Weight 0.4 Kg Model No OM1300 Type of Product VIF Meter Weight (g) 400 g Dimension 96x96 sqmm Voltage 80-300 V Certification CE, UL Display Resolution 4 Digit 3 Row LED Display Country of Origin India Data Sheet Catalog Alpha & EDC Port Type - Inbuilt Ct 5A Name of Manufacturer/Packer/Importer Elmeasure India Pvt. Ltd.

Read more less

Product classification Relay compatible Zero cross function Equipped Operating indicator Equipped Rated voltage 5 to 24 VDC Rated load voltage 100 to 240 VAC Load current 0.1 to 3 A (at 40 ℃) Terminal structure Plug-in terminal

Read more less

PART NUMBER: MR-RB3N PRODUCT DETAILS: Resistance regeneration converter unit - Mitsubishi Electric (MELSERVO J4 series) - Rated output 300W / 0.3kW - Resistance 9Ω - Supply voltage 100Vac or 200Vac - equivalent to MRRB3N

Read more less

General brand PSC Prime model_number Mitsubishi 3.6 Volt Lithium Battery Model: ER17330V/3.6V for CNC Machine System Type Lithium Suitable Device CNC Machine Brand Color Yellow and Black Net Quantity 1 Warranty Warranty Summary Not applicable Service Type Not applicable Covered in Warranty Not applicable Not Covered in Warranty Not applicable

Read more less

Features   Brand: Epcos   Product Category: Power Factor Correction Capacitors   Series: B32343C   Product: Phicap PFC Capacitors

Read more less

Mode of operation Double-acting Piston diameter 63 mm Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 1870 N Stroke 80 mm Cushioning Elastic cushioning rings/plates at both ends

Read more less

Specifications General Sales Package Dig Timer with Push Wheel Setting Brand Selec Model Number XT364-3 Type Programmable Color Black Suitable For Indoor Number of Programs Per Day 0 Dimensions Height 96 mm Width 96 mm Weight 300 g Power Features Power Requirement 240 Power Consumption 0 mW Rechargeable Battery No

Read more less

Application Area for Plastic Industry Control Type On/Off Display Size 96*96 mm Output type Relay Sensor Input RTD, Thermocouple Dimension 96*96 panel size Country of Origin Made in India

Read more less

Contactor Type Magnetic Contactors Number of Poles 4 Pole Mounting Type PC Board Voltage 440V Switching Current 22A Electricity Type DC Usage/Application Industrial Phase Three Phase Power 7.5kW Brand Fuji Electric Model NO SC-5-1/G Availability In Stock

Read more less

A TECHNO 1 Inch 2/2 Way Diaphragm Valve 2W-250-25 is a type of valve that uses a flexible diaphragm to regulate the flow of fluids. It consists of a body, a diaphragm, and a mechanism to actuate the diaphragm, such as a handwheel, pneumatic actuator, or electric actuator. The diaphragm is typically made of a flexible material such as rubber or synthetic elastomer, and it forms a barrier between the fluid flow path and the valve body. When the diaphragm is in the closed position, it seals against the valve seat, preventing fluid from passing through the valve. When the diaphragm is lifted or moved away from the seat, it allows fluid to flow through the valve. Diaphragm valves are commonly used in applications where precise control of fluid flow and tight shut-off are required. They are particularly well-suited for handling corrosive, abrasive, or viscous fluids, as well as fluids containing suspended solids or slurries. One of the key advantages of diaphragm valves is their ability to provide a tight seal even when handling fluids that may be prone to leakage or contamination. Additionally, they are relatively simple in design, easy to operate, and require minimal maintenance. Diaphragm valves find applications in various industries, including water treatment, pharmaceuticals, chemical processing, food and beverage, and biotechnology. They are used in processes such as flow control, shut-off, throttling, and dosing. Overall, diaphragm valves offer reliable performance, excellent sealing capabilities, and versatility, making them suitable for a wide range of fluid handling applications across different industries.

Read more less

Operating mechanism Snap action ctuator Roller plunger 9.5 dia. x 5Resin roller Frequency 50/60 Hz Contact form 1NC/1NO Load General load/Micro load Conduit M20Number of conduit: 1 Ambient temperature Operating: -30 to 70 ℃ (with no icing) Ambient humidity 95 %RH max. Permissible operating frequency 30 operations / 1 minute max. Contact resistance (Initial value) 25 mΩ max. Insulation resistance 100 MΩ min. Impulse withstand voltage Between each terminal of the same polarities: 2.5 kVBetween each terminal of the different polarities: 4 kVBetween each terminal and non-live-metallic part: 6 kV Durability Mechanical: 15,000,000 operations min. Vibration resistance Malfunction: 10 to 55 Hz, 0.75 mm single amplitude Shock resistance Destruction: 1000 m/s2Malfunction: 300 m/s2 Degree of protection IP67 Classification of protection against electric shock Class II (Double insulation) Operating Force (OF) Standard value 6.5 N max. Release Force (RF) Standard value 1.5 N min. Pre-Travel (PT) Standard value 2 mm max. Movement Differential (MD) Standard value 1 mm max. Over-Travel (OT) Standard value 4 mm min. Operating Position (OP) Standard value 28.6±0.8 mm Total Travel (TT) Reference value 6 mm Direct Opening Force Standard value 20 N min. Direct Opening Travel Standard value 3.2 mm min.

Read more less

Product Details: Product Description Brand Autonics Model Number BM3M-TDT Sensing Type Transmitted beam Sensing Distance 3m Sensing Target Opaque material of min. Ø8mm Response time Max. 1ms Power Supply 12-24VDC ±10%(ripple P-P: max. 10%) current Consumption Max. 45mA Sensitivity adjustment Fixed Operation mode Dark ON Control output PNP open collector Connection type Cable type(Ø4, 2m) Environment  Ambient illumination Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) Environment  Ambient temperature -10 to 60℃, storage: -25 to 70℃ Protection structure IP64 Environment Ambient humidity 35 to 85% RH, storage: 35 to 85% RH Approval CE Material Case: Acrylonitrile butadiene styrene, Sensing part: Polycarbonate, Bracket: Steel plate cold commercial, Bolt: Steel chromium molybdenum, Nut: Steel chromium molybdenum Accessories Fixing bracket, Bolts, Nuts Weight Approx. 170g Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.

Read more less
