| Design |
With display |
| Process connection |
G 1/4'' female thread |
| Pressure type |
Relative pressure |
| Pressure range bar |
-1…10 bar |
| Pressure range psi |
-14.5…145.04 psi |
| Operating voltage |
18…33 VDC |
| Electrical output |
Switching output, Current output (3-wire), Voltage output (3-wire), IO-Link |
| Voltage output |
0…10 V |
| Current output |
4…20 mA |
| Communication protocol |
IO-Link |
| Electrical connection |
Connector, M12 × 1 |
| Housing material |
Stainless-steel/Plastic, 1.4404 (AISI 316L)/Grilamid TR90 UV/Elastollan C 65 A 15 HPM 000/Ultramid A3X2G5 |
| Materials (contact with media) |
Stainless steel 1.4404 (AISI 316L)/1.4542 (AISI 630) |
| Medium temperature |
-40…+80 °C |
| Ambient temperature |
-40…+80 °C |
| Protection class |
IP66/IP67/IP69K |
| Approvals |
CE, Metrological certification (RUS), cULus |
