Name: MODEL-PLC CARD CJ1W-OD211 MAKE OMRON
Brand: Industry Baba
Price: 6800.0 INR
Availability: InStock

MODEL-PLC CARD CJ1W-OD211 MAKE OMRON

Product form

DELIVERY TIME : 1-2 WEEKS Power 24V DC Brand Omron Operating Load Voltage Range 10.2 to 26.4 VDC Rated Voltage... Read more

Rs. 6,800.00 Excl. VAT

Power	24V DC
Brand	Omron
Operating Load Voltage Range	10.2 to 26.4 VDC
Rated Voltage	12 to 24 VDC
Maximum Load Current	0.5 A/point,5.0 A/Unit
Maximum Inrush Current	4.0 A/point,10 ms max.
Leakage Current	0.1 mA max
Residual Voltage	1.5 V max
ON Response Time	0.1 ms max
OFF Response Time	0.8 ms max
Insulation Resistance	20 Mega Ohms
Internal Current Consumption	5 VDC 100 mA max
Ambient Operating Temperature	0 to 55 Degree Celsius
Ambient Humidity	10-90%
Model No	CJ1W-OD211
