DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Safety Relays RoHS: N Coil Voltage: 24 VDC Contact Termination: Screw Contact Rating: 3 A Brand: Omron Automation and Safety Current Rating - Max: 3 A Product Type: Safety Relays Factory Pack Quantity: 1 Subcategory: Relays Switching Voltage: 250 VAC, 125 VDC Width: 35.5 mm Part # Aliases: G9SXAD322T15RTDC24 Unit Weight: 331.128 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Safety Relays RoHS:  Details REACH - SVHC: Details Brand: Omron Automation and Safety Number of Channels: 2 Channel Product Type: Safety Relays Factory Pack Quantity: 1 Subcategory: Relays Part # Aliases: G9SXBC202RTDC24 Unit Weight: 290.304 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Safety Controllers RoHS: N Supply Voltage - Max: 24 VDC Supply Voltage - Min: 24 VDC Mounting Style: DIN Rail Mount Size: 115 mm x 100 mm x 23 mm Series: G9SX NS  Brand: Omron Automation and Safety Display Type: LED Indicator Output Type: PNP Product Type: Safety Controllers Factory Pack Quantity: 1 Subcategory: Controllers Part # Aliases: G9SXNS202RTDC24 Unit Weight: 290.304 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Dimensional Drawing of OMRON Micro Switches Specification Table of OMRON Micro Switches OMRON Micro Switches Ratings/Performance Micro Switches item Micro Switches Model number Micro Switches Model D40A-1C□ Interlock Type Type 4 (EN ISO 14119) Coding Level Low level coded (EN ISO 14119) Operating characteristics*2 Operating distance (OFF→ON) 5mm or more*1 Operating distance (ON→OFF) 15mm or less*1 Hysteresis Less than 20% of the operating distance at +23℃ (max. 2.5mm) Temperature effects Within the temperature range of -10 to +55°C, the operating distance at +23°C is within ±20% Repeatability ±10% or less of operating distance at +23℃ Ambient temperature -10 to +55°C (but no freezing or condensation) Ambient humidity 25 to 85% RH Insulation resistance (between live parts and case) 50MΩ or more (500V DC) Withstand voltage (between live parts and case) AC1,000V for 1 minute Pollution level 3 Electromagnetic compatibility Compliant with IEC/EN60947-5-3 Vibration resistance 10~55~10Hz Single amplitude 0.75mm (Double amplitude 1.5mm) Shock Resistant 300m/s2 ormore Protective structure IP67 Micro Switches Material PBT resin attachment M4 screw Tightening torque 1N・m Power supply voltage DC24V +10%/-15% Power Consumption 0.6W or less Auxiliary output*3 DC24V 10mA (PNP open collector output) LED Indication Actuator not detected (red), actuator detected (yellow) Connection cable 0.15m (connector type), 2m, 5m Number of connections 30 units (maximum wiring length is 100m)*4 mass Switch: approx. 145g, actuator: approx. 20g (for D40A-1C2) *1.When the target marks of the Micro Switches and actuator are on the same axis and the sensing surfaces are aligned, this is the distance at which the switch changes from OFF to ON when approaching (point A on the characteristic data graph)and    the distance at which the Micro Switches changes from ON to OFF when moving away (point B on the characteristic data graph).*2.For response time and operating time, refer to the catalog or manual of the connected safety controller.*3.The Micro Switches turns ON when the actuator approaches. The solid-state relay G3R series is available as a relay that can be driven by the auxiliary output of 10 mA.    For detailed specifications, please check the Micro Switches website (www.fa.omron.co.jp/).*4.For details, refer to "Precautions for Use" on page 35 of the digital catalog. Basic Specifications Operating Temperature Range (℃) -10::55 Protection Structure IP67 Body Material Thermoplastic  Main Body External Dimension, Width W (mm) 25 Main Body External Dimension, Height H (mm) 48 Main Body External Dimension, Length L (mm) 13 Specification of Terminal Screw clamp terminal (M4) Mounting format Screw mounting Details Type Standard Shape

