| Size |
M8 |
| Mounting type |
Unshielded |
| Sensing Distance |
2 mm |
| Setting distance |
0 to 1.6 mm |
| Output type |
DC 3 Wire NPN |
| Operation mode |
NO |
| Power supply |
12 to 24 VDC |
| Connection method |
Pre Wired, Length 2M |
| Cable Specifications |
PVC (oil-resistant) |
| Differential travel |
10% max. of sensing distance |
| Detectable object |
Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Standard target |
Iron, 12 × 12 × 1 mm |
| Response frequency |
0.8 kHz |
| Current consumption |
13 mA max |
| Indicator |
Operation indicator (red) |
| Protection circuit |
Load short-circuit protection, Surge suppressor, Reverse polarity protection |
| Ambient temperature range |
Operating/Storage: −40 to 85°C (with no icing or condensation) |
| Ambient humidity |
Operating/Storage: 35% to 95% (with no condensation) |
| Temperature influence |
±15% max. of sensing distance at 23°C in the temperature range of −40 to 85°C ±10% max. of sensing distance at 23°C in the temperature range of −25 to 70°C |
| Voltage influence |
±1% max. of sensing distance at rated voltage in the rated voltage ±15% range |
| Insulation resistance |
50 MΩ min. (at 500 VDC) between current-carrying parts and case |
| Dielectric strength |
1000 VAC, 50/60 Hz for 1 minute between current carry parts and case |
| Vibration resistance |
Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock resistance |
Destruction: 500 m/s2 10 times each in X, Y, and Z directions |
| Degree of protection |
IP67 |
| Weight |
Approx. 65 g |
