Number Of Core 2 Core Usage/Application Electrical Fitting Diameter 4 mm Wire Material Aluminium Packaging Type Roll Insulation Material PVC Roll Length 90 m

Read more less

Main Device application Distribution Range of product Acti9 Range Acti9 Product name XC60 Product or component type Miniature circuit-breaker Device short name xC60 Poles description 3P Number of protected poles 3 [In] rated current 63 A Network type AC Trip unit technology Thermal-magnetic Curve code B Complementary Network frequency 50/60 Hz [Ue] rated operational voltage 220...240 V AC 50/60 Hz380...415 V AC 50/60 Hz Magnetic tripping limit 3...5 x In Breaking capacity 10000 A Icn at 240 V AC 50/60 Hz conforming to IS/IEC 60898-110000 A Icn at 415 V AC 50/60 Hz conforming to IS/IEC 60898-1 Limitation class 3 conforming to IS/IEC 60898-1 Contact position indicator Yes Control type Toggle Local signalling ON/OFF indication mounting mode Clip-on Mounting support 35 mm DIN rail Comb busbar and distribution block compatibility Top: YES 9 mm pitches 6 Height 85 mm Width 54 mm Depth 77.5 mm Product weight 0.31 kg Colour White Mechanical durability 20000 cycles Electrical durability 10000 cycles Connections - terminals Biconnect (bottom)Tunnel type terminals (bottom) 0.33…25 mm² flexibleTunnel type terminals (bottom) 0.5…35 mm² rigid Wire stripping length 13 mm for top or bottom connection Tightening torque 3.5 N.m Earth-leakage protection Separate block Product compatibility C60 auxiliaryC60 accessories Overvoltage category IV Environment Standards IS/IEC 60898-1 IP degree of protection IP20 Pollution degree 3 Tropicalisation 2 conforming to IEC 60068-1 Relative humidity 95 % at 55 °C Ambient air temperature for operation -30…70 °C Ambient air temperature for storage -40…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 8.1 cm Package 1 Width 5.35 cm Package 1 Length 7.4 cm Package 1 Weight 390 g Unit Type of Package 2 BB1 Number of Units in Package 2 4 Package 2 Height 8 cm Package 2 Width 9 cm Package 2 Length 23.8 cm Package 2 Weight 1.622 kg Unit Type of Package 3 CAR Number of Units in Package 3 48 Package 3 Height 27 cm Package 3 Width 30 cm Package 3 Length 35 cm Package 3 Weight 20.064 kg Contractual warranty Warranty (in months) 18

