating temperature range Repeatability, max. (in % of Sr) 5 %, For UB = 20 … 30 V DC, ambient temperature Ta = 23 °C ± 5 °C Switching hysteresis 15 % Number of digital switching outputs 1 Piece(s) Voltage type DC Switching current, max. 200 mA Residual current, max. 0.1 mA Voltage drop ≤ 2 V Switching element Transistor, NPN Switching principle NO (normally open) Switching frequency 800 Hz Readiness delay 100 ms Number of connections 1 Piece(s) Function Signal OUTVoltage supply Type of connection Connector Thread size M12 Type Male Material Metal No. of pins 4 -pin Encoding A-coded Design Cylindrical Dimension (Ø x L) 12 mm x 50 mm Thread size M12 x 1 mm Type of installation Non-embedded/non-flush Housing material Metal Metal housing Copper-nickel alloy Sensing face material Plastic, Polybutylene (PBT) Net weight 0.024 g Housing color Red, RAL 3000Silver Type of fastening Mounting threadVia optional mounting device Standard measuring plate 24 x 24 mm², Fe360 Type of display LED Number of LEDs 1 Piece(s) Ambient temperature, operation -25 ... 70 °C Ambient temperature, storage -25 ... 70 °C Degree of protection IP 67 Protection class II Test procedure for EMC in accordance with standard IEC 61000-4-2IEC 61000-4-3IEC 61000-4-4 Standards applied IEC 60947-5-2 Aluminum 0.4 Stainless steel 0.75 Copper 0.45 Brass 0.35 Fe360 steel 1 Customs tariff number 85365019 ECLASS 5.1.4 27270101 ECLASS 8.0 27270101 ECLASS 9.0 27270101 ECLASS 10.0 27270101 ECLASS 11.0 27270101 ECLASS 12.0 27274001 ECLASS 13.0 27274001 ECLASS 14.0 27274001 ECLASS 15.0 27274001 ECLASS 16.0 27274001 ETIM 5.0 EC002714 ETIM 6.0 EC002714 ETIM 7.0 EC002714 ETIM 8.0 EC002714 ETIM 9.0 EC002714 ETIM 10.0 EC002714
Rs. 1,136.00
-
LE5B/2
Series 5B Operating principle Throughbeam principle Device type Receiver Operating range see transmitter Protective circuit Polarity reversal protectionShort circuit protected Supply voltage UB 10 ... 30 V, DC, Incl. residual ripple Residual ripple 0 ... 15 %, From UB Open-circuit current 0 ... 20 mA Number of digital switching outputs 1 Piece(s) Type Digital switching output Switching element Transistor, NPN Switching principle Light switching(dark switching by reversing polarity of UB) Switching frequency 900 Hz Response time 0.56 ms Readiness delay 300 ms Number of connections 1 Piece(s) Function Signal OUTVoltage supply Type of connection Cable Cable length 2,000 mm Sheathing material PVC Cable color Black Number of conductors 3 -wire Wire cross section 0.14 mm² Dimension (W x H x L) 11 mm x 32.4 mm x 20 mm Housing material Plastic Plastic housing PC-ABS Lens cover material Plastic Net weight 44 g Housing color BlackRed Type of fastening Two M3 threaded sleevesVia optional mounting device Recommended tightening torque for M3 fastening 0.9 N·m Compatibility of materials ECOLAB Type of display LED Number of LEDs 2 Piece(s) Ambient temperature, operation -40 ... 60 °C Ambient temperature, storage -40 ... 70 °C Degree of protection IP 67 Protection class III Approvals c UL US Standards applied IEC 60947-5-2 Customs tariff number 85365019 ECLASS 5.1.4 27270901 ECLASS 8.0 27270901 ECLASS 9.0 27270901 ECLASS 10.0 27270901 ECLASS 11.0 27270901 ECLASS 12.0 27270901 ECLASS 13.0 27270901 ECLASS 14.0 27270901 ECLASS 15.0 27270901 ECLASS 16.0 27270901 ETIM 5.0 EC002716 ETIM 6.0 EC002716 ETIM 7.0 EC002716 ETIM 8.0 EC002716 ETIM 9.0 EC002716 ETIM 10.0 EC002716
Rs. 1,070.00
-
IS C12MM/2NO-8N0-M12
