PLC, FX3U Analog input module; 16 bit; 4 analog inputs for current or voltage FA-COM PLC: Analogue I/O Module Series MELSEC-F SERIES Type FX3U Power Supply (V) 24 Current Type DC Occupied I/O Points on PLC 8 Integrated Analogue Inputs 4 Input Voltage Range (V) -10-10 Input Current Range (mA) -20-20;4-20 Min. Ambient Temperature (°C) 0 Max. Ambient Temperature (°C) 55 Product Dimensions & Weight Depth (mm) 87 Weight (kg) 0,2 Width (mm) 55 Height (mm) 90 Conformity CE COMPLIANT EAC NON-COMPLIANT UL/cUL COMPLIANT UKCA COMPLIANT

Read more less

PLC, FX3U Base Unit AC 100-240 V: 64 inputs DC 24 V; 64 transistor outputs;sink FA-COM PLC: Main Unit Type FX3U Power Supply (V) 100-240 Current Type AC Program Memory 64K STEPS Program Memory Unit RAM Integrated Digital Inputs 64 Integrated Digital Outputs 64 Output Type TRANSISTOR Output Logic SINK Local I/O Points 256 Local + Remote I/O Points 384 Expandable YES Cycle Time LD (ns) 65 Cycle Time MOV (ns) 642 RS-422 1 Power Consumption (W) 65 Buffer Battery YES Protection Class IP10 Min. Ambient Temperature (°C) 0 Max. Ambient Temperature (°C) 55 Series MELSEC-F SERIES Product Dimensions & Weight Depth (mm) 86 Weight (kg) 1,467 Width (mm) 350 Height (mm) 90 Conformity CE COMPLIANT Shipping Approvals ABS,BV,DNV GL,KR,LR,NK,RINA EAC NON-COMPLIANT UKCA COMPLIANT

Read more less

PLC, FX3U Base Unit AC 100-240 V: 64 inputs DC 24 V; 64 relay outputs FA-COM PLC: Main Unit Type FX3U Power Supply (V) 100-240 Current Type AC Program Memory 64K STEPS Program Memory Unit RAM Integrated Digital Inputs 64 Integrated Digital Outputs 64 Output Type RELAY Local I/O Points 256 Local + Remote I/O Points 384 Expandable YES Cycle Time LD (ns) 65 Cycle Time MOV (ns) 642 USB OPTION RS-422 1 Power Consumption (W) 65 Buffer Battery YES Protection Class IP10 Min. Ambient Temperature (°C) 0 Max. Ambient Temperature (°C) 55 Series MELSEC-F SERIES Product Dimensions & Weight Depth (mm) 86 Weight (kg) 1,8 Width (mm) 350 Height (mm) 90 Conformity CE COMPLIANT Shipping Approvals ABS,BV,DNV GL,KR,LR,NK,RINA EAC NON-COMPLIANT UL/cUL COMPLIANT UKCA COMPLIANT

Read more less

PLC Q Series iQ CPU module;4096 EA;1.9 ns/log. Com.;60k steps;Ethernet;USB;SD FA-MOD PLC: CPU Module Series MELSEC-Q SERIES Type UNIVERSAL MODEL QCPU Program Memory 60K Program Memory Unit STEPS Local I/O Points 4.096 Local + Remote I/O Points 8.192 Cycle Time LD (ns) 1,9 Cycle Time MOV (ns) 3,9 USB 1 Ethernet Port 1 Buffer Battery YES Int. Current Consumption (A) 0,58 Product Dimensions & Weight Depth (mm) 115 Weight (kg) 0,2 Width (mm) 27,4 Height (mm) 98 Conformity CE COMPLIANT Shipping Approvals ABS,BV,DNV GL,LR,NK,RINA EAC NON-COMPLIANT UL/cUL COMPLIANT UKCA COMPLIANT

