| ETIM Group: |
Sensors |
| ETIM Class: |
Luminescence sensor |
| Ambient temperature: |
- - - |
| Analogue output 0 mA ... 20 mA: |
- |
| Analogue output 0 V ... 10 V: |
- |
| Analogue output -10 V ... +10 V: |
- |
| Analogue output 4 mA ... 20 mA: |
- |
| AWG-number: |
- |
| Degree of protection (IP): |
IP67 |
| Diameter sensor: |
- |
| Height of sensor: |
53mm |
| Length of sensor: |
80mm |
| Light dot: |
- |
| Material housing: |
Zinc |
| Max. output current: |
100mA |
| No-load current: |
60mA |
| Nominal operating distance: |
- |
| Number of contact energized outputs with signalling function: |
- |
| Number of semiconductor outputs with signalling function: |
- |
| Operation agent-safety class: |
Safety class 2 |
| Setting procedure: |
Other |
| Switching frequency: |
1500Hz |
| Type of electric connection: |
Connector M12 |
| Type of switching output: |
PNP |
| Voltage type: |
DC |
| Width sensor: |
30.4mm |
| With blanking function: |
- |
| With exchange lens: |
- |
| With fibre optics connection: |
- |
| With time function: |