Series C12 type. operating range limit Sn 8 mm Operating range Sa 0 ... 6.4 mm MTTF 326 years Protective circuit Inductive protectionPolarity reversal protectionShort circuit protected Supply voltage UB 10 ... 30 V, DC Residual ripple 0 ... 10 %, From UB Open-circuit current 0 ... 15 mA Temperature drift, max. (in % of Sr) 15 %, Over the entire operating temperature range Repeatability, max. (in % of Sr) 5 %, For UB = 20 … 30 V DC, ambient temperature Ta = 23 °C ± 5 °C Switching hysteresis 15 % Number of digital switching outputs 1 Piece(s) Voltage type DC Switching current, max. 200 mA Residual current, max. 0.1 mA Voltage drop ≤ 2 V Switching element Transistor, NPN Switching principle NO (normally open) Switching frequency 800 Hz Readiness delay 100 ms Number of connections 1 Piece(s) Function Signal OUTVoltage supply Type of connection Connector Thread size M12 Type Male Material Metal No. of pins 4 -pin Encoding A-coded Design Cylindrical Dimension (Ø x L) 12 mm x 50 mm Thread size M12 x 1 mm Type of installation Non-embedded/non-flush Housing material Metal Metal housing Copper-nickel alloy Sensing face material Plastic, Polybutylene (PBT) Net weight 0.024 g Housing color Red, RAL 3000Silver Type of fastening Mounting threadVia optional mounting device Standard measuring plate 24 x 24 mm², Fe360 Type of display LED Number of LEDs 1 Piece(s) Ambient temperature, operation -25 ... 70 °C Ambient temperature, storage -25 ... 70 °C Degree of protection IP 67 Protection class II Test procedure for EMC in accordance with standard IEC 61000-4-2IEC 61000-4-3IEC 61000-4-4 Standards applied IEC 60947-5-2 Aluminum 0.4 Stainless steel 0.75 Copper 0.45 Brass 0.35 Fe360 steel 1 Customs tariff number 85365019 ECLASS 5.1.4 27270101 ECLASS 8.0 27270101 ECLASS 9.0 27270101 ECLASS 10.0 27270101 ECLASS 11.0 27270101 ECLASS 12.0 27274001 ECLASS 13.0 27274001 ECLASS 14.0 27274001 ECLASS 15.0 27274001 ECLASS 16.0 27274001 ETIM 5.0 EC002714 ETIM 6.0 EC002714 ETIM 7.0 EC002714 ETIM 8.0 EC002714 ETIM 9.0 EC002714 ETIM 10.0 EC002714
Rs. 676.00
-
IS C12MM/2NO-4E0 LEUZE
Series C12 type. operating range limit Sn 4 mm Operating range Sa 0 ... 3.2 mm MTTF 326 years Protective circuit Inductive protectionPolarity reversal protectionShort circuit protected Supply voltage UB 10 ... 30 V, DC Residual ripple 0 ... 10 %, From UB Open-circuit current 0 ... 15 mA Temperature drift, max. (in % of Sr) 15 %, Over the entire operating temperature range Repeatability, max. (in % of Sr) 5 %, For UB = 20 … 30 V DC, ambient temperature Ta = 23 °C ± 5 °C Switching hysteresis 15 % Number of digital switching outputs 1 Piece(s) Voltage type DC Switching current, max. 200 mA Residual current, max. 0.1 mA Voltage drop 2 V Switching element Transistor, NPN Switching principle NO (normally open) Switching frequency 1,000 Hz Readiness delay 100 ms Number of connections 1 Piece(s) Function Signal OUTVoltage supply Type of connection Cable Cable length 2,000 mm Sheathing material PVC Cable color Gray Number of conductors 3 -wire Wire cross section 0.2 mm² Design Cylindrical Dimension (Ø x L) 12 mm x 42 mm Thread size M12 x 1 mm Type of installation Embedded/flush Housing material Metal Metal housing Nickel-plated brass Sensing face material Plastic, Polybutylene (PBT) Net weight 76 g Housing color Red, RAL 3000Silver Type of fastening Mounting thread Standard measuring plate 12 x 12 mm², Fe360 Type of display LED Number of LEDs 1 Piece(s) Ambient temperature, operation -25 ... 