| Size |
M12 |
| Mounting type |
Shielded |
| Sensing Distance |
3 mm |
| Setting distance |
0 to 2.4 mm |
| Output type |
DC 2-wire |
| Operation mode |
NO |
| Power supply |
12 to 24 VDC, ripple (p-p): 10% max. (10 to 30 VDC) |
| Connection method |
Pre-wired Models(2 m) |
| Cable Specifications |
PVC (oil-resistant) |
| Differential travel |
10% max. of sensing distance |
| Detectable object |
Ferrous metal (The sensing distance decreases with non-ferrous metal.) |
| Standard target |
Iron, 12 × 12 × 1 mm |
| Response frequency |
1 kHz |
| Leakage current |
0.8 mA max. |
| Indicator |
Operation indicator (red) and setting indicator (green) |
| Protection circuit |
Surge suppressor, Load short-circuit protection (for control and diagnostic output) |
| Ambient temperature range |
Operating: −25 to 70°C, Storage: −40 to 85°C (with no icing or condensation) |
| Ambient humidity |
Operating/storage: 35% to 95% (with no condensation) |
| Temperature influence |
±10% max. of sensing distance at 23°C in the temperature range of −25 to 70°C |
| Voltage influence |
±1% max. of sensing distance at rated voltage in the rated voltage ±15% range |
| Insulation resistance |
50 MΩ min. (at 500 VDC) between current-carrying parts and case |
| Dielectric strength |
1000 VAC, 50/60 Hz for 1 minute between current carry parts and case |
| Vibration resistance |
Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
| Shock resistance |
Destruction: 1,000 m/s2 10 times each in X, Y, and Z directions |
| Degree of protection |
IP67 |
