P1KK001

Description

  • Sensor type: Retro-reflex sensor for clear glass recognition
  • Operating range: 0 to 1500 mm
  • Reference reflector: RQ100BA
  • Clear glass detection: Yes
  • Light source: Red light
  • Polarisation filter: Yes
  • Optical design: Single-lens, no blind spot
  • Light spot diameter: 20 mm @ 0.2 m, 90 mm @ 1 m, 130 mm @ 1.5 m
  • Smallest detectable part: 0.7 mm @ 0.2 m, 6 mm @ 1 m, 10 mm @ 1.5 m
  • Switching hysteresis: Less than 5%
  • Max ambient light: 10,000 Lux
  • Service life (@ +25 °C): 100,000 h
  • Operating voltage: 10 to 30 V DC
  • Operating voltage with IO-Link: 18 to 30 V DC
  • Switching frequency: 2000 Hz (normal), 3500 Hz (speed mode)
  • Response time: 0.25 ms (normal), 0.14 ms (speed mode)
  • Switching output: PNP/NPN, NO/NC, antivalent (configurable)
  • Switching current: 100 mA max
  • Protection features: Short circuit, overload, reverse polarity
  • Interface: IO-Link V1.1
  • Protection class: III
  • Setting method: Potentiometer
  • Mounting: M3 threaded holes
  • Connection: M8 x 1, 4-pin male
  • Housing material: Plastic
  • Optic cover: PMMA
  • Protection rating: IP67, IP68
  • Temperature range: -40 to +60 °C
  • Dimensions: 15 x 32 x 61 mm (W x H x D)
  • Mounting torque: M3 screws, 0.5 Nm
  • Control panel functions: Switching distance adjustment, status/contamination warning, supply voltage indicator
  • Recommended reflectors: RQ100BA, RE18040BA, RR84BA, RE9538BA

P1KK001

Product form

Sensor type: Retro-reflex sensor for clear glass recognition Operating range: 0 to 1500 mm Reference reflector: RQ100BA Clear glass detection:... Read more

Rs. 1,802.00 Excl. VAT

    Description

    • Sensor type: Retro-reflex sensor for clear glass recognition
    • Operating range: 0 to 1500 mm
    • Reference reflector: RQ100BA
    • Clear glass detection: Yes
    • Light source: Red light
    • Polarisation filter: Yes
    • Optical design: Single-lens, no blind spot
    • Light spot diameter: 20 mm @ 0.2 m, 90 mm @ 1 m, 130 mm @ 1.5 m
    • Smallest detectable part: 0.7 mm @ 0.2 m, 6 mm @ 1 m, 10 mm @ 1.5 m
    • Switching hysteresis: Less than 5%
    • Max ambient light: 10,000 Lux
    • Service life (@ +25 °C): 100,000 h
    • Operating voltage: 10 to 30 V DC
    • Operating voltage with IO-Link: 18 to 30 V DC
    • Switching frequency: 2000 Hz (normal), 3500 Hz (speed mode)
    • Response time: 0.25 ms (normal), 0.14 ms (speed mode)
    • Switching output: PNP/NPN, NO/NC, antivalent (configurable)
    • Switching current: 100 mA max
    • Protection features: Short circuit, overload, reverse polarity
    • Interface: IO-Link V1.1
    • Protection class: III
    • Setting method: Potentiometer
    • Mounting: M3 threaded holes
    • Connection: M8 x 1, 4-pin male
    • Housing material: Plastic
    • Optic cover: PMMA
    • Protection rating: IP67, IP68
    • Temperature range: -40 to +60 °C
    • Dimensions: 15 x 32 x 61 mm (W x H x D)
    • Mounting torque: M3 screws, 0.5 Nm
    • Control panel functions: Switching distance adjustment, status/contamination warning, supply voltage indicator
    • Recommended reflectors: RQ100BA, RE18040BA, RR84BA, RE9538BA
