Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: General Purpose Relays RoHS:   Product: Power Relays Type: Low Profile Coil Voltage: 24 VDC Relay Contact Form: 1 Form C (SPDT-NO, NC) Contact Current Rating: 12 A Contact Termination: Solder Pin Mounting Style: Through Hole Switching Voltage: 440 VAC, 300 VDC Coil Termination: Solder Pin Coil Type: Non-Latching Coil Resistance: 1.44 kOhms Coil Current: 16.7 mA Contact Material: Silver Alloy (Ag) Series: G2RL Length: 29 mm Width: 12.7 mm Height: 15.7 mm Brand: Omron Electronics Contact Form: SPDT (1 Form C) Power Consumption: 400 mW Product Type: General Purpose Relays 100 Subcategory: Relays Part # Aliases: G2RL1DC24NC G2RL-1-DC24-BY-OMB G2RL1DC24 G2RL-1DC24 G2RL1DC24BYOMB Unit Weight: 17

Read more less

Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Proximity Sensors - Industrial RoHS: N Technology: Inductive Measuring Range - Max: 2 mm Output Type: NPN Mounting Style: Cable Mount Connection Method: Pre-Cable Cable Length: 2 m Supply Voltage - Min: 10 VDC Supply Voltage - Max: 30 VDC Series: E2B Brand: Omron Automation and Safety Housing Material: Stainless Steel IP Rating: IP67 Maximum Frequency: 1.5 kHz Maximum Operating Temperature: + 70 C Minimum Operating Temperature: - 25 C Packaging: Bulk Product Type: Proximity Sensor 1 Subcategory: Sensors Part # Aliases: E2BS08KS02WPC12M Unit Weight: 65 g

Read more less

specifications description Type of Product Safety Relay Unit Model No G9SB-2002-A AC/DC24 Operation Ambient Temperature -25 to +55℃ (no icing) Monotaro ID 39071155 Mechanical Durability 5 million times or more (opening and closing frequency 7200 times / h) Response Time 10 ms or less Input Auto reset / inverse input Insulation Resistance 100 MΩ or more (DC500V mega) Country of Origin CHINA Tightening Strength (Terminal) 0.5 Nm Ambient Humidity to Use 35～85%RH Electrical Durability 100,000 times or more (rated load, switching frequency 1800 times / h) Contact Configuration (Safety output) 2a contact Function emergency stop Input Channel 2ch input Type of Resetting Auto reset / inverse input

Read more less

Brand Omron Model Name/Number G2R-2-SN DC24(S) Usage/Application Relay Modules Number Of Poles 2 Pole Voltage Type DC Type Industrial Relay Relay Type General Purpose Relays Country of Origin Made in India Availability In Stock Omron G2R-2-SN-24VDC  Relay, 8PIN    Model No.: G2R-2-SN DC24(S) plug-in, 8-pin, DPDT, 5 A, mech & LED indicators, label facility, 24 VD

Read more less

Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Safety Relays RoHS:   Coil Voltage: 24 VDC Relay Contact Form: 3 Form A (3PST-NO), 3 Form A (3PST-NO) Contact Termination: Solder Pin Contact Rating: 10 A Brand: Omron Automation and Safety Coil Resistance: 800 Ohms Contact Form: 3PST (3 Form A), 3PST (3 Form A) Current Rating - Max: 10 A Product: Safety Relays Product Type: Safety Relays Series: G7S 1 Subcategory: Relays Part # Aliases: 644195 G7S3A3BEDC24 Unit Weight: 65 g

Read more less

- High-quality safety relay for reliable performance. - Compatible with CHR4-S-3A1B24D4F24V connection system. - 10-pin design for easy installation and connection. - Rated for 24V voltage. - Provides effective protection against electrical hazards.

Read more less

Safety relay, DPST-NO, DPST-NC, 24 VDC Coil ratings 24 VDC 15 mA Contact form DPST-NO/DPST-NC Contact material Au plating＋Ag alloy Contact rated load 250 VAC 6 A (Resistive load)30 VDC 6 A (Resistive load) Terminal structure PCB terminal

Read more less

Specifications Type Totalising Size 1/32 DIN (48 x 24 mm) Counting functions Total count Counting range 0 - 99999999 LCD backlight Without backlight Number of digits 8 Body color Light grey Installation type On-panel Terminal type Screw Inputs DC voltage Supply voltage DC 4.5-30 V Speed 1000 Hz Product Width (unpacked) 48 mm Product Height (unpacked) 24 mm Product Depth (unpacked) 48.5 mm Relay output 0

Read more less

Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Relay Sockets & Fixings RoHS:   Product: Relay Sockets Accessory Type: DIN Rail Mount Associated Relay Series: H3YN Termination Style: Snap On Brand: Omron Automation and Safety Mounting Style: DIN Rail Product Type: Relay Sockets & Hardware 1 Subcategory: Relays Part # Aliases: 1387322 PYF14ANC PYF14AN Unit Weight: 50.585 g

Read more less

Sensing head size M5 Type Cylinder type (with screw), Shielded Power source DC Three-wires models Sensing distance 1.2 mm ±10% Setting distance 0 to 0.84 mm Operation mode NO

Read more less

Specifications Bezel color Black Display Color graphics Enclosure Type Type 1 indoor use only HMI type Dedicated Basic HMI Interaction Touch screen International Standards UL, CSA, CE LED backlight 50Khr white LED Maritime Standards GOST-R, EAC Memory Card Type USB Interaction Touch screen Display Color graphics HMI type Dedicated Basic HMI Display size and type 7-inch TFT Color LCD Resolution 800 x 480 Memory size 128 MB LED backlight 50Khr white LED Web interface Yes RS-232C port 1 built in RS-232C/RS-422A/RS-485 port 1 built in USB host 1 built in USB slave 1 built in Ethernet port 1 built in Printer PictBridge Enclosure Type Type 1 indoor use only International Standards UL, CSA, CE Maritime Standards GOST-R, EAC Memory Card Type USB Mounting orientation Portrait, Landscape Bezel color Black Request Assistance Please fill out the form below to: Talk to a product expert Arrange a product demonstration or consultation Inquire about product training Get a product quote
