Material Acciaio Alkaline Exterior finish Black Oxide Manufacturer grade Very durable Head style Fillister Colour N.A

Read more less

Model Tubular Inductive Proximity Sensor Detection distance 5 mm ± 10% Secure sensing distance 0 ~ 4 mm Standard sensing object Iron 12 x 12 x 1 mm Sensing distance Unshielded / 非隔離型 Description Standard M12 Hysteresis ≦ 10 % of sensing distance Response time 500 Hz Operating voltage DC 12 ~ 30 V Current consumption ≦ 14 mA no-load Load current 100 mA Max. at DC 24V Residual voltage ≦ DC 2V Insulation resistance 20MΩ min. (DC500V) Voltage withstandability AC 1000 V 60Hz for 60 Sec. Opera tetemperature -20℃ ~ + 60℃ Protection degree IP 67 Option M84R-2M-PVC / M84RL-2M PVC Wiring method Ø4.2 x 2M / 4 wires Weight 65g

Read more less

Type Description Select All Category Sensors, Transducers Proximity Sensors Manufacturer MEAN WELL USA Inc. Series - Packaging Box Part Status Active Sensor Type Inductive Sensing Distance 0.197" (5mm) Output Type NPN/PNP-NC/NO Response Frequency - Shielding Unshielded Material - Body Stainless Steel Voltage - Supply 12V ~ 30V Termination Style Cable Leads Operating Temperature -20°C ~ 60°C Ingress Protection IP67 Indicator No Indicator Package / Case Cylinder, Threaded - M12 Base Product Number PSC

Read more less

Product Specifications Features Best Quality Automation Grade Automatic Application SAFETY RELAY FD1878 Color Red Black Usage indusrary Material ABS Plastic Size standard Voltage 24 VDC / 100-240 VAC Volt (v) Warranty 1 Year from Date of INvoice Color Red Black Mop 2 Shipping Type free Price Type fixed Returnable No MRP 3500.00 INR Packsize 1 Currency INR Stock Quantity 10 Price 3500.00 INR (Approx.) Brand Name PIZZATO Unit Type Number Product Unit 2 Number Moq 2 Minimum Ordered Packs 2 Minimum Order Quantity 2 GSTIN 0% Product Overview