Read more less

Main Range Acti9 Product name Disbo iC60 Product or component type Miniature circuit-breaker Device short name iC60H Poles description 3P Number of protected poles 3 [In] rated current 32 A Network type AC/DC Trip unit technology Thermal-magnetic Curve code C Breaking capacity 42 kA Icu at 12...133 V AC 50/60 Hz conforming to EN/IEC 60947-230 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-215 kA Icu at 380...415 V AC 50/60 Hz conforming to EN/IEC 60947-210 kA Icu at 440 V AC 50/60 Hz conforming to EN/IEC 60947-215 kA Icu at <= 180 V DC conforming to EN/IEC 60947-210000 A Icn at 415 V AC 50/60 Hz conforming to EN/IEC 60898-1 Utilisation category Category A conforming to EN/IEC 60947-2 Complementary Network frequency 50/60 Hz [Ue] rated operational voltage 12...133 V AC 50/60 Hz220...240 V AC 50/60 Hz380...415 V AC 50/60 Hz440 V AC 50/60 Hz<= 180 V DC Magnetic tripping limit 8 x In +/- 20 % [Ics] rated service breaking capacity 21 kA 50 % conforming to EN/IEC 60947-2 - 12...133 V AC 50/60 Hz15 kA 50 % conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz7.5 kA 50 % conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz5 kA 50 % conforming to EN/IEC 60947-2 - 440 V AC 50/60 Hz15 kA 100 % conforming to EN/IEC 60947-2 - <= 180 V DC Limitation class 3 conforming to EN/IEC 60898-1 [Ui] rated insulation voltage 500 V AC 50/60 Hz conforming to EN/IEC 60947-2 [Uimp] rated impulse withstand voltage 6 kV conforming to EN/IEC 60947-2 Contact position indicator Yes Control type Toggle Local signalling Trip indicator mounting mode Clip-on Mounting support Rail 9 mm pitches 6 Height 85 mm Width 54 mm Depth 78.5 mm Product weight 0.375 kg Colour White Mechanical durability 20000 cycles Electrical durability 10000 cycles Provision for padlocking Padlockable Connections - terminals Single terminal (top or bottom) 1…35 mm² rigidSingle terminal (top or bottom) 1…25 mm² flexible Wire stripping length 14 mm for top or bottom connection Tightening torque 3.5 N.m top or bottom Earth-leakage protection Separate block Environment Standards EN/IEC 60947-2EN/IEC 60898-1 IP degree of protection IP20 conforming to IEC 60529 Pollution degree 3 conforming to EN/IEC 60947-2 Overvoltage category IV Tropicalisation 2 conforming to IEC 60068-1 Relative humidity 95 % at 55 °C Ambient air temperature for operation -35…70 °C Ambient air temperature for storage -40…85 °C Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 7.500 cm Package 1 Width 5.400 cm Package 1 Length 9.000 cm Package 1 Weight 359.000 g Unit Type of Package 2 BB1 Number of Units in Package 2 4 Package 2 Height 8.500 cm Package 2 Width 9.800 cm Package 2 Length 22.000 cm Package 2 Weight 1.488 kg Unit Type of Package 3 S03 Number of Units in Package 3 44 Package 3 Height 30.000 cm Package 3 Width 30.000 cm Package 3 Length 40.000 cm Package 3 Weight 16.966 kg Contractual warranty Warranty (in months) 18

Read more less

Overview Product Name TeSys Contactor 3P AC3 32A 230VAC Tax Class GST-18 Coil Voltage 230V AC Number of Poles 3P Short Description Estimated delivery: Timelines may vary based on availability Range of product TESYS DECA Product or component type CONTACTOR Device short name LC1D Contactor application MOTOR CONTROLRESISTIVE LOAD Utilisation category AC-4AC-3AC-1AC-3E

Read more less

Overview Product Name TeSys 32A 3P contactor with 220V AC control Category Contactors Tax Class GST-18 AC3 Current Rating 32A Coil Voltage 220V AC Number of Poles 3P Short Description Estimated delivery: Shipped within 5 to 7 Days Range of product TESYS DECA Product or component type CONTACTOR Device short name LC1D

Read more less

Specifications Brand Kontakt Chemie Product Type Circuit Board Cleaner Sub Type Cleaner Product Form Liquid Trade Name PCC Package Type Aerosol Package Size 200 ml Application Electronic Sporting Equipment, Consumer Electronics Standards/Approvals No Country of Origin Belgium

Read more less

Main ports (4) 4 main ports Series (WE) WE Size (6) 6 Symbols (D) D Component Series (6X) 60 ... 69: unchanged installation and connection dimensions Spring return With spring return Solenoid (E) High-power wet-pin solenoid with detachable coil Electrical voltages (G24) 24V Manual override (N9) With concealed manual override (standard) Corrosion resistance None (valve housing primed) Electrical connection (K4) Standard Spool position monitoring Without position switch Switching time increase Without switching time increase Throttle insert Without throttle insert (standard) Clamping length 42 mm [1.65 inch] (standard) Control spool play Standard (recommended) Seal Material NBR seals Approval Standard Locating hone Without locating hole Power consumption Standard Related products

Read more less

Power Source 2W Number Of Digits 6 digits Mounting Type Panel Voltage 12 VDC Usage Industrial Brand GIC Model SA51A-356 Humidity 45 to 85% (Rh)

