Suitable Media Liquid Brand IFM Pressure Range 75 Bar Accuracy 100% Interface I/O Link Housing Material Stainless Steel Operating Temperature -40 to 105 Deg C IP Protection Class IP67 Model No. PN2294 Weight 223.5 g Availability In Stock Two switching outputs, one of them programmable as IO-Link and one as analogue output Red/green display for clear identification of the acceptable range The process connection can be rotated for optimum alignment With long-term stability thanks to high overload protection Robust design for use in harsh industrial environments

Read more less

Suitable Media Liquid Brand IFM Pressure Range 75 Bar Accuracy 100% Interface I/O Link Housing Material Stainless Steel Operating Temperature -40 to 105 Deg C IP Protection Class IP67 Model No. PN2294 Weight 223.5 g Availability In Stock Two switching outputs, one of them programmable as IO-Link and one as analogue output Red/green display for clear identification of the acceptable range The process connection can be rotated for optimum alignment With long-term stability thanks to high overload protection Robust design for use in harsh industrial environments

Read more less

Product Specifications Product Attribute Attribute Value Alternate Mfr Part Number PN-1-1BREN14-MFRKG/US/ /V Brand IFM EFECTOR Display Digital Manufacturer Part Number PN2299 Measurement Range -1 to 1 bar Measurement Units bar Numeric ID 3882615 Operating Voltage 18 to 30 VDC Process Connection 1/4" NPT Internal Series PN Series

Read more less

Product Attributes Type Description Select All Category Industrial Automation and Controls Industrial Sensors Flow Sensors - Industrial Manufacturer ifm efector, inc. Series - Packaging Box Part Status Active Sensing Range 15 cm/s Flow Sensor Type Liquid Voltage - Input - Port Size Female, 1/2", 0.5" (12.7mm) NPT Switch Function/Rating Logic Material - Body Steel Operating Temperature -20°C ~ 70°C

Read more less

Number of inputs and outputs Number of digital outputs: 2 Measuring range -100...600 °C -148...1112 °F Communication interface IO-Link Process connection threaded connection G 1/2 external thread Application Special feature Gold-plated contacts Application for Pt100 and Pt1000 measuring elements Electrical data Operating voltage[V] 18...32 DC; ("supply class 2" to cULus) Current consumption[mA] < 50 Protection class III Reverse polarity protection yes Power-on delay time[s] 1 Integrated watchdog yes Inputs / outputs Number of inputs and outputs Number of digital outputs: 2 Outputs Total number of outputs 2 Output signal switching signal; IO-Link; (configurable) Electrical design PNP/NPN Number of digital outputs 2 Output function normally open / normally closed; (parameterisable) Max. voltage drop switching output DC[V] 2.5 Permanent current rating of switching output DC[mA] 250 Short-circuit protection yes Type of short-circuit protection pulsed Overload protection yes Measuring/setting range Measuring range -100...600 °C -148...1112 °F Set point SP -99.8...600 °C -147.6...1112 °F Reset point rP -100...599.8 °C -148...1111.6 °F In steps of 0.1 °C 0.1 °F Resolution Resolution of switching output[K] 0.1 Resolution of display[K] 0.1

Read more less

Reliable monitoring of liquids and gases in pipes Variable process connection using adapters Easy setting of the switch points for quick set-up Robust stainless steel housing for use in harsh industrial environments LED bar graph for indication of switch point and flow

Read more less

Product Attributes Type Description Select All Category Industrial Automation and Controls Industrial Sensors Proximity Sensors - Industrial Manufacturer ifm efector, inc. Series - Packaging Box Part Status Active Sensor Type Inductive Sensing Distance 0.157" (4mm) Output Type NPN/PNP-NO Response Frequency - Shielding Unshielded Material - Body Polybutylene Terephthalate (PBT) Voltage - Supply 10V ~ 36V Termination Style Connector Operating Temperature -25°C ~ 80°C Ingress Protection IP67 Indicator LED Package / Case Module

Read more less

Reliable detection of tiny objects Particularly compact housing for use in robotics, assembly and handling technology Precise background suppression Simple alignment due to visible laser light spot Intuitive setting of sensitivity and output function

Read more less

Descriptions of ifm Electronic OJ5058 provided by its distributors. DIFFUSE REFLECTIVE SENSOR, 150MM RANGE, 4WIRE DC PNP, LO/DO, PICO QD RS (Formerly Allied Electronics) IFM efector 200 OJHLFPKG/SO/AS - OJ5058 Omnical DIFFUSE REFLECTIVE SENSOR, 150MM DigiKey

Read more less

Hygienic and robust design Particularly space-saving design Safe sealing in the process Adapters for all standard process connections

Read more less

Pressure Switch Type Differential Pressure Switch No. of Ports 4 Ports Contact Material Silver Cable Length 2 m IP Rating IP67 Weight 63 Frequency 170 Hz Minimum Order Quantity 1 Enclosure Protection IP67 Model No. PV7003 Brand IFM Switch Type Pressure Switch Voltage 10 .... 30 V Availability In Stock Compact housing for use where space is restricted Very high overpressure and vacuum resistance Robust stainless steel housing with high shock and vibration resistance Lifespan of more than 60 million pressure cycles Two programmable switching outputs, one of them with IO-Link communication interface