Read more less

Connector, Universal, 3-position, Plug straight M8, coding: A, Insulation displacement connection, knurl material: Zinc die-cast, nickel-plated, external cable diameter 2.5 mm ... 5 mm In stock Expected to leave our warehouse in Germany on Apr 9, 2026, if ordered now Product details Expand all  All Dutch English French German Similar products SACC-M 8MS-3QO-0,25-M - Connector 1441008 In stock Add or Remove from List Add 1 piece to cart SACC-M 8MS-3QO-0,5-VA - Connector 1426313 In stock Add or Remove from List Add 1 piece to cart SACC-M 8MS-3QO-0,25-M VPE150 - Connector 1327134 Made to order Add or Remove from List Add 150 pieces to cart SACC-M 8FS-3QO-0,5-M - Connector 1441066 In stock Add or Remove from List Add 1 piece to cart SACC-M 8MS-3QO-0,5-M VPE100 - Connector 1195171 Made to order Add or Remove from List Add 100 pieces to cart SACC-M 8FS-3QO-0,25-M - Connector 1441040 In stock Add or Remove from List Add 1 piece to cart SACC-M 8FS-3QO-0,5-VA - Connector 1426314 Add or Remove from List Add 1 piece to cart Compatible products Expand all  All Adapter insert Cable reel Sealing cap Tool Torque screwdriver Your advantages Safe use in the field, thanks to a high degree of protection Insulation displacement connection: innovative and time-saving assembly without stripping the single wire Customers also bought SACC-M 8FS-3QO-0,5-M - Connector 1441066 In stock Add or Remove from List Add 1 piece to cart SACC-M 8MS-4QO-0,5-M - Connector 1441037 In stock Add or Remove from List Add 1 piece to cart SACC-M 8FS-4QO-0,5-M - Connector 1441079 In stock Add or Remove from List Add 1 piece to cart SACC-M 8MS-3QO-0,25-M - Connector 1441008 In stock Add or Remove from List Add 1 piece to cart SAC-3P- 5,0-PUR/M 8FS - Sensor/actuator cable 1669628 In stock Add or Remove from List Add 1 piece to cart SACC-M 8FS-3QO-0,25-M - Connector 1441040 In stock Add or Remove from List Add 1 piece to cart SACC-M12MS-4QO-0,34-M - Connector 1641691 Add or Remove from List Add 1 piece to cart SAC-3P-10,0-PUR/M 8FS - Sensor/actuator cable 1694101 Add or Remove from List Add 1 piece to cart SAC-4P- 5,0-PUR/M 8FS - Sensor/actuator cable 1681868 Add or Remove from List Add 1 piece to cart Frequently searched   Circular connectors, 6-pos.  Circular connectors, 12-pos.  Circular connectors, 3-pos.  M12 male, 12-pos.  M12 male, 17-pos.  Circular connectors, 2-pos.  Circular connectors, 5-pos.  Circular connectors, 7-pos.  Circular connectors, 4-pos.  Circular connectors, 8-pos. Add or Remove from List Why can’t I see prices? Piece Packing unit: 1 piece  Add to cart Where Can I Buy This Item? Ask a Question Show product details (PDF) Product Help Phoenix Contact GmbH & Co. KG Flachsmarktstraße 8, D-32825 Blomberg  Ask a Question  +49 5235-300  info@phoenixcontact.com © 2026 Phoenix ContactSite noticeLegal informationData privacyWhistleblowing systemPrivacy Settings Tell Us What You Think Phoenix Contact on Privacy We use Cookies on our website and our portals and store them in your browser. Depending on their function and purpose, users’ consent may be required for the use of certain Features Safe use in the field, thanks to a high degree of protection Flexible: connectors for on-site assembly Insulation displacement connection: innovative and time-saving assembly without stripping the single wire Tech Specifications Diameter housing 12.5 mm Length 43.4 mm External cable diameter 2.5 mm ... 5 mm ±0.2 mm Stripping length of the sheath 40 mm Ambient temperature (operation) -25 °C ... 80 °C (Plug / socket) Degree of protection IP65 Degree of protection IP67 Rated current at 40°C 4 A Rated voltage 48 V AC Rated voltage 60 V DC Number of Positions 3 Insulation resistance = 100 MO Coding A - standard Standards/regulations M8 connector IEC 61076-2-104 Status display No Overvoltage category II Degree of pollution 3 Connection Method Insulation displacement connection Conductor cross section 0.25 mm² ... 0.5 mm² Conductor cross section AWG 24 ... 20 Wire diameter including insulation 1.1 mm ... 1.55 mm Frequency of connections between conductors of the same cross section 10 Wire insulation material PVC / PE / PP / rubber Structure of individual litz in acc. with VDE 0295 / smallest wire diameter Class 2-6 Insertion/withdrawal cycles = 100 Torque 0.6 Nm (Pressure nut) Torque 0.2 Nm (M8 knurl) Flammability rating according to UL 94 HB Contact material CuSn Contact surface material Ni/Au Contact carrier material TPU GF Material of grip body PA 6 Material, knurls Zinc die-cast, nickel-plated Sealing material NBR Standard designation M8 connector Standards/regulations IEC 61076-2-104 Connection in acc. with standard CUL Flammability rating according to UL 94 HB China RoHS Environmentally Friendly Use Period = 50 China RoHS For details about hazardous substances go to tab “Downloads”, Category “Manufacturer's declaration” Color handle area black REACh SVHC Lead 7439-92-1 Rated current at 40?C 4 A Note NOTE: Observe the permissible bending radii when laying conductors, since the degree of protection may be put in jeopardy if the bending forces are too high. Alleviate mechanical loads upstream of the connector, e.g. by using cable ties. Signal type/category Universal

Read more less

Description 1641691 is a 4-position, straight plug, universal M12 sensor/actuator connector. This A-coded connector is connected by insulation displacement connection which allows connection without stripping any single wire. Contact material is made of Copper Tin in bright alloy/white bronze finish and knurl material is nickel plated zinc die-cast. The product has housing diameter of 16.3mm, length of 54mm, and external cable diameter of 3.5 mm to 6 mm. Conductor cross section is 22 to 26AWG. Search Keywords: SACCM12MS4QO034M SPECS Supplier: Phoenix Contact Part No: SACC-M12MS-4QO-0-34-M Alias/AKA: 1641691 Unit of Measure: Per Each RoHS: Yes HTS: 8536694020 COO: DE ECCN: EAR99 Supplier Standard Pack:  1

