| Sensing Distance |
White paper 300 x 300 mm: 1 m |
| Brand |
Omron |
| Model Name/Number |
E3Z-D62 2M |
| Voltage |
12 to 24 VDC+-10% ripple (p-p) 10% max. |
| Shape |
Square |
| Light Source |
Infrared LED (860 nm) |
| Degree Of Protection |
IEC: IP67 |
| Weight |
Approx 65 Gram |
| Ambient Humidity Range |
35 to 85% (with no condensation) |
| Ambient Temperature Range |
-25 to 55 Deg C |
| Dielectric Strength |
1000 VAC 50/60 Hz 1 min |
| Insulation Resistance |
20 milliohm min. (500 VDC megger) |
| Sensing Method |
Diffuse-reflective |
| Current Consumption |
30 mA max |
| Case Material |
Polybutylene terephthalate (PBT) |
| Differential Distance |
20% max. of sensing distance |
| Lens Material |
Denatured Polyarylate |
