DELIVERY PERIOD : 1-2 WEEKS Type Enclosed Mounting method Direct mounting Phase Single Power output 100 W Efficiency 87 % Output voltage 24 V Rated output current 4.5 A Temperature range -20-60 °C Features Terminal block facing upward Terminal type Screw Communication port(s) None Alarm function - Number of output branches 1 Rated supply voltage at AC 50 Hz 100-240 V Allowable supply voltage AC 85-264 V Allowable supply voltage DC 248-373 V Product Width (unpacked) 97 mm Product Height (unpacked) 38 mm Product Depth (unpacked) 159 mm

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Type Enclosed Mounting method Direct mounting Phase Single Power output 100 W Efficiency 87 % Output voltage 24 V Rated output current 4.5 A Temperature range -20-60 °C Features Terminal block facing forward Terminal type Screw Communication port(s) None Alarm function - Number of output branches 1 Rated supply voltage at AC 50 Hz 100-240 V Allowable supply voltage AC 85-264 V Allowable supply voltage DC 248-373 V Product Width (unpacked) 97 mm Product Height (unpacked) 38 mm Product Depth (unpacked) 159 mm

Read more less

DELIVERY PERIOD : 1-2 WEEKS Type Enclosed Mounting method Direct mounting Phase Single Power output 150 W Efficiency 87 % Output voltage 24 V Rated output current 6.5 A Temperature range -20-60 °C Features Terminal block facing forward Terminal type Screw Communication port(s) None Alarm function - Number of output branches 1 Rated supply voltage at AC 50 Hz 100-240 V Allowable supply voltage AC 90-264 V Allowable supply voltage DC 254-373 V Product Width (unpacked) 97 mm Product Height (unpacked) 38 mm Product Depth (unpacked) 199 mm

Read more less

DELIVERY PERIOD : 1-2 WEEKS Power rating 150 W Output voltage 24 VDC Efficiency 87 % typ. (at 100 VAC input)89 % typ. (at 200 VAC input)90 % typ. (at 230 VAC input) Input Rated input voltage 100 to 240 VAC Allowable input voltage variable range 85 to 264 VAC (Single-phase)80 to 370 VDC Frequency 50/60Hz (47 to 450 Hz) Rated input current 3 A typ. (at 100 VAC input)1.8 A typ. (at 200 VAC input) Leakage current 0.5 mA max. (at 100 VAC input)1 mA max. (at 200 VAC input) Inrush current (cold start at 25 ℃) 14 A typ. (at 100 VAC input)28 A typ. (at 200 VAC input) Output Rated output current 6.5 A Output voltage variable range -10 to +15 % (With V.ADJ) Ripple 110 mV(p-p) max. Static input variation influence 0.5 % max. Static load variation influence 1.0 % max. Ambient temperature variation influence 0.05 %/℃ max. Start up time 1000 ms max. (at 100 VAC input)1000 ms max. (at 200 VAC input) Hold time 10 ms typ. (at 100 VAC input)55 ms typ. (at 200 VAC input) Additional functions Overload protection Yes, automatic reset Overvoltage protection Yes, Shut off the input voltage and turn on the input again Overheat protection No Series operation Yes (Up to 2 Power Supplies with external diode) Parallel operation No (However, backup operation is possible, external diodes required.) Output indicator Yes (color: green) Insulation Dielectric strength Between all input terminals and all output terminals: 3 kVAC for 1 min, Cut-off current: 20 mABetween all input terminals and PE terminals: 2 kVAC for 1 min, Cut-off current: 20 mABetween all output terminals and PE terminals: 1 kVAC for 1 min, Cut-off current: 20 mA Insulation resistance Between all output terminals and all input terminals/PE terminals: 100 MΩ min., at 500 VDC Environment Vibration resistance 10 to 55 Hz, 4.5 G max., 0.375 mm single amplitude in each 3 directions for 2 hours Shock resistance 150 m/s2, in each 6 directions 3 times Altitude 3000 m max. Ambient temperature (Operating) -20 to 70 ℃ (with no freezing or condensation) Ambient temperature (Storage) -25 to 75 ℃ (with no freezing or condensation) Ambient humidity (Operating) 90 %RH max. Ambient humidity (Storage) 90 %RH max. Reliability Life expectancy 10 years min. (at rated input, a load rate of 50% load, under the temperature of 40 ℃ max., standard mounting) Construction Construction Covered type Connection Terminal blocks Terminal type Screw terminal Mounting DIN track mounting Cooling fan Cooling fan No Weight (Main) 500 g max. Note Do not use the Inverter output for the Power Supply. Inverters with an output frequency of 50/60 Hz are available, but the rise in the internal temperature of the Power Supply may result in ignition or burning.

