| Number of inputs |
2 (single-ended) |
| Power supply |
via the E-bus |
| Signal voltage |
0…10 V |
| Distributed clocks |
– |
| Internal resistance |
> 130 kΩ |
| Input filter limit frequency |
1 kHz |
| Dielectric strength |
max. 30 V |
| Conversion time |
0.625 ms default setting, configurable, multiplex |
| Resolution |
12 bit (16 bit presentation incl. sign) |
| Measurement error/uncertainty |
< ±0.3% (relative to full scale value) |
| Electrical isolation |
500 V (E-bus/signal voltage) |
| Current consumption E-bus |
typ. 130 mA |
| Current consumption power contacts |
– |
| Bit width in the process image |
inputs: 8 byte |
| Special features |
activatable FIR/IIR filters, limit value monitoring |
| Weight |
approx. 60 g |
| Operating temperature |
-25…+60°C |
| Storage temperature |
-40…+85°C |
| Relative humidity |
95%, no condensation |
| Vibration/shock resistance |
conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission |
conforms to EN 61000-6-2/EN 61000-6-4 |
| Pluggable wiring level |
for all ESxxxx terminals |
| Protect. rating/installation pos. |
IP20/variable |
| Approvals/markings |
CE, CCC, ATEX, IECEx |
| Ex marking |
ATEX:
II 3 G Ex ec IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc |
