The Pilz 774310 PNOZ X3 safety relay is designed for use in critical safety applications, featuring 3 Normally Open (n/o) contacts, 1 Normally Closed (n/c) contact, and 1 Solid State Output (so). Operating on both 24V AC and DC, this relay offers exceptional performance for safety monitoring, ensuring fast response and reliable operation in emergency stop systems and other safety circuits.
Key Features:
- 3 Normally Open (n/o) contacts, 1 Normally Closed (n/c) contact, 1 Solid State Output (so)
- 24V AC/DC operation for versatile applications
- Fast response time for critical safety functions
- Compliant with CE, UL, and TÜV safety standards
- Reliable design for industrial automation and machinery safety
Applications:
- Emergency stop systems
- Safety gate and device monitoring
- Automation and manufacturing safety systems
Technical Specifications:
| Product Type: |
Safety Relay |
| Model: |
774310 |
| Supply Voltage: |
24V AC/DC |
| Contacts: |
3 Normally Open (n/o) contacts, 1 Normally Closed (n/c) contact, 1 Solid State Output (so) |
| Inputs: |
For emergency stops, safety gates, etc. |
| Outputs: |
Relay outputs (3 n/o, 1 n/c), 1 Solid State Output (so) |
| Housing Material: |
Plastic (IP20 rated) |
| Mounting Type: |
DIN rail mounting |
| Dimensions (W x H x D): |
90 x 22.5 x 120 mm |
| Operating Temperature: |
-10°C to +55°C |
| Operating Humidity: |
95% RH (non-condensing) |
| Certification: |
CE, UL, TÜV |