Read more less

DELIVERY PERIOD : 1-2 WEEKS Micro Switches item Micro Switches Model number Micro Switches Model D40A-1C□ Interlock Type Type 4 (EN ISO 14119) Coding Level Low level coded (EN ISO 14119) Operating characteristics*2 Operating distance (OFF→ON) 5mm or more*1 Operating distance (ON→OFF) 15mm or less*1 Hysteresis Less than 20% of the operating distance at +23℃ (max. 2.5mm) Temperature effects Within the temperature range of -10 to +55°C, the operating distance at +23°C is within ±20% Repeatability ±10% or less of operating distance at +23℃ Ambient temperature -10 to +55°C (but no freezing or condensation) Ambient humidity 25 to 85% RH Insulation resistance (between live parts and case) 50MΩ or more (500V DC) Withstand voltage (between live parts and case) AC1,000V for 1 minute Pollution level 3 Electromagnetic compatibility Compliant with IEC/EN60947-5-3 Vibration resistance 10~55~10Hz Single amplitude 0.75mm (Double amplitude 1.5mm) Shock Resistant 300m/s2 ormore Protective structure IP67 Micro Switches Material PBT resin attachment M4 screw Tightening torque 1N・m Power supply voltage DC24V +10%/-15% Power Consumption 0.6W or less Auxiliary output*3 DC24V 10mA (PNP open collector output) LED Indication Actuator not detected (red), actuator detected (yellow) Connection cable 0.15m (connector type), 2m, 5m Number of connections 30 units (maximum wiring length is 100m)*4 mass Switch: approx. 145g, actuator: approx. 20g (for D40A-1C2) *1.When the target marks of the Micro Switches and actuator are on the same axis and the sensing surfaces are aligned, this is the distance at which the switch changes from OFF to ON when approaching (point A on the characteristic data graph)and    the distance at which the Micro Switches changes from ON to OFF when moving away (point B on the characteristic data graph).*2.For response time and operating time, refer to the catalog or manual of the connected safety controller.*3.The Micro Switches turns ON when the actuator approaches. The solid-state relay G3R series is available as a relay that can be driven by the auxiliary output of 10 mA.    For detailed specifications, please check the Micro Switches website (www.fa.omron.co.jp/).*4.For details, refer to "Precautions for Use" on page 35 of the digital catalog. Basic Specifications Operating Temperature Range (℃) -10::55 Protection Structure IP67 Body Material Thermoplastic  Main Body External Dimension, Width W (mm) 25 Main Body External Dimension, Height H (mm) 48 Main Body External Dimension, Length L (mm) 13 Specification of Terminal Screw clamp terminal (M4) Mounting format Screw mounting Details Type Standard Shape

