| Application |
Interface |
| Number of phases |
1 |
| Mounting method |
With plug-in socket |
| Terminal type |
Plug-in |
| Complete with socket |
|
| LED indicator |
|
| Rated operational voltage, AC |
100-240 V |
| Operating voltage range, AC |
75-264 V |
| Rated operational voltage, DC |
75-264 V |
| Operating voltage range, DC |
75-264 V |
| Rated operation current Ie at AC-1 |
2 A |
| Product Height (unpacked) |
29 mm |
| Product Width (unpacked) |
13 mm |
| Product Depth (unpacked) |
28 mm |
| Supply voltage DC |
5-24 V |
| Control current max. |
15 mA |
| Must operate voltage max. |
4 V |
| Must release voltage min. |
1 V |
| Maximum operating temperature |
80 °C |
| Minimum operating temperature |
-30 °C |
| Isolation |
Phototriac |
| Switching at zero-crossing |
|
