| Rated cross-section [mm²] |
2,5 |
| Connection capacity [mm²] |
0,5 ÷ 2,5 |
| Rated current [A] |
24* |
| Rated current ATEX [A] |
20* |
| Short-time withstand current [A] |
300 |
| Insulation voltage Ui [V] |
1000 V AC / 1500 V DC |
| Voltage ATEX [V] |
500 |
| Impulse voltage U (Imp) [V] |
8000 |
| Tightening torque [Nm] |
0,4 |
| Tools |
Screwdriver PH 0 / 0,5 x 3 |
| Assembly method (on DIN rail) |
TH 15, TH 35, G 32 |
| Pollution degree |
2 |
| IP code |
20 |
| Operating temperature [°C] |
-40 ÷ +105 |
| Number of clamping points per level |
2 |
| Number of levels |
1 |
| End cover plate required |
YES |
| Testing |
IEC 60947-7-1 |
| ATEX approval |
Ex II 2G Ex eb IIC Gb /Ex I M2 Ex eb I Mb |
| Dimensions [mm] (width / height / length) |
5 / 40 / 41,8 |
| Weight [g] |
7 |
| Packing [pcs] |
100 |
| Clamping screw |
M 2,5 x 7,6 |
| Note |
*In case a plug-in-bridge is applied, the current load for RSA 2,5 A terminal is max 22 A. |
