MODEL- SERVO MOTOR HG-KR23

Description

Servo Motor
Series MELSERVO-J4
Type HG-KR
Rated Capacity (kW) 0,2
Rated Torque (Nm) 0,64
Maximum Torque (Nm) 2,2
Rated Speed (rpm) 3000
Maximum Speed (rpm) 6000
Inertia (kg*cm2) 0,221
Brake NO
Shaft Type STRAIGHT SHAFT
Protection Class IP65
Power Supply (V) 200
Current Type AC
Encoder Type 22-BIT
Encoder Resolution (p/rev) 4194304
Product Dimensions & Weight
Width (mm) 60
Height (mm) 77,1
Depth (mm) 76,6
Weight (kg) 0,91

MODEL- SERVO MOTOR HG-KR23

Product form

Servo Motor Series MELSERVO-J4   Type HG-KR   Rated Capacity (kW) 0,2   Rated Torque (Nm) 0,64   Maximum Torque... Read more

Out of stock

Rs. 19,712.00 Excl. VAT

    Description

    Servo Motor
    Series MELSERVO-J4
    Type HG-KR
    Rated Capacity (kW) 0,2
    Rated Torque (Nm) 0,64
    Maximum Torque (Nm) 2,2
    Rated Speed (rpm) 3000
    Maximum Speed (rpm) 6000
    Inertia (kg*cm2) 0,221
    Brake NO
    Shaft Type STRAIGHT SHAFT
    Protection Class IP65
    Power Supply (V) 200
    Current Type AC
    Encoder Type 22-BIT
    Encoder Resolution (p/rev) 4194304
    Product Dimensions & Weight
    Width (mm) 60
    Height (mm) 77,1
    Depth (mm) 76,6
    Weight (kg) 0,91
