| Anfahrgeschwindigkeit |
max. 20 m/min |
| Approach direction |
|
| Actuating head on the right |
A |
| Connection type |
|
| 1 x |
Plug connector RC18
|
| Number of door position NO contacts |
1 |
| Number of guard lock monitoring NO contacts |
2 |
| Number of door position positively driven contacts |
2 |
| Number of guard lock monitoring positively driven contacts |
2 |
| Extraction force |
30 N |
| Actuation frequency |
max. 1200 1/h |
| Actuating force |
35 N |
| Lid |
black |
| Installation orientation |
any |
| Insertion depth |
52 mm |
| Storage temperature |
-25 ... 80 °C |
| Mechanical life |
1 x 10⁶ |
| Retention force |
10 N |
| Switching principle |
Slow-action switching contact |
| Degree of protection |
IP65 |
| Ambient temperature |
-25 ... 80 °C |
| Material |
|
| Contact |
Silver alloy, gold flashed |
| Housing |
Anodized die-cast alloy |
| Locking force Fmax
|
2000 N |
| Locking force FZh
|
1500 N |
| Guard locking principle |
Closed-circuit current principle |
