The EUCHNER NG1VS-510L024-M is a robust, metal-housed, IP67-rated limit switch with a continuously adjustable steel roller lever arm, offering high mechanical durability with 30 million operating cycles and precise switching with a snap-action, silver-alloy contact (1 NO + 1 NC). Designed to EN 50041, it's suitable for industrial automation in challenging environments, including conveyor systems, automated production lines, and machine tools.
-
Robust Design: Anodized die-cast metal housing resists corrosion and provides durability in tough conditions.
-
High Mechanical Life: Engineered for up to 30 million operating cycles.
-
IP67 Protection: Rated to protect against dust and immersion in water up to 1 meter for 30 minutes.
-
Adjustable Lever: A continuously adjustable steel roller lever arm, 28-75mm in length.
-
Versatile Actuator Head: The actuator head can be adjusted in 4x90-degree increments.
-
High Precision: Features a switching element with a high operating point accuracy of +/- 0.002 mm max.
-
Snap-Action Switching: Utilizes a snap-action switching element for reliable contact.