Read more less

Spec Detail Specifications and design of the products are subject to change without notice for the product improvement. Item Specifications Product Number FX-102P Part Number FX-102P Products Name Digital Fiber Sensor Product details Long sensing range type The price of the product Please contact our office Applicable regulations and certifications CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), UL/c-UL Listing certification Supply voltage 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less Power consumption Normal operation: 720 mW or less (Current consumption 30 mA or less at 24 V supply voltage)ECO mode: 600 mW or less (Current consumption 25 mA or less at 24 V supply voltage) Output PNP open-collector transistor- Maximum source current: 100 mA- Applied voltage: 30 V DC or less (between output and +V)- Residual voltage: 1.5 V or less (at 100 mA source current) Output:Output operation Selectable either Light-ON or Dark-ON, at SET mode Output:Short-circuit protection Incorporated External input PNP non-contact input- Signal conditionHigh: +4 V to +V DC (Sink current 0.5 to 3 mA)Low: 0 to +0.6 V DC or Open- Input impedance: 10 kOhm approx. Response time Emission frequency 1: 2.5 ms or less (factory default setting)Emission frequency 2: 2.8 ms or lessEmission frequency 3: 3.2 ms or lessEmission frequency 4: 5.0 ms or less Sensitivity setting 2-point teaching / Limit teaching / Full-auto teaching Operation indicator Orange LED (lights up when the output is ON) Digital display 4 digits (green) + 4 digits (red) LCD display Fine sensitivity adjustment function Incorporated Timer function ON-delay / OFF-delay timer, switchable either effective or ineffective[Timer period: 1 ms, 5 ms, 10 ms, 20 ms, 40 ms, 50 ms, 100 ms, 500 ms, 1,000 ms] Emission amount setting function 3-level + Auto setting Interference prevention function Incorporated Emission frequency selection method (Functions at emission frequency 1, 2, 3 or 4)(Note) When using the interference prevention function, set the emission frequencies for the amplifiers to be covered by the interference prevention function to different frequency values. Ambient temperature –10 to +55 ℃ +14 to +131 ℉(If 4 to 7 units are mounted close together: –10 to +50 ℃ +14 to +122 ℉, if 8 to 16 units are mounted close together: –10 to +45 ℃ +14 to +113 ℉) (No dew condensation or icing allowed),Storage: –20 to +70 ℃ –4 to +158 ℉ Ambient humidity 35 to 85 % RH, Storage: 35 to 85 % RH Ambient illuminance Incandescent light: 3,000 lx or less at the light-receiving face Voltage withstandability 1,000 V AC for one min. between all supply terminals connected together and enclosure(Note) The voltage withstandability and the insulation resistance values given in the above table are for the amplifier only. Insulation resistance 20 MOhm , or more, with 250 V DC megger between all supply terminals connected together and enclosure(Note) The voltage withstandability and the insulation resistance values given in the above table are for the amplifier only. Vibration resistance 10 to 150 Hz frequency, 0.75 mm 0.030 in double amplitude in X, Y and Z directions for two hours each Shock resistance 98 m/s2 acceleration (10 G approx.) in X, Y and Z directions five times each Emitting element (modulated) Red LED (Peak emission wavelength: 643 nm 0.025 mil) Material Enclosure: PolycarbonateKey switch: PolycarbonateFiber lock lever: PBT Connection method Connector(Note) Connector attached cable CN-14A-C2 is not attached to the models that have no ''-CC2'' at the end of the model Nos.Make sure to use the optional connector attached cable CN-14A(-R)-Cx or the connector CN-14A, or a connector manufactured by J.S.T. Mfg., Ltd.(contact: SPHD-001T-P0.5, housing: PAP-04V-S). Cable length Total length up to 100 m 328.084 ft is possible with 0.3 mm2, or more, cable. Weight Net weight: 15 g approx.Gross weight: 35 g approx. Accessory FC-FX-1(Protection cover): 1 pc. scroll scroll scroll

