Inserts
|
Suitable Shell:16BHood/Housing
|
|
Number of contacts
|
40
|
|
Electrical data acc. to EN 61 984
|
|
|
---Rated current
|
10A
|
|
---Rated voltage conductor
|
250V
|
|
---Rated impulse voltage
|
4kV
|
|
---Pollution degree
|
3
|
|
---Pollution degree 2 also
|
10A 230/400V 4kV 2
|
|
Rated voltage acc. to UL/CSA
|
600V
|
|
Insulation resistance
|
≥1010Ω
|
|
Material
|
polycarbonate
|
|
Limiting temperatures
|
-40℃...+125℃
|
|
Flammability acc. to UL 94
|
V0
|
|
Mechanical working life(mating cycles)
|
≥500
|
|
Contacts
|
|
Material
|
copper alloy
|
|
Surface
|
hard-gold plated
|
|
hard-silver plated
|
|
Contact resistance
|
≤3mΩ
|
|
Screw terminal
|
|
|
---Wrie gauge
|
0.14-2.5mm2
|
|
---AWG
|
26-14
|
|
---Tightening/Test torque
|
|