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Proximity Sensors RoHS:  Details REACH - SVHC: Details Sensing Method: Inductive Sensing Distance: 2 mm Mounting Style: Panel Output Configuration: NPN-NC Brand: Omron Automation and Safety Height: 15 mm Length: 37 mm Maximum Operating Temperature: + 70 C Minimum Operating Temperature: - 25 C Operating Supply Voltage: 30 V Product Type: Proximity Sensors Series: E2E  Factory Pack Quantity: 1 Subcategory: Sensors Width: 15 mm Part # Aliases: E2EX2D2NQ E2EX2D2N Unit Weight: 215.460 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Certification body Standard TÜV Rheinland EN ISO 13849-1EN ISO 13849-2IEC 61508EN 62061EN 61131-2IEC 61326-3-1 UL UL508ISA12.12.01 (excluding the DST1-MRD08SL-1)UL1998IEC 61508-3   Specifications   Model DST1-ID12SL-1 DST1-MD16SL-1 DST1-MRD08SL-1 DST1-XD0808SL-1 Communications power supplyvoltage 11 to 25 VDC supplied via communications connector I/O power supply voltage 20.4 to 26.4 VDC (24 VDC -15%/+10%) Currentconsumption Communicationspower supply 24 VDC, 100 mA 24 VDC, 110 mA 24 VDC, 100 mA 24 VDC, 110 mA I/O power supply* 24 VDC, 70 mA 24 VDC,50 mA (Input)130 mA (Output) 24 VDC,80 mA (Input)130 mA (Output) 24 VDC,50 mA (Input)130 mA (Output) Overvoltage category II Noise immunity Conforms to IEC61131-2. Vibration resistance 10 to 57 Hz: 0.35-mm single amplitude, 57 to 150 Hz: 50 m/s2 Shock resistance 150 m/s2, 11 ms 100 m/s2, 11 ms 150 m/s2, 11 ms Mounting method 35-mm DIN Track Ambient operating temperature -10 to 55°C Ambient operating humidity 10% to 95% (with no condensation) 10% to 85% (withno condensation) 10% to 95% (withno condensation) Ambient storage temperature -40 to 70°C Degree of protection IP20 Weight 420 g 600 g 420 g   * Not including power consumption for external devices. Safety Input Specifications(Common with the DST1 Series)   Input type Sinking inputs (PNP) ON voltage 11 VDC min. OFF voltage 5 VDC max. OFF current 1 mA max. Input current 6 mA   Safety Output Specifications (Semiconductor output)(Common with the DST1-MD16SL-1/XD0808SL-1)   Output type Sourcing outputs (PNP) Rated output current 0.5 A max./output ON residual voltage 1.2 V max. Leakage current 0.1 mA max.   Test Output Specifications(Common with the DST1 Series)   Output type Sourcing outputs (PNP) Rated output current 0.7 A max./output ON residual voltage 1.2 V max. Leakage current 0.1 mA max.   Safety Output Specifications (Relay Output)(DST1-MRD08SL-1)   Applicable relays G7SA-2A2B, EN50205 Class A Failure rate P level *(Reference value) 5 VDC, 1 mA Rated load (resistive) 2 A at 240 VAC, 2 A at 30 VDC Durability Mechanical 5,000,000 operations min. (at 7,200 operations/h) Electrical 100,000 operations min. (at 1,800 operations/h with a resistive load)   * This value is equivalent to 300 operations/minute. CIP Safety on DeviceNet Communications   Safety Slave communications Max. 4 connections (Max. 2 connections for the DST1-XD0808SL-1)   DeviceNet Slave Communications(Common with the DST1 Series)   Standard Slave communications Max. 2 connections

Read more less

DELIVERY PERIOD : 1-2 WEEKS Applicable product family G7SA Mounting method DIN rail/screw Terminal type Screw Product Width (unpacked) 22.5 mm Product Height (unpacked) 90 mm Product Depth (unpacked) 60.5 mm Color Black Hold down clip included Release Lever included Applicable wire Solid, Stranded

Read more less

Safety relay, 3PST-NO, SPST-NC, 24 VDC Coil ratings 24 VDC 15 mA Contact form 3PST-NO/SPST-NC Contact material Au plating＋Ag alloy Contact rated load 250 VAC 6 A (Resistive load)30 VDC 6 A (Resistive load) Terminal structure PCB terminal

Read more less

DELIVERY PERIOD : 1-2 WEEKS Miniature Power Relay, 2-pole, Single contact, Plug-in terminals, Built-in diode for coil surge absorption, with operation indicator, 24 VDC Coil ratings 24 VDC 36.3 mA Operating indicator LED Coil surge killer Diode Contact form DPDT Contact method Single Contact material Ag Contact rated load 220 VAC 5 A (Resistive load)220 VAC 2 A (Inductive load (cosφ = 0.4))24 VDC 5 A (Resistive load)24 VDC 2 A (Inductive load (L/R = 7 ms)) Terminal structure Plug-in terminal

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Automotive Relays RoHS:  Details Series: G6D  Brand: Omron Electronics Product Type: Automotive Relays Factory Pack Quantity: 10 Subcategory: Relays Part # Aliases: G6DF4BDC24 Unit Weight: 113.400 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Relay Sockets & Fixings RoHS:  Details Product: Relay Sockets Associated Relay Series: G7SA Number of Poles: 6 Pole Brand: Omron Automation and Safety Mounting Style: DIN Rail Product Type: Relay Sockets & Hardware Factory Pack Quantity: 1 Subcategory: Relays Part # Aliases: 1421760 381008 P7SA14FNDDC24 Unit Weight: 70 g

Read more less
