DELIVERY PERIOD : 1-2 WEEKS Manufacturer OMRON Type of relay interface Contacts configuration SPDT Control voltage 24V DC Max. operating current 6A AC contacts rating @R(at resistive load) at resistive load 6A / 250V AC DC contacts rating @R(at resistive load) at resistive load 6A / 30V DC Switched voltage max. 125V DC, max. 440V AC Mounting for DIN rail mounting Manufacturer series G2RV-SR Leads screw terminals Relay variant Relay set Operate time 20ms Release time 40ms Operating temperature -40...55°C Contact material silver alloy Body dimensions 88.8x6.2x78mm Contact resistance 100m Mechanical durability 5000000 cycles Electrical life 50000 cycles Gross weight29.2 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Limit Switches RoHS:  Details REACH - SVHC: Details Illuminated: Non-Illuminated Contact Form: DPDT Actuator: Roller Lever Current Rating: 100 mA Voltage Rating AC: 125 VAC Voltage Rating DC: 30 VDC Operating Force: 13.34 N Termination Style: Screw Mounting Style: Chassis Mount IP Rating: IP67 Actuator Style: Roller Lever Brand: Omron Automation and Safety Product Type: Limit Switches Series: WL Factory Pack Quantity: 1 Subcategory: Switches Type: Two-Circuit Limit Switch Part # Aliases: WLCA122N Unit Weight: 275 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Attribute Value Select Attribute Brand: Omron Automation and Safety Description/Function: NO Height: 29 mm Length: 47 mm Maximum Operating Temperature: + 70 C Minimum Operating Temperature: - 25 C Product Type: Proximity Sensors Series: E2EQ Factory Pack Quantity: 1 Subcategory: Sensors Width: 29 mm Part # Aliases: E2EQX7D1 Unit Weight: 40 g

Read more less

Degree of protection Flux tight Terminal structure PCB terminal Coil Coil ratings 24 VDC 20.8 mA Coil resistance 1152 Ω Operate voltage (Set voltage) 75 % max. Release voltage (Reset voltage) 10 % min. Maximum voltage 110 % Power consumption Approx. 500 mW Contact Contact rated load 250 VAC 6 A (Resistive load)30 VDC 6 A (Resistive load) Max. contact voltage 250 VAC125 VDC Max. contact current AC: 6 ADC: 6 A Contact form 4PST-NO/DPST-NC Contact material Au plating＋Ag alloy Performance Contact resistance 100 mΩ max. (Voltage drop method with 5 VDC 1 A) Operating time 20 ms max. (With rated operating power applied, 23 ℃, not including contact bounce) Reset time 20 ms max. (With rated operating power applied, 23 ℃, not including contact bounce) Maximum operating frequency Mechanical: 36000 time/hourRated load: 1800 time/hour Insulation resistance Between coil and contacts: 1000 MΩ min. (at 500 VDC)Between contacts of different polarity: 1000 MΩ min. (at 500 VDC)Between contacts of same polarity: 1000 MΩ min. (at 500 VDC) Dielectric strength Between coil and contacts: 4000 VAC 50/60 Hz 1 minBetween contacts of different polarity (Between pole 3 and pole 5_pole 4 and pole 6_pole 5 and pole 6): 2500 VAC 50/60 Hz 1 minBetween contacts of different polarity (Except for between pole 3 and pole 5_pole 4 and pole 6_pole 5 and pole 6): 4000 VAC 50/60 Hz 1 minBetween contacts of same polarity: 1500 VAC 50/60 Hz 1 min Vibration resistance (destruction) 10 to 55 to 10 Hz, 0.75 mm single amplitude (1.5 mm double amplitude) Vibration resistance (Malfunction) 10 to 55 to 10 Hz, 0.75 mm single amplitude (1.5 mm double amplitude) Shock resistance (destruction) 1000 m/s2 Shock resistance (Malfunction) 100 m/s2 Endurance (Mechanical) 10,000,000 operations min. (switching frequency 36,000 operations/h) Endurance (Electrical) 100,000 operations min. (rated load) Failure rate 5 VDC 1 mA (failure level: Preference value, Switching frequency: 300 operations per minute) Ambient temperature (Operating) -40 to 85 ℃ (with no freezing or condensation) Ambient humidity (Operating) 5 to 85 % Weight Approx. 25 g Mounting method Socket, Soldering Applicable socket P7SA-14F/ P7SA-14F-ND/ P7SA-14P/ P7SA-14F-ND-PU

Read more less

Manufacturer Omron Product Category Relay Sockets & Hardware Packaging Each Product Type Relay Sockets & Hardware Subcategory Relays

Read more less

Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Relay Sockets & Fixings RoHS:  Details Product: Relay Sockets Termination Style: Plug In Brand: Omron Automation and Safety Height: 17 mm Mounting Style: DIN Rail Number of Contacts: 8 Product Type: Relay Sockets & Hardware Factory Pack Quantity: 1 Subcategory: Relays Width: 45 mm Part # Aliases: P3G-08Q P3G08Q 1275773 P3G08 Unit Weight: 73 g

Read more less

Small general purpose power switching relay for industrial use.[Features]·A high-capacity version of Type MY, which is available in a wide variety of types including ones with operation indicator lights, surge absorbing elements, etc.· The contact structure is 1C, 2C, 3C and 4C.· The standard product is compliant with international UL, CSA, and SEV standards and the Product Safety of Electrical Appliances and Materials Act of Japan.· Equipped with an arc barrier for arc interruption. Withstand voltages up to 2,000 V.· New built-in diode and built-in CR circuit models are now available as part of the product series. The lineup also includes the types that are compliant with the international LR and VDE standards.[Applications]·Various control equipment at production sites where high reliability is required.· Used not only for electric, water, gas and other control systems, but also for most types of electrical machinery and equipment.

