| Model |
LV-N10 |
| Type |
Zero line |
| Cable/connector |
– |
| Main/Expansion unit |
Expansion unit |
| I/O Control outputs |
None |
| External input |
| Monitor output |
| Response time |
80 µs (HIGH SPEED)/250 µs (FINE)/500 µs (TURBO)/1 ms (SUPER)/4 ms (ULTRA)/16 ms (MEGA) *1
|
| Output selection |
LIGHT-ON/DARK-ON (switch-selectable) |
| Timer function |
Timer OFF/OFF-delay timer/ON-delay timer/One-shot timer,
Timer duration selectable: 1 ms to 9,999 ms,
Maximum error against the setting value: ±10% max. |
| Control outputs |
NPN open collector 30 V, Residual voltage 1 V or less (Output current: 10 mA or less) / 2 V or less (Output current: 10 to 100 mA)
(Stand-alone) 1 output max: 100 mA or less, 2 output total: 100 mA or less
(Multiple connections) 1 output max: 20 mA or less |
| Monitor output |
– |
| External input |
Input time 2 ms (ON)/20 ms (OFF) or more*2
|
Multiple connections to
expansion units |
Up to 17 units can be connected in total (two-output type is treated as two units) |
| Protection circuit |
Reverse polarity protection, Over-current protection, Surge absorber |
Number of interference
prevention units |
Connected to other than LV-S31: 0 for HIGH SPEED; 2 for FINE/TURBO/SUPER; 4 for ULTRA/MEGA,
Connected to LV-S31: 2 for FINE; 4 for TURBO/SUPER/ULTRA/MEGA*3
|
| Case size |
H 32.6 mm 1.28″ × W 9.8 mm 0.39″ × L 78.7 mm 3.1″ |
| Rating Power voltage |
24 VDC (operating voltage 10 to 30 VDC (with ripple)), Ripple (P-P) 10 % or less, Class 2 or LPS*4*5
|
Power
consumption |
Normal: 830 mW or less (at 30 V. 30 mA at 24 V, 56 mA or less at 12 V)*6
Eco on mode: 710 mW or less (at 30 V. 26 mA at 24 V, 48 mA or less at 12 V)*6
Eco Full mode: 550 mW or less (at 30 V. 21 mA at 24 V, 40 mA or less at 12 V)
*7
|
| Environmental resistance
Ambient temperature
|
-20 to +55 °C -4 to 131 °F (No freezing)*8
|
| Relative humidity |
35 to 85 % RH (No condensation) |
| Vibration resistance |
10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
| Shock resistance |
500 m/s2, 3 times in each of the X, Y, and Z directions |
| Weight |
Approx. 20 g |
