Specifications Model FS-N11CP Type Standard 1 outputM8 connector*1 Output PNP Main unit/Expansion unit Main unit Control output 1PNP open collector 24 V; 1 output max: 100 mA or less; 2 output total: 100 mA or less (used stand-alone)/20 mA or less (multiple connections); residual voltage 1 V or less External input 1Input time 2 ms (ON)/20 ms (OFF) or more (25 ms or more (ON/OFF) when external calibration is selected.) Light source Red, 4-element LED APC ON/OFF switchable (Factory setting: OFF) Response time 50 µs (HIGH SPEED) /250 µs (FINE) /500 µs (TURBO) /1 ms (SUPER) /4 ms (ULTRA) /16 ms (MEGA) Number of interference prevention units 0 for HIGH SPEED; 4 for FINE; 8 for TURBO/SUPER/ULTRA/MEGA(When set to double, the number of interference-prevention units will be doubled.) Unit expansion Up to 16 units can be connected total (two output type is treated as two units) Rating Power voltage 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less Current Consumption Normal: 950 mW or less (39 mA max. at 24 V, 52 mA max. at 12 V)*2Eco on mode: 850 mW or less (35 mA max. at 24 V, 44 mA max. at 12 V)*2Eco Full mode: 520 mW or less (21 mA max. at 24 V, 26 mA max. at 12 V) Environmental resistance Ambient light Incandescent lamp: 20,000 lux or less, Sunlight: 30,000 lux or less Ambient temperature -20 to +55 °C (No freezing)*3 Relative humidity 35 to 85 % RH (No condensation) Vibration resistance 10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z directions Shock resistance 500 m/s2, 3 times in each of the X, Y, and Z directions Case material Both main unit and expansion unit housing material: Polycarbonate Weight Approx. 22 g

Read more less

Specifications Model PZ-G61P Type Retro-reflective *1Long-range(with P.R.O.function) Shape Rectangular Output PNP Cable connection Cable (2 m) *2 Detecting distance 0.1 to 4.2 m(When R-2Lreflectoris used) Spot diameter ― Light source Red LED Sensitivity adjustment 1-turn trimmer (230°) Response time 500 µs Operation mode LIGHT-ON/DARK-ON (switch-selectable) Indicators (LED) Output： Orange LED,Stable operation： Green LED Control output Open collector output, 30 V max., 100 mA max., Residual voltage： 1 V max. Protection circuit Reversed polarity, overcurrent protection, surge absorber Interference suppression Up to 2 units(with the automatic different frequency function) Tightening torque Rectangular models (Mounting hole part): 0.5 N m max. Rating Power voltage 10 to 30 VDC, including Ripple (P-P) 10 % Current consumption 34 mA or less Environmental resistance Enclosure rating IEC: IP67/NEMA: 4A, 6, 12/DIN: IP69K Ambient light Incandescent lamp: 5,000 lux max., Sunlight: 20,000 lux max. Ambient temperature -20 to +55 °C (No freezing) Relative humidity 35 to 85 % RH (No condensation) Vibration resistance 10 to 55 Hz, Double amplitude 1.5 mm, 2 hours in each of the X, Y, and Z directions Shock resistance 1,000 m/s2, 6 times in each of the X, Y, and Z directions Material Housing, M18 nut(threaded models only) Glass-fibre reinforced PBT Lens cover Acrylic(PMMA) Trimmer Glass-fibre reinforced polyamide (PA) Case connection Screw: Nickel-plated iron and zinc, packing: nitrile butadiene rubber (NBR) Cable (cable models only) Polyvinyl chloride (PVC) Connector (connector type with cable only) ― Accessories Instruction manual Weight Rectangular cable models: Approx. 60 g (Thrubeam-models transmitter: Approx. 50 g)

Read more less

Specifications Model FU-83C*1 Heat resistant temperature 300°C*2 Fibre unit length 1 m cannot be cut Minimum bend radius R25 mm Minimum detectable object Gold wire with a diameter of 0.005 mm *3 Environmental resistance Ambient temperature -40 to +300 °C Weight Approx. 23 g

Read more less

Specifications Model FU-10 Type Variable spot Focal distance 10 to 30 mm Fibre unit length 2 m free-cut Fibre unit diameter ø1.3×2 Environmental resistance Ambient temperature -40 to +70 °C Weight Approx. 5 g

Read more less

Item specifics Condition New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. See all condition definitionsopens in a new window or tab Brand Keyence MPN Does not apply Manufacturer Part Number Does not apply Type Fiber Optic Sensor Model FU-20 UPC Does not apply

Read more less

Specifications Model FU-4FZ*1 Size ø3 mm Fibre unit length 2 m free-cut Fibre unit diameter ø1.3×2 Minimum bend radius R2 mm Tough-Flex Minimum detectable object Gold wire with a diameter of 0.005 mm *2 Environmental resistance Ambient temperature -40 to +50 °C Weight Approx. 8 g

Read more less

Item specifics Condition New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. See all condition definitionsopens in a new window or tab UPC Does not apply MPN PK3-T5N Model PK3-T5N Brand None Type sensor Country of Origin China

Read more less

Part Number PN3097 Brand IFM Availability In Stock

Read more less

Product Attributes Type Description Select All Category Sensors, Transducers Float, Level Sensors Manufacturer ifm efector, inc. Series - Packaging Box Part Status Active Type Liquid, Temperature Output Type Digital Output Configuration PNP/NPN-NC/NO Current 200 mA Switch Actuation Level - Mounting Type Bracket Mount Material - Housing & Prism Stainless Steel Operating Temperature 0°C ~ 60°C Voltage Rating 18V ~ 30V

Read more less

Measurement of flow and temperature at the same time Optimised for water, oils and air Red/green display for clear identification of the acceptable range With switching output, analogue signal and IO-Link The process connection can be rotated for optimum alignment

Read more less

Two switching outputs, one of them programmable as analogue output Clearly visible 4-digit LED display Country-specific pressure units selectable With long-term stability thanks to high overload protection Selectable output polarity

Read more less
