DELIVERY PERIOD : 1-2 WEEKS  Model No. LT-150/60 Control Type PID Input Type Thermocouple Transfer Medium Both Water and Oil Pump Power (kW) 0.5 Brand Toshiba Availability In Stock Product Details: Application Industrial Brand Shibaura Capacity (In Tons) 60LPM Models LT150i, LT150, LT200 MOULD TEMPERATURE CONTROL UNIT,90 deg c with water,150 deg c with oil.Heat Transfer Unit Water/Oil.Insulated Sealed Tank.PID Based Temperature Control.Leak Stop Feature. Models LT150i, LT150, LT200 MOULD TEMPERATURE CONTROL UNIT,90 deg c with water,150 deg c with oil.Heat Transfer Unit Water/Oil.Insulated Sealed Tank.PID Based Temperature Control.Leak Stop Feature.

Read more less

DELIVERY TIME : 1-2 WEEKS  Connector Type Screw Contact Material Silver or Copper Contact Type 2NO 2NC Current Rating 8 Amps Mounting Type DIN Rail Mount About this item 8 Amp RELAY MODULE 24V DC OMRON RELAY, With Base With Fuse 2 CHANGEOVER, 8 CHANNEL 12 MONTHS WARRANTY DIN RAIL MOUNTABLE

Read more less

DELIVERY TIME : 1-2 WEEKS  Miniature Power Relay, 4-pole, Single contact, Plug-in terminals, With operation indicator, 24 VDC Coil ratings 24 VDC 36.3 mA Operating indicator LED Contact form 4PDT Contact method Single Contact material Au clad + Ag alloy Contact rated load 220 VAC 3 A (Resistive load)220 VAC 0.8 A (Inductive load (cosφ = 0.4))24 VDC 3 A (Resistive load)24 VDC 1.5 A (Inductive load (L/R = 7 ms)) Terminal structure Plug-in terminal

Read more less

DELIVERY TIME : 1-2 WEEKS  Door switch type Key-operated Guard-lock Material housing Plastic Material head Plastic Ambient temperature (operating) -10-55 °C Connection method Screw terminal Cable length 0 m Direction of operation Adjustable Holding force 1300 N Door contacts NC 2 Door contacts NO 0 Lock monitor contacts NC 2 Lock monitor contacts NO 0 Lock/Release key type Standard key Lock/Release key position Front Lock/Release key material Resin Solenoid voltage 24 V LED indicator Degree of protection (IP) IP67 Conduit size PG13.5 Number of conduits 2 Switch action Slow action Shape Cuboid Overall length of sensor 95 mm Height of sensor 35.5 mm Width of sensor 88.5 mm Switch without actuator Lock/Release logic Power to unlock (Mechanical lock)

Read more less

Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Emergency Stop Switches / E-Stop Switches Type: Pendant Illuminated: Non-Illuminated Brand: Omron Automation and Safety Product: Safety Switches Product Type: Emergency Stop Switches Series: A4EG Factory Pack Quantity: 1 Subcategory: Switches Part # Aliases: A4EGBE2R041 Unit Weight: 502.107 g

Read more less

DELIVERY TIME : 1-2 WEEKS  Screen diagonal 7 in Number of pixels, horizontal 800 Number of pixels, vertical 480 Type of display TFT Frame color Black Number of Ethernet ports 1 Number of USB ports 2 Number of RS-232 ports 2 Number of RS-422 ports 1 Number of RS-485 ports 1 Number of colors of the display 65536 Number of grey-scales/blue-scales of display 64 Degree of protection (IP), front side IP65 Width of the front 202.0 mm Height of the front 148 mm Width of panel cutout 191 mm Height of panel cutout 137 mm Built-in depth 46 mm Product Weight (unpacked) 1000 g

Read more less

DELIVERY TIME : 1-2 WEEKS  ype of module Digital I/O Number of digital inputs 24 Digital input type PNP/NPN OFF/ON delay 0.1-1 ms Permitted voltage at input 20.4-26.4 V Number of digital outputs 16 Digital output type NPN Output current 0.3 A Permitted voltage at output 4.5-30 V Product Height (unpacked) 90 mm Product Width (unpacked) 150 mm Product Depth (unpacked) 50 mm Product Weight (unpacked) 320 g

Read more less

DELIVERY TIME : 1-2 WEEKS  Type Description Select All Category Switches Accessories  Manufacturer Omron Automation and Safety Series D4NS Packaging Bulk Part Status Active Accessory Type Operation Key For Use With/Related Products D4NS Series Report Product Information Error View Similar