70 °C Ambient temperature, storage -30 ... 80 °C Degree of protection IP 67 Protection class II Test procedure for EMC in accordance with standard IEC 61000-4-2IEC 61000-4-3IEC 61000-4-4 Standards applied IEC 60947-5-2 Aluminum 0.4 Stainless steel 0.75 Copper 0.45 Brass 0.35 Fe360 steel 1 Customs tariff number 85365019 ECLASS 5.1.4 27270101 ECLASS 8.0 27270101 ECLASS 9.0 27270101 ECLASS 10.0 27270101 ECLASS 11.0 27270101 ECLASS 12.0 27274001 ECLASS 13.0 27274001 ECLASS 14.0 27274001 ECLASS 15.0 27274001 ECLASS 16.0 27274001 ETIM 5.0 EC002714 ETIM 6.0 EC002714 ETIM 7.0 EC002714 ETIM 8.0 EC002714 ETIM 9.0 EC002714 ETIM 10.0 EC002714
Rs. 0.00
-
LV-NH100 KEYENCE
Specifications Model LV-NH100 Type Area thrubeam, High performance FDA (CDRH) Part 1040.10 Class 1 Laser Product IEC 60825-1 Light source Visible red semiconductor laser, Wavelength: 660 nm Detectingdistance MEGA 2000 mm(Detecting area: 10 mm) ULTRA SUPER TURBO FINE HSP Environmental resistance Ambient temperature -10 to +55 °C (No freezing) Relative humidity 35 to 85 % RH (No condensation) Material Case Glass reinforced plastic Lens cover Transmitter: Glass, Receiver: Polyarylate Weight Approx. 75 g
Rs. 0.00
-
FS-N11CP KEYENCE
Specifications Model FS-N11CP Type Standard 1 outputM8 connector*1 Output PNP Main unit/Expansion unit Main unit Control output 1PNP open collector 24 V; 1 output max: 100 mA or less; 2 output total: 100 mA or less (used stand-alone)/20 mA or less (multiple connections); residual voltage 1 V or less External input 1Input time 2 ms (ON)/20 ms (OFF) or more (25 ms or more (ON/OFF) when external calibration is selected.) Light source Red, 4-element LED APC ON/OFF switchable (Factory setting: OFF) Response time 50 µs (HIGH SPEED) /250 µs (FINE) /500 µs (TURBO) /1 ms (SUPER) /4 ms (ULTRA) /16 ms (MEGA) Number of interference prevention units 0 for HIGH SPEED; 4 for FINE; 8 for TURBO/SUPER/ULTRA/MEGA(When set to double, the number of interference-prevention units will be doubled.) Unit expansion Up to 16 units can be connected total (two output type is treated as two units) Rating Power voltage 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less Current Consumption Normal: 950 mW or less (39 mA max. at 24 V, 52 mA max. at 12 V)*2Eco on mode: 850 mW or less (35 mA max. at 24 V, 44 mA max. at 12 V)*2Eco Full mode: 520 mW or less (21 mA max. at 24 V, 26 mA max. at 12 V) Environmental resistance Ambient light Incandescent lamp: 20,000 lux or less, Sunlight: 30,000 lux or less Ambient temperature -20 to +55 °C (No freezing)*3 Relative humidity 35 to 85 % RH (No condensation) Vibration resistance 10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z directions Shock resistance 500 m/s2, 3 times in each of the X, Y, and Z directions Case material Both main unit and expansion unit housing material: Polycarbonate Weight Approx. 22 g
Rs. 0.00
-
FU-10
Specifications Model FU-10 Type Variable spot Focal distance 10 to 30 mm Fibre unit length 2 m free-cut Fibre unit diameter ø1.3×2 Environmental resistance Ambient temperature -40 to +70 °C Weight Approx. 5 g
Rs. 1,321.00
-
Keyence FU-20
Item specifics Condition New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. See all condition definitionsopens in a new window or tab Brand Keyence MPN Does not apply Manufacturer Part Number Does not apply Type Fiber Optic Sensor Model FU-20 UPC Does not apply
Rs. 1,261.00
-
FU-4FZ KEYENCE
