MODEL-INVERTER FR-E840-0060EPB-60(2.2K) MAKE MITSUBISHI FOR I-97

Description

DELIVERY PERIOD : 1-2 WEEKS

Series FR-E800 SERIES
Type FR-E800-ETH INVERTER
Minimum Rated Voltage (V) 380
Min. Permissible Voltage (V) 323
Maximum Rated Voltage (V) 480
Max. Permissible Voltage (V) 528
Current Type AC
Phases 3
Rated Output Current LD (A) 6,9
Rated Output Current ND (A) 6
Rated Motor Capacity LD (kW) 3
Rated Motor Capacity ND (kW) 2,2
Control Method V/F CONTROL
REAL SENSORLESS VECTOR CONTROL
PM SENSORLESS VECTOR CONTROL
MAGNETIC FLUX VECTOR CONTROL
Motor Type INDUCTION MOTOR, PM MOTOR
Brake Chopper ED (%) 100
Integrated EMC Filter NO
Safe Torque Off (STO) YES
Regenerative (4Q) NO
Integrated DC Choke NO
Display BUILT-IN
Display Type 4 DIGITS LED
PLC Function YES
Program Memory 2K
Program Memory Unit STEPS
Integrated Digital Inputs 2
Digital Outputs (Transistor) 0
Digital Outputs (Relay) 1
Integrated Analogue Inputs 2
Integrated Analogue Outputs 0
IO Type of Terminal Block SPRING CLAMP
Expandable YES
RS-485 NO
USB 1 (MINI B)
Ethernet Port 2
Built-In Network MODBUS/TCP
ETHERNET/IP
CC-LINK IE TSN
CC-LINK IE FIELD BASIC
BACNET/IP
Leakage Current (mA) 1,2
Power Loss LD (W) 89
Power Loss ND (W) 76
Standby Power Consumption (W) -
Protection Class IP20
Frequency Range (Hz) 0,2–590

MODEL-INVERTER FR-E840-0060EPB-60(2.2K) MAKE MITSUBISHI FOR I-97

Product form

DELIVERY PERIOD : 1-2 WEEKS Series FR-E800 SERIES   Type FR-E800-ETH INVERTER   Minimum Rated Voltage (V) 380   Min.... Read more

Rs. 5,700.00 Excl. VAT

  • Shipped today? Order within: Jun 15, 2026 17:00:00 -0400

    Description

    DELIVERY PERIOD : 1-2 WEEKS

    Series FR-E800 SERIES
    Type FR-E800-ETH INVERTER
    Minimum Rated Voltage (V) 380
    Min. Permissible Voltage (V) 323
    Maximum Rated Voltage (V) 480
    Max. Permissible Voltage (V) 528
    Current Type AC
    Phases 3
    Rated Output Current LD (A) 6,9
    Rated Output Current ND (A) 6
    Rated Motor Capacity LD (kW) 3
    Rated Motor Capacity ND (kW) 2,2
    Control Method V/F CONTROL
    REAL SENSORLESS VECTOR CONTROL
    PM SENSORLESS VECTOR CONTROL
    MAGNETIC FLUX VECTOR CONTROL
    Motor Type INDUCTION MOTOR, PM MOTOR
    Brake Chopper ED (%) 100
    Integrated EMC Filter NO
    Safe Torque Off (STO) YES
    Regenerative (4Q) NO
    Integrated DC Choke NO
    Display BUILT-IN
    Display Type 4 DIGITS LED
    PLC Function YES
    Program Memory 2K
    Program Memory Unit STEPS
    Integrated Digital Inputs 2
    Digital Outputs (Transistor) 0
    Digital Outputs (Relay) 1
    Integrated Analogue Inputs 2
    Integrated Analogue Outputs 0
    IO Type of Terminal Block SPRING CLAMP
    Expandable YES
    RS-485 NO
    USB 1 (MINI B)
    Ethernet Port 2
    Built-In Network MODBUS/TCP
    ETHERNET/IP
    CC-LINK IE TSN
    CC-LINK IE FIELD BASIC
    BACNET/IP
    Leakage Current (mA) 1,2
    Power Loss LD (W) 89
    Power Loss ND (W) 76
    Standby Power Consumption (W) -
    Protection Class IP20
    Frequency Range (Hz) 0,2–590