Read more less

PLC Q Series iQ CPU module; 4096 I/O; 9,5 ns/com.; 60k steps; Ethernet int. FA-MOD PLC: CPU Module Series MELSEC-Q SERIES Type UNIVERSAL MODEL QCPU Program Memory 60K Program Memory Unit STEPS Local I/O Points 4.096 Local + Remote I/O Points 8.192 Cycle Time LD (ns) 9,5 Cycle Time MOV (ns) 19 USB 1 Ethernet Port 1 Buffer Battery YES Int. Current Consumption (A) 0,39 Product Dimensions & Weight Depth (mm) 89,3 Weight (kg) 0,22 Width (mm) 27,4 Height (mm) 98 Conformity CE COMPLIANT Shipping Approvals ABS,BV,DNV GL,LR,NK,RINA EAC NON-COMPLIANT UL/cUL COMPLIANT UKCA COMPLIANT

Read more less

  Model name Q06HCPU Overview Number of I/O points: 4096, number of I/O device points: 8192, program capacity: 60K steps, basic operation processing speed (LD X0): 34 ns, program memory capacity: 240K bytes, external interface: USB/RS-232, with memory card interface Conformance standard UL cUL CE(EMC) CE(RoHS) KC(EMC) LR NK DNV ABS RINA BV Sales status Discontinued Discontinued date 2018/09 *Please check or inquire it in each overseas sales company site because the sale situation is different depending on each countries. Replacement models Q06UDVCPU Learn more about our products

Read more less

PLC Q Series iQ CPU module; 1024 I/O; 60 ns/com.; 15k steps FA-MOD PLC: CPU Module Series MELSEC-Q SERIES Type UNIVERSAL MODEL QCPU Program Memory 15K Program Memory Unit STEPS Local I/O Points 1.024 Local + Remote I/O Points 8.192 Cycle Time LD (ns) 60 Cycle Time MOV (ns) 120 USB 1 RS-232 1 Buffer Battery YES Int. Current Consumption (A) 0,33 Product Dimensions & Weight Depth (mm) 89,3 Weight (kg) 0,15 Width (mm) 27,4 Height (mm) 98 Conformity CE COMPLIANT Shipping Approvals ABS,BV,DNV GL,LR,NK,RINA EAC NON-COMPLIANT UL/cUL COMPLIANT UKCA COMPLIANT

Read more less

PLC, FX3U Base Unit AC 100-240 V; 40 inputs DC 24 V; 40 transistor outputs; sink FA-COM PLC: Main Unit Type FX3U Power Supply (V) 100-240 Current Type AC Program Memory 64K STEPS Program Memory Unit RAM Integrated Digital Inputs 40 Integrated Digital Outputs 40 Output Type TRANSISTOR Output Logic SINK Local I/O Points 256 Local + Remote I/O Points 384 Expandable YES Cycle Time LD (ns) 65 Cycle Time MOV (ns) 642 RS-422 1 Power Consumption (W) 50 Buffer Battery YES Protection Class IP10 Min. Ambient Temperature (°C) 0 Max. Ambient Temperature (°C) 55 Series MELSEC-F SERIES Product Dimensions & Weight Depth (mm) 86 Weight (kg) 1,2 Width (mm) 285 Height (mm) 90 Conformity CE COMPLIANT Shipping Approvals ABS,BV,DNV GL,KR,LR,NK,RINA EAC NON-COMPLIANT UKCA COMPLIANT

