MODEL-MPCB MMP-T32LF 0.63-1A

Description

Series MMP-T SERIES
Type MOTOR CIRCUIT BREAKERS
Compliant with Standard(s) EN 60947-4-1, EN 60947-2, IEC 60947-4-1, GB14048.2, IEC 60947-2
Frame Size 32
Number of Poles 3
Rated Current (A) 0,63
Rated Voltage (V) 690
Frequency Range (Hz) 50/60
Rated Capacity (kW) 0,18
Heater Designation (A) 0,63
Range of Setting Current (A) 0,4-0,63
Breaking Capacity at 415V (kA) 100
Electrical Durability (Load) 100000 OPERATIONS
Mech. Durability (at no Load) 100000 OPERATIONS
Wiring SCREW-CLAMP
Automatic Tripping Device THERMAL-MAGNETIC (ADJUSTABLE)

Product Dimensions & Weight

Width (mm) 45
Height (mm) 90
Depth (mm) 82
Weight (kg) 0,33

Conformity

CE COMPLIANT
UL/cUL NON-COMPLIANT
EAC NON-COMPLIANT
UKCA COMPLIANT

MODEL-MPCB MMP-T32LF 0.63-1A

Product form

Series MMP-T SERIES Type MOTOR CIRCUIT BREAKERS Compliant with Standard(s) EN 60947-4-1, EN 60947-2, IEC 60947-4-1, GB14048.2, IEC 60947-2 Frame... Read more

Rs. 3,937.50 Excl. VAT

    Description

    Series MMP-T SERIES
    Type MOTOR CIRCUIT BREAKERS
    Compliant with Standard(s) EN 60947-4-1, EN 60947-2, IEC 60947-4-1, GB14048.2, IEC 60947-2
    Frame Size 32
    Number of Poles 3
    Rated Current (A) 0,63
    Rated Voltage (V) 690
    Frequency Range (Hz) 50/60
    Rated Capacity (kW) 0,18
    Heater Designation (A) 0,63
    Range of Setting Current (A) 0,4-0,63
    Breaking Capacity at 415V (kA) 100
    Electrical Durability (Load) 100000 OPERATIONS
    Mech. Durability (at no Load) 100000 OPERATIONS
    Wiring SCREW-CLAMP
    Automatic Tripping Device THERMAL-MAGNETIC (ADJUSTABLE)

    Product Dimensions & Weight

    Width (mm) 45
    Height (mm) 90
    Depth (mm) 82
    Weight (kg) 0,33

    Conformity

    CE COMPLIANT
    UL/cUL NON-COMPLIANT
    EAC NON-COMPLIANT
    UKCA COMPLIANT
