Description
-
Type: Contactor
-
Poles: 3P (3 Normally Open Contacts)
-
Rated Operational Voltage (Ue): ≤ 440 V AC
-
Rated Operational Current (Ie): 9 A (AC-3)
-
Coil Voltage: 220 V AC
-
Utilization Category: AC-3 (Squirrel cage motors: starting, switching off)
-
Mechanical Durability: Up to 10 million operations
-
Electrical Durability: Up to 1 million operations
-
Mounting: Screw mounting or snap-on mounting on 35 mm DIN rail
-
Terminal Type: Screw terminals
-
Dimensions: Compact design for space-saving installation
-
Standards Compliance: IEC/EN 60947-4-1, UL 60947-4-1, CSA C22.2 No. 14
-
Environmental Protection: IP20 (finger-safe protection)
-
Ambient Temperature: -25°C to +60°C
-
Storage Temperature: -55°C to +85°C
Applications
The LC1D09M7 contactor is ideal for controlling three-phase motors, heating systems, and other electrical loads in various industries, including manufacturing, HVAC, and automation.
Benefits
- High reliability and long service life
- Compact and modular design for easy installation
- Compatible with a wide range of accessories (e.g., auxiliary contacts, timers)
- Energy-efficient coil design
- Global certifications for use in multiple regions