Specifications Model FU-4FZ*1 Size ø3 mm Fibre unit length 2 m free-cut Fibre unit diameter ø1.3×2 Minimum bend radius R2 mm Tough-Flex Minimum detectable object Gold wire with a diameter of 0.005 mm *2 Environmental resistance Ambient temperature -40 to +50 °C Weight Approx. 8 g
Rs. 800.00
-
IGT203 IFM
Functionality Type Sensor Measuring Media Metallic target Sensor Type Inductive sensor Measurement Accuracy ± 10 % (Real sensing range Sr) Temperature Range 0...100 °C (Ambient temperature) Measurement Range 8 mm (Sensing range) Measurement Sensor Type Inductive Number Of Sensors 1 Thread Size M18 x 1 Instrument Type Sensor Part Type Inductive sensor Application Use in hygienic areas / regular cleaning processes Mounting Type Flush mountable, Threaded type Included Hardware Lock nuts: 2 Output Signal PNP Ports And Interfaces M12 Connector Wired Connectivity Yes Highlighted Features Reverse polarity protection, Gold-plated contacts, High protection rating for the requirements of harsh industrial environments Repeatability 1...20 % of Sr (Hysteresis) Power Voltage 2.5 V (Max. voltage drop switching output DC) Power Source Limited Voltage/Current Amperage < 10 mA (Current consumption), 100 mA (Permanent current rating of switching output DC) Power Consumption < 10 mA Dimensions M18 x 1 / L = 46 mm, M18 x 1 / L = 45 mm Color Silver Material Stainless steel (1.4404 / 316L) (lock nuts), PEEK natural (sensing face), PEI (LED window) Weight 44.7 g Finish Machined metallic finish Shape Cylindrical, Threaded type Top Use Cases Use in the food industry, Harsh industrial environments, Hygienic applications (especially within the demanding food and beverage industry) Typical Users Professional operators, Engineers Sustainability Certifications IP69K, EN 55011, EN 61000-4-2 ESD, EN 61000-4-3 HF radiated, EN 61000-4-4 Burst Show less
Rs. 3,658.00
-
IGT203 IFM
Functionality Type Sensor Measuring Media Metallic target Sensor Type Inductive sensor Measurement Accuracy ± 10 % (Real sensing range Sr) Temperature Range 0...100 °C (Ambient temperature) Measurement Range 8 mm (Sensing range) Measurement Sensor Type Inductive Number Of Sensors 1 Thread Size M18 x 1 Instrument Type Sensor Part Type Inductive sensor Application Use in hygienic areas / regular cleaning processes Mounting Type Flush mountable, Threaded type Included Hardware Lock nuts: 2 Output Signal PNP Ports And Interfaces M12 Connector Wired Connectivity Yes Highlighted Features Reverse polarity protection, Gold-plated contacts, High protection rating for the requirements of harsh industrial environments Repeatability 1...20 % of Sr (Hysteresis) Power Voltage 2.5 V (Max. voltage drop switching output DC) Power Source Limited Voltage/Current Amperage < 10 mA (Current consumption), 100 mA (Permanent current rating of switching output DC) Power Consumption < 10 mA Dimensions M18 x 1 / L = 46 mm, M18 x 1 / L = 45 mm Color Silver Material Stainless steel (1.4404 / 316L) (lock nuts), PEEK natural (sensing face), PEI (LED window) Weight 44.7 g Finish Machined metallic finish Shape Cylindrical, Threaded type Top Use Cases Use in the food industry, Harsh industrial environments, Hygienic applications (especially within the demanding food and beverage industry) Typical Users Professional operators, Engineers Sustainability Certifications IP69K, EN 55011, EN 61000-4-2 ESD, EN 61000-4-3 HF radiated, EN 61000-4-4 Burst Show less
Rs. 3,658.00
