AC failure bridging time @ Inom
> 20 ms @ 230 V AC / > 20 ms @ 115 V AC
Earth leakage current, max.
3.5 mA
Housing version
Metal, corrosion resistant
Indication
Green LED (Uoutput > 21.6 V DC)
Yellow LED (loutput > 90 % IRated typ. )
red LED (overload, overtemperature, short-circuit, Uoutput <20.4 V DC)
Max. perm. air humidity (operational)
5 %…95 % RH
Mounting position, installation notice
on terminal rail TS 35
MTBF
-
- According to Standard:
- SN 29500
-
- Operating time (hours), min.:
- 1,500,000 h
-
- Ambient temperature:
- 25 °C
-
- Input voltage:
- 230 V
-
- Output power:
- 480 W
-
- Duty cycle:
- 100 %
-
- According to Standard:
- SN 29500
-
- Operating time (hours), min.:
- 679,000 h
-
- Ambient temperature:
- 40 °C
-
- Input voltage:
- 230 V
-
- Output power:
- 480 W
-
- Duty cycle:
- 100 %
Operating altitude
≤ 3000 m
Power factor (approx.)
> 0.98…230 V AC / > 0.98…115 V AC
Power loss, nominal load
43 W
Protection against over-heating
Yes
Protection against reverse voltages from the load
30…35 V DC
Short-circuit protection
Yes
Surge voltage category
II
