| AC input voltage range |
90~264VAC; 127~370VDC |
| AC inrush current (max.) |
Cold start, 35A at 230VAC |
| DC adjustment range |
12V: 12~14V, 24V: 24~28V, 48V: 48~55V |
| Current adjustment range |
10%~100% rated output current adjustable by 1~10Vdc, PWM signal or resistance |
| Overload protection |
105%~130% Constant current limiting, auto-recovery |
| Over voltage protection |
14V: 14~17V, 24V: 29~33V, 48V: 56~65V Shut down o/p voltage, re-power on to recover |
| Over temperature protection |
Shut down o/p voltage, re-power on to recover |
| Withstand voltage |
I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC |
| Working temperature |
-20~+60!aC (refer to output derating curve |
| Safety standards |
UL60950-1, TUV EN60950-1 approved |
| EMC standards |
EN55022 classA, EN61000-3-2(125W for EDR-150),3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2(EN50082-2) |
| Connection (screw DIN terminal) |
I/P: 3 poles, O/P: 4 poles |
| Dimension (LxWxH) (mm) |
40x 125.2x 113.5 |
|
|