Read more less

PLC, FX3U Base Unit AC 100-240 V; 40 inputs DC 24 V; 40 relay outputs FA-COM PLC: Main Unit Type FX3U Power Supply (V) 100-240 Current Type AC Program Memory 64K STEPS Program Memory Unit RAM Integrated Digital Inputs 40 Integrated Digital Outputs 40 Output Type RELAY Local I/O Points 256 Local + Remote I/O Points 384 Expandable YES Cycle Time LD (ns) 65 Cycle Time MOV (ns) 642 USB OPTION RS-422 1 Power Consumption (W) 50 Buffer Battery YES Protection Class IP10 Min. Ambient Temperature (°C) 0 Max. Ambient Temperature (°C) 55 Series MELSEC-F SERIES Product Dimensions & Weight Depth (mm) 86 Weight (kg) 1,2 Width (mm) 285 Height (mm) 90 Conformity CE COMPLIANT Shipping Approvals ABS,BV,DNV GL,KR,LR,NK,RINA EAC NON-COMPLIANT UL/cUL COMPLIANT UKCA COMPLIANT

Read more less

PLC, FX3U Base Unit AC 100-240 V; 40 inputs DC 24 V; 40 transistor outputs; sink FA-COM PLC: Main Unit Type FX3U Power Supply (V) 100-240 Current Type AC Program Memory 64K STEPS Program Memory Unit RAM Integrated Digital Inputs 40 Integrated Digital Outputs 40 Output Type TRANSISTOR Output Logic SINK Local I/O Points 256 Local + Remote I/O Points 384 Expandable YES Cycle Time LD (ns) 65 Cycle Time MOV (ns) 642 RS-422 1 Power Consumption (W) 50 Buffer Battery YES Protection Class IP10 Min. Ambient Temperature (°C) 0 Max. Ambient Temperature (°C) 55 Series MELSEC-F SERIES Product Dimensions & Weight Depth (mm) 86 Weight (kg) 1,2 Width (mm) 285 Height (mm) 90 Conformity CE COMPLIANT Shipping Approvals ABS,BV,DNV GL,KR,LR,NK,RINA EAC NON-COMPLIANT UKCA COMPLIANT

Read more less

PLC, FX3U Base Unit AC 100-240 V; 40 inputs DC 24 V; 40 relay outputs FA-COM PLC: Main Unit Type FX3U Power Supply (V) 100-240 Current Type AC Program Memory 64K STEPS Program Memory Unit RAM Integrated Digital Inputs 40 Integrated Digital Outputs 40 Output Type RELAY Local I/O Points 256 Local + Remote I/O Points 384 Expandable YES Cycle Time LD (ns) 65 Cycle Time MOV (ns) 642 USB OPTION RS-422 1 Power Consumption (W) 50 Buffer Battery YES Protection Class IP10 Min. Ambient Temperature (°C) 0 Max. Ambient Temperature (°C) 55 Series MELSEC-F SERIES Product Dimensions & Weight Depth (mm) 86 Weight (kg) 1,2 Width (mm) 285 Height (mm) 90 Conformity CE COMPLIANT Shipping Approvals ABS,BV,DNV GL,KR,LR,NK,RINA EAC NON-COMPLIANT UL/cUL COMPLIANT UKCA COMPLIANT

Read more less

PLC, FX3U Base Unit AC 100-240 V; 32 inputs DC 24 V; 32 transistor outputs; sink FA-COM PLC: Main Unit Type FX3U Power Supply (V) 100-240 Current Type AC Program Memory 64K STEPS Program Memory Unit RAM Integrated Digital Inputs 32 Integrated Digital Outputs 32 Output Type TRANSISTOR Output Logic SINK Local I/O Points 256 Local + Remote I/O Points 384 Expandable YES Cycle Time LD (ns) 65 Cycle Time MOV (ns) 642 RS-422 1 Power Consumption (W) 45 Buffer Battery YES Protection Class IP10 Min. Ambient Temperature (°C) 0 Max. Ambient Temperature (°C) 55 Series MELSEC-F SERIES Product Dimensions & Weight Depth (mm) 86 Weight (kg) 1 Width (mm) 220 Height (mm) 90 Conformity CE COMPLIANT Shipping Approvals ABS,BV,DNV GL,KR,LR,NK,RINA EAC NON-COMPLIANT UKCA COMPLIANT

Read more less
