DELIVERY PERIOD : 1-2 WEEKS Certification body Standard TÜV Rheinland EN ISO 13849-1EN ISO 13849-2IEC 61508EN 62061EN 61131-2IEC 61326-3-1 UL UL508ISA12.12.01 (excluding the DST1-MRD08SL-1)UL1998IEC 61508-3   Specifications   Model DST1-ID12SL-1 DST1-MD16SL-1 DST1-MRD08SL-1 DST1-XD0808SL-1 Communications power supplyvoltage 11 to 25 VDC supplied via communications connector I/O power supply voltage 20.4 to 26.4 VDC (24 VDC -15%/+10%) Currentconsumption Communicationspower supply 24 VDC, 100 mA 24 VDC, 110 mA 24 VDC, 100 mA 24 VDC, 110 mA I/O power supply* 24 VDC, 70 mA 24 VDC,50 mA (Input)130 mA (Output) 24 VDC,80 mA (Input)130 mA (Output) 24 VDC,50 mA (Input)130 mA (Output) Overvoltage category II Noise immunity Conforms to IEC61131-2. Vibration resistance 10 to 57 Hz: 0.35-mm single amplitude, 57 to 150 Hz: 50 m/s2 Shock resistance 150 m/s2, 11 ms 100 m/s2, 11 ms 150 m/s2, 11 ms Mounting method 35-mm DIN Track Ambient operating temperature -10 to 55°C Ambient operating humidity 10% to 95% (with no condensation) 10% to 85% (withno condensation) 10% to 95% (withno condensation) Ambient storage temperature -40 to 70°C Degree of protection IP20 Weight 420 g 600 g 420 g   * Not including power consumption for external devices. Safety Input Specifications(Common with the DST1 Series)   Input type Sinking inputs (PNP) ON voltage 11 VDC min. OFF voltage 5 VDC max. OFF current 1 mA max. Input current 6 mA   Safety Output Specifications (Semiconductor output)(Common with the DST1-MD16SL-1/XD0808SL-1)   Output type Sourcing outputs (PNP) Rated output current 0.5 A max./output ON residual voltage 1.2 V max. Leakage current 0.1 mA max.   Test Output Specifications(Common with the DST1 Series)   Output type Sourcing outputs (PNP) Rated output current 0.7 A max./output ON residual voltage 1.2 V max. Leakage current 0.1 mA max.   Safety Output Specifications (Relay Output)(DST1-MRD08SL-1)   Applicable relays G7SA-2A2B, EN50205 Class A Failure rate P level *(Reference value) 5 VDC, 1 mA Rated load (resistive) 2 A at 240 VAC, 2 A at 30 VDC Durability Mechanical 5,000,000 operations min. (at 7,200 operations/h) Electrical 100,000 operations min. (at 1,800 operations/h with a resistive load)   * This value is equivalent to 300 operations/minute. CIP Safety on DeviceNet Communications   Safety Slave communications Max. 4 connections (Max. 2 connections for the DST1-XD0808SL-1)   DeviceNet Slave Communications(Common with the DST1 Series)   Standard Slave communications Max. 2 connections

Read more less

DELIVERY PERIOD : 1-2 WEEKS Applicable product family G7SA Mounting method DIN rail/screw Terminal type Screw Product Width (unpacked) 22.5 mm Product Height (unpacked) 90 mm Product Depth (unpacked) 60.5 mm Color Black Hold down clip included Release Lever included Applicable wire Solid, Stranded

Read more less

Safety relay, 3PST-NO, SPST-NC, 24 VDC Coil ratings 24 VDC 15 mA Contact form 3PST-NO/SPST-NC Contact material Au plating＋Ag alloy Contact rated load 250 VAC 6 A (Resistive load)30 VDC 6 A (Resistive load) Terminal structure PCB terminal

Read more less

DELIVERY PERIOD : 1-2 WEEKS Miniature Power Relay, 2-pole, Single contact, Plug-in terminals, Built-in diode for coil surge absorption, with operation indicator, 24 VDC Coil ratings 24 VDC 36.3 mA Operating indicator LED Coil surge killer Diode Contact form DPDT Contact method Single Contact material Ag Contact rated load 220 VAC 5 A (Resistive load)220 VAC 2 A (Inductive load (cosφ = 0.4))24 VDC 5 A (Resistive load)24 VDC 2 A (Inductive load (L/R = 7 ms)) Terminal structure Plug-in terminal

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Automotive Relays RoHS:  Details Series: G6D  Brand: Omron Electronics Product Type: Automotive Relays Factory Pack Quantity: 10 Subcategory: Relays Part # Aliases: G6DF4BDC24 Unit Weight: 113.400 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Relay Sockets & Fixings RoHS:  Details Product: Relay Sockets Associated Relay Series: G7SA Number of Poles: 6 Pole Brand: Omron Automation and Safety Mounting Style: DIN Rail Product Type: Relay Sockets & Hardware Factory Pack Quantity: 1 Subcategory: Relays Part # Aliases: 1421760 381008 P7SA14FNDDC24 Unit Weight: 70 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Safety relay, 5PST-NO, SPST-NC, 24 VDC Coil ratings 24 VDC 20.8 mA Contact form 5PST-NO/SPST-NC Contact material Au plating＋Ag alloy Contact rated load 250 VAC 6 A (Resistive load)30 VDC 6 A (Resistive load) Terminal structure PCB terminal

Read more less

DELIVERY PERIOD : 1-2 WEEKS Safety relay, 3PST-NO, 3PST-NC, 24 VDC Coil ratings 24 VDC 20.8 mA Contact form 3PST-NO/3PST-NC Contact material Au plating＋Ag alloy Contact rated load 250 VAC 6 A (Resistive load)30 VDC 6 A (Resistive load) Terminal structure PCB terminal

Read more less

DELIVERY PERIOD : 1-2 WEEKS Type of module Digital I/O Number of digital inputs 12 Digital input type PNP/NPN OFF/ON delay 0-32 ms Permitted voltage at input 20.4-26.4 V Number of digital outputs 8 Digital output type PNP Output current 0.3 A Permitted voltage at output 4.5-30 V Product Height (unpacked) 90 mm Product Width (unpacked) 86 mm Product Depth (unpacked) 50 mm Product Weight (unpacked) 300 g

Read more less

DE DELIVERY PERIOD : 1-2 WEEKS

Read more less

DELIVERY PERIOD : 1-2 WEEKS Photomicrosensor, Slot type, Through-beam, L-shaped, Sensing distance: 5 mm (slot width), Dark-ON, Indicator: No incident light, NPN output, Pre-wired model, 2 m Type Grooved Type (L-shaped) Luminous method Non-modulated Sensing method Through-beam type Sensing distance Slot width: 5 mm Control output (Output type) NPN open collector output Operation mode Dark-ON Connection method Pre-wired models

Read more less

DELIVERY PERIOD ; 1-2 WEEKS  Type Description Select All Category Industrial automation & controls sensors proximity sensors -- industrial  Manufacturer Omron Automation and Safety Series E2E  Packaging Bulk Part Status Active Sensor Type Inductive Sensing Distance 0.079" (2mm) Output Type NPN-NO, 2-Wire Response Frequency 1.5kHz Shielding Shielded Material - Body Stainless Steel Voltage - Supply 10V ~ 30V Termination Style Cable Leads Operating Temperature -25°C ~ 70°C Ingress Protection IP67 Indicator LED Package / Case Cylinder, Threaded - M8 Base Product Number E2E X2  Report Product Information Error View Similar
