Description
The Netter Vibration NEG 5020 electric vibrator operates at 3000 U/min, generating a force of 197 N with a power consumption of 0.035 kW. It is suitable for use in automation and drive technology applications, particularly for enhancing material flow in hoppers, silos, and chutes. This piece of equipment operates at 400 V and features compact dimensions for versatile installation.
| Type |
Electric vibrator |
| Supply Voltage |
400V |
| Power Rating |
0.035kW |
| Current Rating |
0.15A |
| RPM |
3000 U/min |
| Dimensions |
(A) 157 x (B) 75 x (C) 110 x (D) 60 x (E) 85 x (F) 90 x (G) 6,5 x (H) 38 x (I) 33 x (L) 72 x (M) 97 x (N) 65mm |
| Centrifugal force |
197N |
| Dim |
(A) 157 x (B) 75 x (C) 110 x (D) 60 x (E) 85 x (F) 90 x (G) 6,5 x (H) 38 x (I) 33 x (L) 72 x (M) 97 x (N) 65 |
| Misc Attribute |
NEG 5020 |
| Operating temperature (min.) |
-20°C |
