SizeStandard Nominal size7 mm Type of seal on screwed plugCoating Mounting positionoptional DesignStraight design Size of pack10 DesignPush-pull principle Operating pressure complete temperature range-0.095 MPa ... 0.6 MPa Operating pressure complete temperature range-0.95 bar ... 6 bar Operating pressure complete temperature range-13.775 psi ... 87 psi Temperature-dependent operating pressure-0.095 MPa ... 1.4 MPa Temperature-dependent operating pressure-0.95 bar ... 14 bar Temperature-dependent operating pressure-13.775 psi ... 203 psi Note on operating pressureWater: max. 0.6 MPa at max. 50°C Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) Note on operating and pilot mediumLubricated operation possible Corrosion resistance class CRC1 - Low corrosion stress LABS (PWIS) conformityVDMA24364-B1/B2-L Cleanroom suitability, measured according to ISO 14644-14Class 4 according to ISO 14644-1 Ambient temperature-10 °C ... 80 °C Product weight14 g Type of mountingExternal hexagon, size 14 mm Pneumatic connection, port 1Male thread R1/4 Pneumatic connection, port 2For tubing outside diameter of 8 mm Colour of release ringBlue Note on materialsRoHS-compliant Material housingBrass, nickel-plated Material release ringPOM Material tubing sealNBR Material tubing clamp componentHigh-alloy stainless steel

Read more less

SizeStandard Nominal size5 mm Type of seal on screwed plugCoating Mounting positionoptional DesignStraight design Size of pack10 DesignPush-pull principle Operating pressure complete temperature range-0.095 MPa ... 0.6 MPa Operating pressure complete temperature range-0.95 bar ... 6 bar Operating pressure complete temperature range-13.775 psi ... 87 psi Temperature-dependent operating pressure-0.095 MPa ... 1.4 MPa Temperature-dependent operating pressure-0.95 bar ... 14 bar Temperature-dependent operating pressure-13.775 psi ... 203 psi Note on operating pressureWater: max. 0.6 MPa at max. 50°C Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) Note on operating and pilot mediumLubricated operation possible Corrosion resistance class CRC1 - Low corrosion stress LABS (PWIS) conformityVDMA24364-B1/B2-L Cleanroom suitability, measured according to ISO 14644-14Class 4 according to ISO 14644-1 Ambient temperature-10 °C ... 80 °C Product weight15 g Type of mountingExternal hexagon, size 14 mm Pneumatic connection, port 1Male thread R1/4 Pneumatic connection, port 2For tubing outside diameter of 6 mm Colour of release ringBlue Note on materialsRoHS-compliant Material housingBrass, nickel-plated Material release ringPOM Material tubing sealNBR Material tubing clamp componentHigh-alloy stainless steel

Read more less

specifications Type R Male Thread with External Hex Country of Origin India Tolerance To Nominal Tightening Torque ± 20 % Series Quick Star Type of Product Push-in-Fitting Part No 190646 Weight 46 g Color Silver, Blue Nominal Size 6.7 mm Ambient Temperature -10 °C ... 80 °C Operating Pressure -0.95 bar ... 14 bar Material Code 6471127 Model No QS-1/2-10 Housing Material Brass, Nickel-Plated Connection 1 Male Thread R1/2 Connection 2 For Tubing OD - 10 mm Tightening Torque 26 Nm Name of Manufacturer/Packer/Importer Festo India Private Limited Nominal Size (mm) 6.7 mm

