Primary brand
Mitsubishi Electric
Main function
AC servo motor
Product series / family name
MELSERVO J2S series
Sub-range name
HC-KF series
Functions
AC brushless rotary servo motor
Design
straight shaft
built-in absolute feedback encod. (17-bit)
low inertia / small power capacity
fan cooling
Supply voltage (AC)
200Vac class
Rated active power (kW)
200W / 0.2kW
Rotational speed
3000rpm
4500rpm (maximum)
Moment of inertia
0.0000260kg.m2 (0.26kg.cm2)
Mounting mode
60x60mm flange mounting
Resolution
17-bit (equivalent to 131072ppr) feedback
Degree of protection
IP55
Dimensions
H72.8mm x W42mm x D129.5mm
Ambient air temperature for operation
0...+40 °C
Ambient air temperature for storage
-15°C...+70 °C
Order code / Manufacturer SKU
HC-KFS23
Manufacturer product status
Discontinued