Read more less

Product related Article number 3SE5242-0BD03 Life cycle status Active Product Product Family Enclosure width 50 mm EAN 4011209694873 UPC – Commodity Code 85365080 Pricing related Customer Price – List Price – Region Specific Price Group / Headquarter Price Group 41K / 41K Surcharge for raw material – Metal Factor LA------ Delivery related Export Control Regulations AL : N / ECCN : N Standard delivery time 5 Day/Days Packaging dimensions (L x W x H) 67,00 x 43,00 x 118,00 mm Net weight 0,104 Kg Quantity Unit 1 Piece Packaging Quantity 1 Minimum Order Quantity 1 Dangerous goods No Environment related WEEE (2012/19/EU) Take-Back Obligations 5 Compliance with the substance restrictions according to RoHS directive Since: 01.07.2006 REACH Art. 33 Duty to inform according to the current list of candidates Imidazolidine-2-thione (2-imidazoline-2-thiol) CAS-No. 96-45-7 > 0,1 % (w / w) SCIP Number da496a6b-a103-4c8c-a37f-749670939b10 Siemens specific Product Group 5317 Catalog ID CC-IC10 Group Code R711 Country of origin Germany Product class Straightforward, can be reused over the short term Classification eClass Version : 16, Classification : 27-27-06-01 Version : 14, Classification : 27-27-06-01 Version : 12, Classification : 27-27-06-01 Version : 9.1, Classification : 27-27-06-01 Version : 9, Classification : 27-27-06-01 Version : 8, Classification : 27-27-06-01 Version : 7.1, Classification : 27-27-06-01 Version : 6, Classification : 27-27-06-01 ETIM Version : 10, Classification : EC000030 Version : 9, Classification : EC000030 Version : 8, Classification : EC000030 Version : 7, Classification : EC000030 IDEA Version : 4, Classification : 5202 UNSPSC Version : 15, Classification : 39-12-22-13

Read more less

Configured Specifications of ALS-030-R Type Jaw Type Hole diameter d1 - Hole diameter d2 - O.D. 30 Full Length 35 Application Standard / Servo Motor / Stepping Motor / Encoder Allowable Torque Range 10.01~20.00 Features High torsional rigidity / High Torque / High accuracy / High durability / Backlash 0 / Low Inertia Moment / Vibration Absorption / Shaft hole Unfinished Allowable Misalignment Angular Misalignment / Eccentricity / Axial Misalignment Max. Rotational Speed Range 10001~78000 Body Material Aluminum Allowable Torque 12.5 Allowable Angular Misalignment 1 Allowable Lateral Misalignment 0.1 Product Category Coupling body Allowable Lateral Misalignment Range 0.02~0.2 Maximum Rotation Speed 15900 Buffer Material Polyurethane Resin Operating Temperature Range -30～80 Allowable Axial Clearance (±) 0~+1.0 Moment of Inertia 6.25×10-6 Shaft Hole Specifications - Shaft hole finished - Keyway Standard d1, d2: old JIS (2-type) RoHS 10 - -

Read more less

DB25 (25 pin) Male to DB9 (Serial / RS232) Female Cable 1.5 Meter. DB25 (25 Pin) to DB9 (9 Pin / RS232) cable is Ideal for connecting your printers, monitors, modems, scanners, cameras, POS, cash registers, automated industrial control device and transmission of their signals. Support over 1Mbps data transfer rate Connector A : DB 9 (Female), Connector B : DB 25 (Male) Shell : Molded Applications : Connecting printers, monitors, modems, scanners, and cameras, Data Transfer, Scanner, Monitor, Modem, Printer *product image for illustration purposes only. actual product may vary.

Read more less

Brand UNITRONIC® Product type Low-frequency data cable Weight 41 kg/km Copper index 24.000 kg/km copper index (lb) 161.250 lb/10,000 ft
