| Cooling System |
None (Passive Cooling) |
| Control System |
Pulse Output to PLC/Drive |
| Rated Current |
Max. 50 mA |
| Way |
Shaft Type |
| Protection Level |
IP65 |
| Protection Class |
Class I |
| Cover Material |
Other, ABS Plastic |
| Rated Insulation Voltage |
500 V AC (insulation) |
| Components |
Encoder Body, Shaft, Cable/Connector |
| Connectivity Type |
Cable Outlet (1 m) or Connector |
| Features |
High Precision, Compact Design, Rugged Construction, Reliable Performance |
| Current Rating |
Max. 50 mA |
| Operating Voltage |
10-30 V DC |
| Base Material |
Other, Aluminium |
| Rated Operation Voltage |
10 - 30 V DC |
| Product Type |
Other, INCREMENTAL ENCODER |
| Material |
Other, High-grade Industrial Aluminium Alloy |
| Surface Finish |
Other, Fine Anodized |
| Standard |
Siemens Standard |
| Surface Color |
Other, Silver |
| Rated Voltage |
10 - 30 V DC |
| Frequency (MHz) |
Up to 300 kHz |
| Maximum Output Current |
No data available |
| Dimension (L*W*H) |
50 mm (diameter) x 60 mm (length) |
| Application |
Industrial Automation, Motion Control |
| IP Rating |
Other, IP65 |
| Display Type |
Other, No Display |
