DELIVERY PERIOD : 1-2 WEEKS  Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Proximity Sensors RoHS:  Details Sensing Method: Inductive Sensing Distance: 3 mm Mounting Style: Panel Output Configuration: NO Brand: Omron Automation and Safety Description/Function: NO Maximum Operating Temperature: + 70 C Minimum Operating Temperature: - 25 C Operating Supply Voltage: 24 V Series: E2E  Factory Pack Quantity: 1 Subcategory: Sensors Part # Aliases: E2EX3D1R2MQ E2EX3D1R2M Unit Weight: 70 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Specifications Mounting method With plug-in socket Usage General purpose, Interface Poles 1 Coil voltage 24 V Rated carry current 10 A Operation voltage DC Contact material AgSnIn Contact description SPDT Features Diode, LED, Transparent case, With mechanical indicator Terminal type Plug-in

Read more less

DELIVERY PERIOD : 1-2 WEEKS  [Features]· A waterproof connector for use with FA - designed for saving man- and maintenance-hours, and environment resistance.▪ Conforms to IP67.· An FA dedicated small connector providing 94V-0 heat resistance.· Changing the wiring system to connectors makes maintenance easy and shortens the equipment downtime.·The connectors with cables are available in three types: crimp type, solder type, and screw connection type.· The connector with cable is a UL standard compatible part.• Compliant with IEC61076-2-101 (IEC60947-5-2), NECA4202. Product Specification  Part Numbers  Catalog  Classification Name Type Assembly Type Connector(Crimp Type, Solder Type, Screw Connection Type)Used for attaching a connector to sensor and relay cables. Model XS2G Plug Model XS2C Socket Connector for Relay BoxUsed for attaching a connector to a relay box. Model XS2P Socket T-Shaped Joint, Y-Shaped Jointused for branch wiring and daisy chain connections etc. Shape XS2R plug/socket T-Shaped Joint Y-Shaped Joint Connector for Sensor EmbeddingUsed for embedding a connector into the sensor unit. Model XS2M plug Embedded type with screw Embedded type without screw Connector for Panel MountingMounts to a panel, enabling connections to an I/O box. Model XS2M plug Flange Mounted Type Screw Mounted Type Structure Structural diagram Rating/Performance Rated Current 3A Rated Voltage For DC: 125 V DC, For AC: 250 V AC Contact Resistance (Connector Part) 40 mΩ or Less(with 20 mV or Less, 100 mA or Less) Insulation Resistance 103 MΩ or More (at 500 V DC) Withstand Voltage (Connector Part) 1,500 V AC 1 min (Leak Current 1 mA or Less) Protective Structure IP67 (IEC529) Insertion/Removal Tolerance 200 times Assembled Fixture Strength Tensile: 98 N/15 s, Torsion: 0.98 N·m/15 s Cable Holding Strength Cable Outer Diameter:ø6 mm 98 N/15 sø4 to ø5 mm 49 N/15 sø3 mm 29 N/15 s Operating Temperature Range -25 to +70°C Operating Humidity Range 20 to 85% RH Assembly Type Connector Compatible Cable Compatible Cable Outer Diameter(mm) Core Conductor Size Crimp Type Solder Type Screw Connection Type For ø8 ø7 to ø8 - - 0.18 to 0.75 mm2 For ø7 ø6 to ø7 For ø6 ø5 to 6 0.18 to 0.3 mm20.5 to 0.75 mm22 types of contact available. 0.5 mm2or Less For ø4 ø4 to ø5 For ø3 ø3 to ø4 Materials/Processing Item Type Model XS2F/H/W Model XS2M/R/P Model XS2C/G Contact Material Phosphor bronze Brass Finish Ni-base 0.4 μm gold plating Anchoring Tool Material Brass * Finish Ni-Plating * ContactBlock Material PBT Resin(UL94V-0) PA Resin(UL94V-0) PBT Resin(UL94V-0) Color For DC: Light Gray, For AC: Dark Gray O-Ring Rubber Cover Soft PBT(UL94V-0) - PBT Resin(UL94V-0) Cap - - PBT Resin(UL94V-0) Cable Clamp - - PA Resin(UL94V-0) Contact Clamp - - PBT Resin(UL94V-0) Lock Spring - - LCP Resin(UL94V-0) Waterproof Bushing - - Rubber Ring - - Steel *Model XS2R: The T-shaped joint is aluminum and white. Mating Part Type

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Power Supply Voltage 24 V Channel 2 Brand Omron Type Optical Fiber Amplifier Color Black Light Source Infrared LED Power 230 V Model Name/Number E3X-HD11 2M Shape Cuboid, rail mounting Sensing method Amplifier Cable length 2m Output type NPN Operation mode Dark-ON, Light-ON Response time 0.05 ms Material housing Polycarbonate

