| Display method |
4-digit 7-segment LED |
| Character height |
14.2mm |
| Max. display Range |
-1999 to 9999 |
| Measurement |
AC current, Frequency |
| Input specification |
0-5A, 0-2.5A, 0-1A, 0-500mA, 0-250mA, 0-100mA, 0-50mA |
| AC Measurement |
Average value (AVG), Root mean square value (RMS) |
| Power voltage |
100-240VAC~ 50/60Hz |
| Output_Main Output(Comparative Value) |
Relay (HI, GO, LO) |
| Display accuracy |
• 23℃±5℃ - ± 0.3 % F.S. rdg ± 3 digit (frequency: ± 0.1 % F.S. rdg ± 2-digit)
• -10℃ to 50℃ - ± 0.5 % F.S. rdg ± 3-digit |
| A/D conversion method |
ΣΔ (Sigma Delta) ADC |
| Sampling cycle |
16.6ms |
| Hold function |
Includes (external hold function) |
| Environment_Ambient temperature |
-10 to 50℃, storage: -20 to 60℃ |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Insulation type |
Double insulation or reinforced insulation(mark:  , dielectric strength between the measuring input part and the power part: 1kV) |
| Protection structure |
IP56 (front part, IEC standard) |
| Unit weight (packaged weight) |
≈ 211 g (≈ 326 g) |