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Type Book type Mounting method DIN rail Phase Single Power output 60 W Efficiency 88 % Output voltage 24 V Rated output current 2.5 A Power boost ratio 120 % Temperature range -40-70 °C Terminal Screw Communication port(s) None Alarm function - Number of output branches 1 Rated supply voltage at AC 50 Hz 100-240 V Allowable supply voltage AC 85-264 V Allowable supply voltage DC 90-350 V Width 32 mm Height 90 mm Depth 110 mm

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Power rating 120 W Output voltage 24 VDC Efficiency 84 % typ. (at 100 VAC input)87 % typ. (at 200 VAC input) Input Rated input voltage 100 to 240 VAC Allowable input voltage variable range 85 to 264 VAC80 to 370 VDC Frequency 50/60Hz (47 to 63 Hz) Rated input current 1.9 A max., 1.5 A typ. (at 100 VAC input)1.1 A max., 0.71 A typ. (at 200 VAC input) Power factor 0.9 min. Leakage current 0.5 mA max. (at 100 VAC input)1.0 mA max. (at 200 VAC input) Inrush current (cold start at 25 ℃) 17.5 A max., 14 A typ. (at 100 VAC input)35 A max., 28 A typ. (at 200 VAC input) Output Rated output current 5 A Output voltage variable range -10 to +15 % With V.ADJ Ripple 60 mV max. Static input variation influence 0.5 % max. (at 100% load) Static load variation influence 1.5 % max. (at rated input, 0 to 100% load) Ambient temperature variation influence 0.05 %/℃ max. Start up time 550 ms typ. (at 100 VAC input)430 ms typ. (at 200 VAC input) Hold time 52 ms typ. (at 100 VAC input)54 ms typ. (at 200 VAC input) Additional functions Overload protection Yes, automatic reset Overvoltage protection Yes, Shut off the input voltage and turn on the input again Series operation Yes (Up to 2 Power Supplies with external diode) Parallel operation No (However, backup operation is possible, external diodes required.) Output indicator Yes (color: green) Insulation Dielectric strength Between all input terminals and PE terminals: 2 kVAC for 1 min, Detection current: 20 mABetween all input terminals and all output terminals/alarm outputs: 3 kVAC for 1 min, Detection current: 20 mABetween all output terminals/alarm outputs and all PE terminals: 1 kVAC for 1 min, Detection current: 30 mABetween all output terminals and all alarm outputs: 500 VAC for 1 min, Detection current: 20 mA Insulation resistance Between all output terminals/alarm outputs and all input terminals/PE terminals: 100 MΩ min., at 500 VDC Environment Vibration resistance 10 to 55 Hz, 0.375 mm single amplitude in each 3 directions for 2 hours Shock resistance 150 m/s2, in each 6 directions 3 times Ambient temperature (Operating) -10 to 60 ℃ Ambient temperature (Storage) -25 to 65 ℃ Ambient humidity (Operating) 25 to 85 % Ambient humidity (Storage) 25 to 90 % Reliability Life expectancy 10 years (at rated input, a load rate of 50% load, under the temperature of 40 ℃, standard mounting) Construction Construction Covered type Connection Terminal blocks Terminal type Screw terminal Mounting DIN track mounting Attachment Terminal block cover Weight (Main) 550 g max. Note Do not use the Inverter output for the Power Supply. Inverters with an output frequency of 50/60 Hz are available, but the rise in the internal temperature of the Power Supply may result in ignition or burning.

Read more less

DELIVERY PERIOD : 1-2 WEEKS OMRON S82K-24024 Power Supply 50/60Hzomron corporations82k-24024power supplyoutputdc24v 10ainput 50/60hzac100-120v 5.5aac200-230v 3.5ashort 100-120vopen 200-230vvoltage selectkm15190made in japanweight: 1.730 kg

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Brand Omron  Output Voltage 12V dc Output Current 4.2A Power Rating 50W Number of Outputs 1 Input Voltage 100 → 240V ac Series S8FS-C

Read more less

Item Code 10001633 Type Resistor Power Rating 5v Voltage Rating 15amp Model No 2SC5422 Brand Toshiba

Read more less

DELIVERY PERIOD : 1-2 WEEKS

Read more less

DELIVERY PERIOD : 1-2 WEEKS

Read more less

DELIVERY PERIOD : 1-2 WEEKS

Read more less
