| Bore Diameter: |
32 to 250 mm (Rod B), 40 to 250 mm (Rod C), 40 to 160 mm (Rod A) |
| Seal Material: |
Nitrile (NBR) [1], Urethane Rubber [2](φ32 to φ160), Fluorocarbon [3], Hydrogenated Nitrile (HNBR) [6](φ32 to φ160), Slipper Seal [8](φ32 to φ100) |
| Operating Pressure: |
14 MPa |
| Maximum Operating Pressure: |
9 MPa Cap Side, 15 MPa Rod Side(A), 13.5 MPa Rod Side(B), 11 MPa Rod Side(C) |
| Proof Pressure: |
21 MPa |
| Minimum Operating Pressure: |
0.3 MPa or Less, Cap Side, 0.6 MPa or Less, Rod Side(A), 0.45 MPa or Less, Rod Side(B), 0.4 MPa or Less, Rod Side(C) |
| Operating Speed: |
8 to 400 mm/sec (U Sealφ32 to φ63), 8 to 300 mm/sec (φ80 to φ125), 8 to 200 mm/sec (φ140 to φ250), 1 to 400 mm/sec (Slipper Sealφ32 to φ63), 1 to 300 mm/sec (φ80,φ100) |
| Operating Temperature: |
-10 to 80 °C (No freezing |
