| Operation method |
Unipolar constant current drive |
| Applied Motor |
2-phase stepper motor |
| Resolution |
FULL STEP(1-division), HALF STEP(2-division), Micro STEP(4, 5, 8, 10, 16, 20-division) |
| Power voltage |
24-35VDC
|
| Max. Run Current |
2A/Phase |
| Max. Current Consumption |
3A |
| Number Of Axes |
1-axis |
| Input pulse characteristic_pulse width |
Min. 10㎲(CW, CCW), Min. 1ms(HOLD OFF) |
| Input pulse characteristic_Duty Rate |
50%(CW, CCW) |
| Input pulse characteristic_Rising/Falling time |
Max. 0.5㎲(CW, CCW) |
| Input pulse characteristic_Pulse input voltage |
[H]: 4-8VDC , [L]: 0-0.5VDC
|
| Input pulse characteristic_pulse input current |
4mA(CW, CCW), 10mA(HOLD OFF) |
| Input pulse characteristic_Max. input pulse freq |
Max. 50kHz(CW, CCW) |
| Environment_Ambient temperature |
0 to 50℃, storage: -10 to 60℃ |
| Environment_Ambient humidity |
35 to 85% RH, storage: 35 to 85% RH |
| Weight |
Approx. 295g(approx. 180g) |
