Model-NJW-165-PM5-Male Connector

Description

Configured Specifications

  • Number Of Pins
    5
  • Applicable pin/contact
    Male
  • Wire connection method
    Solder
  • Allowable Current
    5
  • Connection direction
    Straight
  • Allowable Voltage
    125
  • Protection function (environmentally resistant)
    [Available] IP67 equivalent
  • Application
    Cable Connection
  • Representative Standard
    PSE
  • Connector Shape
    Round
  • Series starting with M, N, O
    NJW
  • Connector series initials
    M/N/O
  • Type of connector shape
    Plug
  • Connector shape characteristics
    General Shape
  • Shell Size
    16
  • Normal core/reverse core
    Reverse-core type
  • Used cable outer diameter
    4.0 to 4.8
  • Conforming wire conductor cross section
    0.5
  • Operating Temperature Range
    -25 to +85
  • Flange
    NA
  • Screw for Pipes
    NA
  • Angles for changing guide position (as seen from pin insert connection side)
    Standard
  • Shell plating treatment
    Special Processing
  • Contact plating treatment
    Silver
  • Trusco Code
    -
  • Specifications
    -
  • Mating partner 1
    NJW-165-AD(F)F5 [relay plug]
  • Mating partner 2
    NJW-165-AD(F)FK5 [relay plug]
  • Mating partner 3
    NJW-165-ADF5 [relay plug]
  • Mating partner 4
    NJW-165-ADFK5 [relay plug]
  • Mating partner 5
    NJW-165-RBF [panel receptacle]
  • Mating partner 6
    NJW-165-RF [panel receptacle]
  • Mating partner 7
    -
  • Mating partner 8
    -
  • Mating partner 9
    -
  • Mating partner 10
    -
  • Mating partner 11
    -
  • Mating partner 12
    -
  • Mating partner 13
    -
  • Mating partner 14
    -
  • Mating partner 15
    -
  • -
    -

Model-NJW-165-PM5-Male Connector

Product form

Configured Specifications Number Of Pins 5 Applicable pin/contact Male Wire connection method Solder Allowable Current 5 Connection direction Straight Allowable... Read more

Rs. 1,451.00 Excl. VAT

    Description

    Configured Specifications

    • Number Of Pins
      5
    • Applicable pin/contact
      Male
    • Wire connection method
      Solder
    • Allowable Current
      5
    • Connection direction
      Straight
    • Allowable Voltage
      125
    • Protection function (environmentally resistant)
      [Available] IP67 equivalent
    • Application
      Cable Connection
    • Representative Standard
      PSE
    • Connector Shape
      Round
    • Series starting with M, N, O
      NJW
    • Connector series initials
      M/N/O
    • Type of connector shape
      Plug
    • Connector shape characteristics
      General Shape
    • Shell Size
      16
    • Normal core/reverse core
      Reverse-core type
    • Used cable outer diameter
      4.0 to 4.8
    • Conforming wire conductor cross section
      0.5
    • Operating Temperature Range
      -25 to +85
    • Flange
      NA
    • Screw for Pipes
      NA
    • Angles for changing guide position (as seen from pin insert connection side)
      Standard
    • Shell plating treatment
      Special Processing
    • Contact plating treatment
      Silver
    • Trusco Code
      -
    • Specifications
      -
    • Mating partner 1
      NJW-165-AD(F)F5 [relay plug]
    • Mating partner 2
      NJW-165-AD(F)FK5 [relay plug]
    • Mating partner 3
      NJW-165-ADF5 [relay plug]
    • Mating partner 4
      NJW-165-ADFK5 [relay plug]
    • Mating partner 5
      NJW-165-RBF [panel receptacle]
    • Mating partner 6
      NJW-165-RF [panel receptacle]
    • Mating partner 7
      -
    • Mating partner 8
      -
    • Mating partner 9
      -
    • Mating partner 10
      -
    • Mating partner 11
      -
    • Mating partner 12
      -
    • Mating partner 13
      -
    • Mating partner 14
      -
    • Mating partner 15
      -
    • -
      -
