| Number of connections per level |
2 |
| Nominal cross section |
16 mm² |
| Level 1 above 1 below 1 |
| Connection method |
Screw connection |
| Screw thread |
M4 |
| Tightening torque |
1.5 ... 1.8 Nm |
| Stripping length |
11 mm |
| Internal cylindrical gage |
A7 |
| Connection in acc. with standard |
IEC 60947-7-1 |
| Conductor cross-section rigid |
2.5 mm² ... 25 mm² |
| Cross section AWG |
12 ... 4 (converted acc. to IEC) |
| Conductor cross-section flexible |
4 mm² ... 16 mm² |
| Conductor cross-section, flexible [AWG] |
10 ... 6 (converted acc. to IEC) |
| Conductor cross-section flexible (ferrule without plastic sleeve) |
1.5 mm² ... 16 mm² |
| Flexible conductor cross-section (ferrule with plastic sleeve) |
1.5 mm² ... 16 mm² |
| Cross-section with insertion bridge, rigid |
16 mm² |
| Cross-section with insertion bridge, flexible |
16 mm² |
| 2 conductors with same cross section, solid |
1.5 mm² ... 6 mm² |
| 2 conductors with same cross section, flexible |
1.5 mm² ... 6 mm² |
| 2 conductors with same cross section, flexible, with ferrule without plastic sleeve |
1.5 mm² ... 4 mm² |
| 2 conductors with the same cross section, flexible, with TWIN ferrule with plastic sleeve |
0.75 mm² ... 10 mm² |
| Nominal current |
76 A |
| Maximum load current |
101 A (with 25 mm² conductor cross-section) |
| Nominal voltage |
400 V |
| Nominal cross section |
16 mm² |