Read more less

DELIVERY TIME : 1-2 WEEKS  Type Description Select All Category Switches Accessories Manufacturer Omron Automation and Safety Series D4NS Packaging Bulk Part Status Active Accessory Type Operation Key For Use With/Related Products D4NS Series

Read more less

DELIVERY TIME : 1-2 WEEKS  Solid State Relay, Phototriac, Applied output load: 5 A at 100 to 240 VAC, Without Zero cross function, #110 input terminals, Certified by UL, CSA, and EN (TUV), Rated input voltage: 24 VDC Product classification For single-phase heater Zero cross function None Operating indicator None Rated voltage 24 VDC Rated load voltage 100 to 240 VAC Load current 0.1 to 5 A (With heat sink at 40 ℃)0.1 to 5 A (Without a heat sink at 40 ℃) Terminal structure Tab terminal (Input: #110, Output: #250)

Read more less

DELIVERY TIME : 1-2 WEEKS  [Features]· Lead-use eliminated, safe for environment.·With different colors for AC and DC coil tapes, AC and DC specifications are easily identified.·Type MY(S) with a convenient latching lever for circuit check is now also available.·Wiring labor-hours can be shortened by 60% if combined with push-in plus socket Type PYF-□-PU (according to the manufacturer's measured data).·Terminal Shape: Socket / plug-in terminal, PCB terminal.[Applications]·Widely applicable to almost all types of electrical machines and devices.

Read more less

DELIVERY TIME : 1-2 WEEKS  Operating indicator LED Degree of protection Closed type (cover) Terminal structure Plug-in terminal Coil Coil ratings 24 VDC 36.3 mA Coil resistance 662 Ω Operate voltage (Set voltage) 80 % max. Release voltage (Reset voltage) 10 % min. Maximum voltage 110 % (23 ℃) Power consumption Approx. 0.9 W Contact Contact rated load 220 VAC 3 A (Resistive load)220 VAC 0.8 A (Inductive load (cosφ = 0.4))24 VDC 3 A (Resistive load)24 VDC 1.5 A (Inductive load (L/R = 7 ms)) Max. contact voltage 250 VAC125 VDC Max. contact current AC: 3 ADC: 3 A Maximum switching power 660 VA (Resistive load)176 VA (Inductive load (cosφ = 0.4))72 W (Resistive load)36 W (Inductive load (L/R = 7 ms)) Contact form 4PDT Contact method Single Contact material Au clad + Ag alloy Performance Contact resistance 50 mΩ max. (Voltage drop method with 5 VDC 1 A) Operating time 20 ms max. (With rated operating power applied, not including contact bounce) Reset time 20 ms max. (With rated operating power applied, not including contact bounce) Maximum operating frequency Mechanical: 18000 time/hourRated load: 1800 time/hour Insulation resistance Between coil and contacts: 100 MΩ min. (at 500 VDC)Between contacts of different polarity: 100 MΩ min. (at 500 VDC)Between contacts of same polarity: 100 MΩ min. (at 500 VDC) Dielectric strength Between coil and contacts: 2000 VAC 50/60 Hz 1 minBetween contacts of different polarity: 2000 VAC 50/60 Hz 1 minBetween contacts of same polarity: 1000 VAC 50/60 Hz 1 min Vibration resistance (destruction) 10 to 55 to 10 Hz, 0.5-mm single amplitude (1-mm double amplitude) Vibration resistance (Malfunction) 10 to 55 to 10 Hz, 0.5-mm single amplitude (1-mm double amplitude) Shock resistance (destruction) 1000 m/s2 Shock resistance (Malfunction) 200 m/s2 Endurance (Mechanical) 100 million operations min. (switching frequency 18,000 operations/h) Endurance (Electrical) 200,000 operations min. (23 ℃, Rated load, switching frequency 1,800 operations/h) Failure rate 1 VDC 1 mA (failure level: Preference value, Switching frequency: 120 operations per minute) Ambient temperature (Operating) -55 to 60 ℃ (with no freezing or condensation) Ambient humidity (Operating) 5 to 85 % Weight Approx. 35 g Mounting method Socket Applicable socket PYF14S/ PYF14T/ PYF-14-PU/ PYF-14-PU-L/ PYFZ-14/ PYFZ-14-E/ PY14/ PY14-Y1/ PY14QN/ PY14QN2/ PY14QN-Y1/ PY14QN2-Y1/ PY14-02

Read more less