Read more less

echnical Data SizeStandard Nominal size3 mm Type of seal on screwed plugCoating Mounting positionoptional DesignStraight design Size of pack10 DesignPush-pull principle Operating pressure complete temperature range-0.095 MPa ... 0.6 MPa Operating pressure complete temperature range-0.95 bar ... 6 bar Operating pressure complete temperature range-13.775 psi ... 87 psi Temperature-dependent operating pressure-0.095 MPa ... 1.4 MPa Temperature-dependent operating pressure-0.95 bar ... 14 bar Temperature-dependent operating pressure-13.775 psi ... 203 psi Note on operating pressureWater: max. 0.6 MPa at max. 50°C Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) Note on operating and pilot mediumLubricated operation possible Corrosion resistance class CRC1 - Low corrosion stress LABS (PWIS) conformityVDMA24364-B1/B2-L Cleanroom suitability, measured according to ISO 14644-14Class 4 according to ISO 14644-1 Ambient temperature-10 °C ... 80 °C Product weight7.4 g Type of mountingExternal hexagon, size 10 mm Pneumatic connection, port 1Male thread R1/8 Pneumatic connection, port 2For tubing outside diameter of 4 mm Colour of release ringBlue Note on materialsRoHS-compliant Material housingBrass, nickel-plated Material release ringPOM Material tubing sealNBR Material tubing clamp componentHigh-alloy stainless steel

Read more less

Description PUSH BUTTON P2AF2 BLACK MAKE-TEKNIC PLASTIC

Read more less

Brand S.E Material Polyurethane (PU) Colour Green

Read more less

Sensing Distance 5 mm Usage for Industrial Material Stainless Steel Brand Autonics Sensor Type NPN NO Power supply voltage 12-24 VDC Availability In Stock Wire type and power DC 3-wire type 12-24VDC  Sensing side diameter M12 Sensing distance 4mm Installation Shield(flush) Standard sensing target 12×12×1mm(iron) Response frequency 500Hz Current specification Current consumption: Max. 10mA Control output NPN Normally Open Material Brass(nickel plated) Cable Standard/material Standard cable Protection structure IP67 Body length Standard type Environment_Ambient temperature -25 to 70℃, storage: -30 to 80℃ Environment_Ambient humidity 35 to 95% RH, storage: 35 to 95% RH Hysteresis(distance) Max. 10% of sensing distance Residual voltage Max. 1.5V Weight ≈ 62g (≈ 74g)

Read more less

Part number BLO.PVSL 400-24-40 Manufacturer BLOCK Type Component Type number PVSL 400/24-40 Order number PVSL 400/24-40 Designation EN_US Switched mode power supply, 24Vdc, 40A Description EN_US Switched Mode Power Supply three phase, Series: POWER VISION, Input: 400-500Vac 50-60Hz, Output: 24Vdc, 40A, Power Boost: 60A / 4s, 100A / 50ms, Terminals: pluggable Cage Clamps, Ambient temperature: -25°C... +70°C Languages EN_US, DE_DE Product group Electrical engineering > Voltage source and generator > Voltage source

Read more less

FA-COM PLC: Digital I/O Module Series MELSEC IQ-F SERIES Type TRANSISTOR OUTPUT (SOURCE) Occupied I/O Points on PLC 16 Integrated Digital Outputs 16 Output Type TRANSISTOR Output Logic SOURCE Conformity CE COMPLIANT UL/cUL COMPLIANT EAC NON-COMPLIANT Shipping Approvals ABS,BV,DNV GL,KR,LR,NK,RINA UKCA COMPLIANT Product Dimensions & Weight Width (mm) 40 Height (mm) 90 Depth (mm) 83 Weight (kg) 0,194 Product Packaging Cardboard (g) 52 Other paper (g) 0 Aluminum (g) 0 Steel (g) 0 Styrofoam (g) 0 Other plastic (g) 0 Wood (g) 0 Glass (g) 0 Others (g) 0

Read more less

DELIVERY PERIOD : 1- 2 WEEKS FA-COM PLC: Digital I/O Module Series MELSEC-F SERIES Type FX2N Occupied I/O Points on PLC 8 Integrated Digital Inputs 4 Integrated Digital Outputs 4 Output Type RELAY Product Dimensions & Weight Depth (mm) 87 Weight (kg) 0,2 Width (mm) 43 Height (mm) 90 Conformity CE COMPLIANT Shipping Approvals DNV GL EAC COMPLIANT UL/cUL COMPLIANT UKCA COMPLIANT

Read more less

Battery Capacity 500mAH Voltage 3V Battery Type Lithium Usage/Application PLC Memory Backup Brand Mitshubishi Model Name/Number Mitsubishi Fx3u 32BL Availability In Stock

Read more less
