| Sensor |
Inductive |
| Size |
M12 |
| Mounting |
Shielded |
| Sensing Distance |
2 mm |
| Setting Distance |
0 to 1.6 mm |
| Output Configuration |
DC 3 Wire NPN |
| Operation Mode |
NO |
| Connection |
Pre Wired, Length 2M |
| Cable Specifications |
PVC (oil-resistant) |
| Power Supply Voltage |
12 to 24 VDC |
| Standard Target |
Iron, 12 × 12 × 1 mm |
| Differential Travel |
10% max. of sensing distance |
| Detectable Object |
Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Response Frequency |
1.5 kHz |
| Indicator |
Operation indicator (red) |
| Protection Circuit |
Load short-circuit protection, Surge suppressor, Reverse polarity protection |
| Ambient Temperature Range |
Operating/Storage: −40 to 85°C (with no icing or condensation) |
| Ambient Humidity Range |
Operating/Storage: 35% to 95% (with no condensation) |
| Insulation Resistance |
±15% max. of sensing distance at 23°C in the temperature range of −40 to 85°C ±10% max. of sensing distance at 23°C in the temperature range of −25 to 70°C |
| Dielectric Strength |
50 MΩ min. (at 500 VDC) between current-carrying parts and case |
| Vibration Resistance |
Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock Resistance |
Destruction: 1,000 m/s2 10 times each in X, Y, and Z directions |
| Voltage Influence |
±1% max. of sensing distance at rated voltage in the rated voltage ±15% range |
| Degree Of Protection |
IP67 |
