Description
PowerDC
PFM InputNo
Non-IlluminatedNo
IP RatingIP67
DisplayNo
Supply Voltage18-30 V dc
Item StatusRELEASED
Housing StyleFlat Mount - Dome Window
Primary Housing MaterialPolycarbonate
IndicationYes
IlluminationNo
Mounting ThreadNo Thread
Color Input ControlIndividual (One wire/color, same number of colors as input wires)
Number of Colors3
Product Size (mm)80
Color TechnologyStandard LED
Color Option 1Green
Animation Option 1Multiple
ConnectionIntegral QD
Quick Disconnect TypeM12
Color Option 2Red
Animation Option 2Multiple
Color Option 3Yellow
Animation Option 3Multiple
Max Current Color (mA)40
Wire Selectable FunctionMulti-Function
Number of Input Pins/Conductors5
Input TypePNP
I/O Block CompatibleNo
Max Input Response Time (ms)10
Physical Dimensions (LxWxH or DxH mm)107.6 x 80.9 x 66.7
Environmental RatingIP67
Eye ShieldNo
High Temperature (up to 100 C)50
Min Op. Temperature (C)-40
Primary Housing ColorYellow
Primary Window MaterialAcrylic Diffused
Feature: Washdown RatedNo
Feature: AudibleNo
Feature: CascadeNo
Feature: Chemical ResistantNo
Feature: IlluminatedNo
Multi-Color DeviceSingle Color On - Alternating
Application: Traffic LightNo
Feature: Quick DisconnectYes
WirelessNo
USBNo
EPLAN StatusPublished
EPLAN Original Sent Date10/27/202