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Rated power supply voltage 24 VDC If power supply incorporates a single-phase full-wave rectifier. Allowable voltage variable range 85 to 110% of the power supply voltage Power consumption Relay ON: Approx. 1.1 W (at 24 VDC)/Relay OFF: Approx. 0.1 W (at 24 VDC) Reset voltage 10% max. of rated supply voltage Number of time ranges 4 Operation mode ON delay, Interval, Flicker OFF start, Flicker ON start Control output (Type) Time-limit: 4PDT Control output (Contact output) Resistive load: 3 A at 250 VAC (cosφ=1)Minimum applicable load: 1 mA at 1 VDC (failure level: P) Ambient temperature range Operating: -10 to 50 ℃ (with no icing)Storage: -25 to 65 ℃ (with no icing) Ambient humidity range Operating: 35 to 85 % Accuracy of operating time ±1% FS max. (±1% ±10 ms in a range of 1 s) Setting error ±10% FS ±50 ms max. Reset time 0.1 s max. (including halfway reset) Influence of voltage ±2% FS max. Influence of temperature ±2% FS max. Insulation resistance 100 MΩ min. (at 500 VDC) Dielectric strength Between current carrying terminals and exposed non-current carrying metal parts: 2000 VAC 50/60 Hz 1 min (Terminal screw sections are not excluded)Between operating power circuit and control output: 2,000 VAC 50/60 Hz 1 minBetween contacts of different polarity: 1,500 VAC 50/60 Hz 1 minBetween non-continuous contacts: 1,000 VAC 50/60 Hz 1 min Impulse withstand voltage Between power terminals: 1 kVBetween current carrying terminals and exposed non-current carrying metal parts: 1.5 kV Noise immunity ±1.5 kV square-wave noise by noise simulator (pulse width: 100 ns/1 µs, 1-ns rise) Static immunity Mulfunction: 4 kV, Destruction: 8 kV Vibration resistance Destruction: 10 to 55 Hz, 0.75 mm single amplitude each in 3 directions for 1 hourMalfunction: 10 to 55 Hz, 0.5 mm single amplitude each in 3 directions for 10 min Shock resistance Destruction: 1,000 m/s2, 3 times each in 6 directionsMalfunction: 100 m/s2, 3 times each in 6 directions Life expectancy (relay output) Electrical: 200,000 operations min. (3 A at 250 VAC, resistive load at 1800 operations/h, Room temperature)Mechanical: 10 million operations min. (under no load at 1,800 operations/h) Degree of protection IP40 Connecting method 14-pin round socket Case color Beige Weight Approx. 50 g Applicable socket PYFZ-14/ PYFZ-14-E/ PY14/ PY14-02

Read more less

Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Industrial Relays Delivery Restrictions:  Mouser does not sell this product in your region. RoHS: N Product: Slim Form Relays Contact Termination: Screw Relay Contact Form: 1 Form C (SPDT-NO, NC) Contact Current Rating: 6 A Coil Termination: Screw Coil Type: Non-Latching Coil Voltage: 24 VDC Switching Voltage: 400 VAC, 125 VDC Series: G2RV Brand: Omron Automation and Safety Contact Form: SPDT (1 Form C) Product Type: Industrial Relays Subcategory: Relays Part # Aliases: G2RVSL700DC24 Unit Weight: 17 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Connector Type Plug-In Contact Material Silver Tin Oxide Contact Type 4pdt Mounting Type Plug In Mount Brand Omron About this item Coil Voltage - 100/110 vac 14PIN Plug-in Terminal With LED Indicator Contact Form - 4PDT

Read more less

DELIVERY PERIOD : 1-2 WEEKS Solid State Relay, Photocoupler, Applied output load: 3 A at 3 to 480 VDC, Rated input voltage: 5 to 24 VDC, With Operating indicator, Plug-in terminal, Certified by UL, CSA, and EN (TÜV certification) Product classification Relay compatible Operating indicator Equipped Rated voltage 5 to 24 VDC Rated load voltage 4 to 48 VDC Load current 0.1 to 3 A (at 40 ℃) Terminal structure Plug-in terminal

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Type Enclosed Mounting method Direct mounting Phase Single Power output 100 W Efficiency 87 % Output voltage 24 V Rated output current 4.5 A Temperature range -20-60 °C Features Terminal block facing forward Terminal type Screw Communication port(s) None Alarm function - Number of output branches 1 Rated supply voltage at AC 50 Hz 100-240 V Allowable supply voltage AC 85-264 V Allowable supply voltage DC 248-373 V Product Width (unpacked) 97 mm Product Height (unpacked) 38 mm Product Depth (unpacked) 159 mm