Read more less

DELIVERY PERIOD : 1-2 WEEKS Photomicrosensor, Slot type, Through-beam, L-shaped, Sensing distance: 5 mm (slot width), Dark-ON/Light-ON (selectable), Indicator: Incident light, NPN output, Connector model Type Grooved Type (L-shaped) Luminous method Non-modulated Sensing method Through-beam type Sensing distance Slot width: 5 mm Control output (Output type) NPN open collector output Operation mode Dark-ON/Light-ON (selectable) Connection method Connector type

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Cameras & Camera Modules RoHS:  Details Product Type: Photoelectric Sensors Brand: Omron Automation and Safety Factory Pack Quantity: 1 Subcategory: Cameras & Accessories Part # Aliases: FZS2M Unit Weight: 76.200 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Specifications Shape L-shaped Sensing method Through-beam with slot Sensing distance 5 mm Setting method Fixed Connection method System connector Output type NPN Operation mode Dark-ON, Light-ON Response time 0.17 ms Material housing PBT Thread size Other Product Width (unpacked) 26.2 mm Product Height (unpacked) 15.5 mm Product Depth (unpacked) 14.7 mm Type of light Infrared light Supply voltage DC 5-24 V Accessories EE-1017 1M Accessory photomicro sensor EE-SX97 series, cable connector, 1 m

Read more less

DELIVERY PERIOD : 1-2 WEEKS Photomicrosensor, Slot type, Through-beam, Standard, Sensing distance: 5 mm (slot width), Light-ON/Dark-ON (2 outputs), Indicator: Incident light, NPN output, Connector model Type Grooved Type (Close-mounting) Luminous method Non-modulated Sensing method Through-beam type Sensing distance Slot width: 5 mm Control output (Output type) NPN open collector output Operation mode With both Dark-ON and Light-ON (2 outputs) Connection method Connector type

Read more less

DELIVERY PERIOD : 1-2 WEEKS The EE-SX672 is a slot-type Photomicrosensor with connector or pre-wired model (non-modulated). Easy operation monitoring with bright light indicator. Flexible robot cable is provided as a standard feature. Infrared LED with a peak wavelength of 940nm light source. T-shaped output Connector type connection method Applications Sensing & Instrumentation Technical Specifications Find similar products Sensing Method Through Beam Sensing Distance / Slot Width 5mm Supply Voltage DC Min 5V Supply Voltage DC Max 24V Output Current 100mA Collector Current IC Max 100mA IP Rating - Operating Temperature Min -25°C Product Range EE-SX67 Series Find similar products Sensing Range Max 5mm Supply Voltage Min 5VDC Supply Voltage Max 24VDC Sensor Case / Package Module Collector Emitter Voltage Max - Sensor Output Type NPN Sensor Mounting Solder Operating Temperature Max 55°C Qualification -

Read more less

DELIVERY PERIOD : 1-2 WEEKS Physical Body MaterialBrass Technical Current Rating15 mA Max Operating Temperature70 °C Max Supply Voltage30 V Min Operating Temperature-25 °C Min Supply Voltage10 V Response Frequency70 Hz Sensing Distance5 mm Sensing MethodInductive ShieldingShielded TerminationCable Leads Dimensions Height60 mm Length18 mm

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Safety Relays RoHS:  Details Coil Voltage: 24 VDC Relay Contact Form: 4 Form A (4PST-NO), 2 Form A (DPST-NO) Contact Termination: Solder Pin Contact Rating: 10 A Brand: Omron Automation and Safety Coil Resistance: 800 Ohms Contact Form: 4PST (4 Form A), DPST (2 Form A) Current Rating - Max: 10 A Product: Safety Relays Product Type: Safety Relays Series: G7S  Factory Pack Quantity: 1 Subcategory: Relays Part # Aliases: G7S-4A2B-E DC24 644196 G7S4A2BEDC24 Unit Weight: 65 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Safety Relays RoHS:  Details Coil Voltage: 24 VDC Relay Contact Form: 2 Form A (DPST-NO) Contact Termination: Solder Pin Contact Rating: 6 A Brand: Omron Automation and Safety Coil Resistance: 1.6 kOhms Contact Form: DPST (2 Form A) Current Rating - Max: 6 A Product: Safety Relays Product Type: Safety Relays Factory Pack Quantity: 1 Subcategory: Relays Part # Aliases: 376123 G7SA2A2B24DC 1221753 G7SA2A2BDC24 Unit Weight: 22 g

Read more less