Read more less

Spec Detail Specifications and design of the products are subject to change without notice for the product improvement. Item Specifications Product Number FX-501 Part Number FX-501 Products Name Digital Fiber Sensor Product details Standard type Applicable regulations and certifications CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), UL/c-UL Listing certification Supply voltage 12 to 24 V DC+10-15 % Ripple P-P 10 % or less Power consumption Normal operation: 960 mW or less (current consumption 40 mA or less at 24 V supply voltage)ECO mode: 680 mW or less (current consumption 28 mA or less at 24 V supply voltage) Output NPN open-collector transistor- Maximum sink current: 100 mA (Note 1)- Applied voltage: 30 V DC or less (between output and 0 V)- Residual voltage: 2 V or less (Note 2) (at maximum sink current)(Note 1) 50 mA max. if 5 or more standard types are connected together.(Note 2) 50 mA max. if 5 or more standard types are connected together. (25 mA in case of 2-output type and cable type) Output:Output points 1 point Output:Output operation Switchable either Light-ON or Dark-ON by L/D mode Output:Short-circuit protection Incorporated Response time H-SP: 25 micro s or lessFAST: 60 micro s or lessSTD: 250 micro s or lessLONG: 2 ms or lessU-LG: 4 ms or lessHYPR: 24 ms or less, selectable External input - External input(switchable with Output 2) - Possible external input function - Sensitivity setting 2-point teaching / Limit teaching / Full-auto teaching / Manual adjustment Incident light intensity display range H-SP / FAST / STD: 0 to 4,000LONG: 0 to 8,000U-LG / HYPR: 0 to 9,999 Timer function Incorporated with variable OFF-delay / ON-delay /One-shot / ON-delay - OFF-delay / ON-delay - One-shot timer, switchable either effective or ineffective Timer function:Timer period Timer range ''ms'': 0.5 ms approx., 1 to 9,999 ms approx., 1 ms approx.Timer range ''sec.'': 0.5 s approx., 1 to 32 s approx., 1 s approx.Timer range ''1/10 ms'': 0.05 ms approx., 0.1 to 999.9 ms approx., 0.1 ms approx.each output is set individually Emission amount setting function Incorporated, 3 levels (each level 25 to 100 %) + Auto setting [1 level (25 to 100 %) when using H-SP mode] Interference prevention function Incorporated (Note) , selectable either automatic interference prevention or different frequency(Note) Number of sensor heads which is possible to be mounted closely in auto interference prevention function depends on response time as shown in table below.Number of sensor heads which is possible to be mounted closely in different frequency Interference prevention function is up to 3 units.- Number of sensor heads mountable closely (Unit: set)Response time: IP-1H-SP: 0FAST: 2STD: 4LONG: 8U-LG: 8HYPR: 12 Various settings Hysteresis setting / Shift amount setting / Emission power setting / Display turning setting / ECO setting / Data bank loading saving setting / Copying setting / Code setting / Reset setting / Logical calculation setting / Threshold value tracking setting, etc. Protection IP40 (IEC) Ambient temperature -10 to +55 ℉ +14 to +131 ℉ [If 4 to 7 units are mounted in cascade: -10 to +50 ℉ +14 to +122 ℉　or if 8 to 16 units are mounted in cascade: -10 to +45 ℉ +14 to +113 ℉　] (No dew condensation or icing allowed), Storage: -20 to +70 ℉ -4 to +158 ℉　 Vibration resistance 10 to 150 Hz frequency, 0.75 mm 0.030 in double amplitude (10 G max.) in X, Y and Z directions for two hours each Shock resistance 98 m/s2 acceleration (10 G approx.) in X, Y and Z directions five times each Emitting element (modulated) Red LED (Peak emission wavelength: 643 nm 0.025 mil) Material Enclosure, Case cover: PolycarbonateSwitch: Polyacetal Cable - Cable extension - Weight Net weight: 15 g approx.Gross weight: 70 g approx. Accessory FX-MB1 (Amplifier protection seal): 1 set

Read more less

Product Attribute Attribute Value Select Attribute Manufacturer: Panasonic Product Category: Photoelectric Sensors Delivery Restrictions:  This item may require additional fees and documentation. Customs delays may also occur. RoHS:   Sensing Method: Reflective Sensing Distance: 15 mm to 100 mm Light Source: Red LED Amplifier Type: Built In Output Configuration: PNP Connection Method: Cable Supply Voltage - Min: 12 VDC Supply Voltage - Max: 24 VDC Minimum Operating Temperature: - 25 C Maximum Operating Temperature: + 55 C Brand: Panasonic Industrial Automation Country of Assembly: Not Available Country of Diffusion: Not Available Country of Origin: JP IP Rating: IP67 Operating Supply Voltage: 12 VDC to 24 VDC Product Type: Photoelectric Sensors Series: CX-400 1 Subcategory: Sensors

Read more less

Type Description Select All Category Industrial Automation and Controls Industrial Sensors Photoelectric, Industrial Manufacturer Panasonic Industrial Automation Sales Series CX-400 Packaging Box Part Status Active Sensing Method Reflective Sensing Distance 0.079" ~ 1.969" (2mm ~ 50mm) Voltage - Supply 12V ~ 24V Response Time 1ms Output Configuration PNP - Open Collector Light Source Red LED Connection Method Cable Ingress Protection IP67 Cable Length 78.74" (2m) Adjustment Type - Operating Temperature -25°C ~ 55°C Base Product Number CX-441

Read more less

Spec Detail Specifications and design of the products are subject to change without notice for the product improvement. Item Specifications Product Number EX-14A Part Number EX-14A Products Name Ultra-slim Photoelectric Sensor Product details Convergent reflective (Diffused beam type) [Front sensing] Applicable regulations and certifications CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), ISO 13849-1 (Category 1, PLc) (Note), UL Recognition certification(Note) : Conformed from December 2021 production. Sensing range 2 to 25 mm 0.079 to 0.984 in (Conv. point: 10 mm 0.394 in)(Note) The sensing range and the hysteresis are specified for white non-glossy paper (50 × 50 mm 1.969 × 1.969 in) as the object. Min. sensing object ø0.1 mm ø0.004 in copper wire (Completely beam interrupted object) (Setting distance: 10 mm 0.394 in) Hysteresis 15 % or less of operation distance(Note) The sensing range and the hysteresis are specified for white non-glossy paper (50 × 50 mm 1.969 × 1.969 in) as the object. Repeatability(perpendicular to sensing axis) 0.1 mm 0.004 in or less Supply voltage 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less Current consumption 13 mA or less Output NPN open-collector transistor- Maximum sink current: 50 mA- Applied voltage: 30 V DC or less (between output and 0 V)- Residual voltage: 2 V or less (at 50 mA sink current),1 V or less (at 16 mA sink current) Output:Utilization category DC-12 or DC-13 Output:Short-circuit protection Incorporated Response time 0.5 ms or less Operation indicator Orange LED (lights up when the output is ON) Incident beam indicator - Stability indicator Green LED (lights up under stable light received condition or stable dark condition) Pollution degree 3 (Industrial environment) Protection IP67 (IEC) Ambient temperature -25 to +55 ℃ -13 to +131 ℉ (No dew condensation or icing allowed), Storage: -30 to +70 ℃ -22 to +158 ℉ Ambient humidity 35 to 85 % RH, Storage: 35 to 85 % RH Ambient illuminance Incandescent light: 3,000 lx or less at the light-receiving face Voltage withstandability 1,000 V AC for one min. between all supply terminals connected together and enclosure Insulation resistance 20 MOhm , or more, with 250 V DC megger between all supply terminals connected together and enclosure Vibration resistance 10 to 500 Hz frequency, 3 mm 0.118 in double amplitude (20 G max.) in X, Y and Z directions for two hours each Shock resistance 500 m/s2 acceleration (50 G approx.) in X, Y and Z directions three times each Emitting element Red LED (Peak emission wavelength: 680 nm 0.027 mil, modulated) Material Enclosure: PolyarylateLens: Polyarylate Cable 0.1 mm2 3-core (emitter: 2-core) cabtyre cable, 2 m 6.562 ft long Cable extension Extension up to total 50 m 164.042 ft is possible with 0.3 mm2, or more, cable.(Note) : For safety applications, do not exceed 30 m 98.425 ft. Weight Net weight: 20 g approxGross weight: 40 g approx Accessory Mounting screws: 1 set

Read more less

  Type Description Select All Category Industrial Automation and Controls Industrial Sensors Proximity Sensors - Industrial Manufacturer Panasonic Industrial Automation Sales Series GX Packaging Box Part Status Active Sensor Type Inductive Sensing Distance 0.13" (3.3mm) Output Type PNP-NO, 3-Wire Response Frequency 500Hz Shielding Unshielded Material - Body Plastic Voltage - Supply 12V ~ 24V Termination Style Cable Leads Operating Temperature -25°C ~ 70°C Ingress Protection IP68 Indicator LED Package / Case Module Base Product Number GX-F12
