Battery Capacity 01000 mpr Voltage 3 v Battery Type Lithium-Ion Brand omron Model Name/Number Cj1w-bat01 The Omron CJ1W-BAT01 is a lithium battery designed for use with Omron's CJ1M and CJ2 series programmable logic controllers (PLCs). Here's a detailed overview: Features:   Voltage: 3.0V Capacity: 850mAh Battery Chemistry: Lithium Design: Compact cylindrical shape with wired connectors Durability: Reliable performance in industrial environments Shelf Life: Long-lasting with minimal self-discharge Safety Standards: Compliant with industry regulations   Applications:   Data Retention: Ensures memory retention in Omron PLCs during power outages Industrial Automation: Supports critical processes in manufacturing and automation systems Backup Power: Provides backup for real-time clock and memory functions in PLCs

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Standard Proximity SensorE2E(DC 2/3-Wire)Your Search for Proximity SensorsStarts with the World-leadingPerformance and Quality of the E2E• Standard Sensors for detecting ferrous metals.• Wide array of variations. Ideal for a variety of applications.• Models with different frequencies are also available to preventmutual interference.• Superior environment resistance with standard cable made ofoil-resistant PVC and sensing surface made of material thatresists cutting oil.• Useful to help prevent disconnection.Cable protector provided as a standard feature.FeaturesLineup includes models with Smartclick pre-wired connectors for fast connection.UL-recognized Models AvailableFor the most recent information on models that have been certified forsafety standards, refer to your OMRON website.(Standards do not apply to all models.)Note: DC 2-Wire Models have been integrated into the E2E NEXT Seriesat the end of october 2022.DC 3-Wire Models have been discontinued at the end of March 2022.Be sure to read Safety Precautions onpage 18.XS5 Smartclick connectors used toenable checking connector matingJacket: Polyester elastomerInsulation: Oil-resistant grade PUR (polyurethane)

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Basic / Snap Action Switches RoHS:  Details Series: Z  Type: General Purpose Contact Form: SPDT Switch Function: ON - (OFF), OFF - (ON) Actuator: Plunger Current Rating: 15 A Voltage Rating AC: 250 VAC Voltage Rating DC: 14 VDC Operating Force: 3.43 N Termination Style: Screw Mounting Style: Chassis Mount IP Rating: IP00 Actuator Style: Plunger Brand: Omron Automation and Safety Illuminated: Non-Illuminated Product Type: Snap Action Switches Factory Pack Quantity: 1 Subcategory: Switches Part # Aliases: 1500284 Z15GDBNC Z15GDB Unit Weight: 45 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Omron NB10W-TW01B HMI Operator Panel – 10.1″ Industrial Touchscreen The Omron NB10W-TW01B HMI Operator Panel is a 10.1-inch TFT touchscreen designed for industrial automation applications. With an 800 x 480 pixel resolution and support for 65,536 colors, it delivers clear and vibrant visuals for an enhanced user experience. The IP65-rated front panel ensures protection against dust and water, making it suitable for rugged industrial environments. Equipped with multiple communication interfaces, including 1 Ethernet port, 2 USB ports, 2 RS-232, 1 RS-422, and 1 RS-485, this HMI panel offers seamless connectivity with PLCs and other automation systems. Its 64-level grayscale/blue-scale display enhances data visualization, while the black frame design gives it a modern and professional look. With a front panel width of 268.8mm and a height of 210.8mm, the NB10W-TW01B fits securely into a panel cutout of 258mm x 200mm. Its 54mm built-in depth ensures easy integration into control cabinets. Designed for efficiency and durability, this Omron HMI panel provides a responsive and intuitive touchscreen interface, making it an ideal solution for industrial automation and process control applications.

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: General Purpose Relays RoHS:  Details Product: Power Relays Type: Standard Coil Voltage: 24 VDC Relay Contact Form: 2 Form C (DPDT-NO, NC) Contact Current Rating: 5 A Contact Termination: Solder Pin Mounting Style: Through Hole Switching Voltage: 380 VAC, 125 VDC Coil Termination: Solder Pin Coil Type: Non-Latching Coil Resistance: 1.6 kOhms Coil Current: 21.8 mA Contact Material: Silver Alloy (Ag) Series: G2R Length: 29 mm Width: 12.7 mm Height: 25.5 mm Brand: Omron Electronics Contact Form: DPDT (2 Form C) Power Consumption: 530 mW Product Type: General Purpose Relays Factory Pack Quantity: 100 Subcategory: Relays Part # Aliases: G2R2DC24 G2R2DC24NC G2R2DC24BYOMI Unit Weight: 17 g

Read more less

Mounting method With plug-in socket Usage General purpose Poles 3 Rated carry current 5 A Coil voltage 24 V Operation voltage DC Contact material Ag Contact description 3PDT Features Transparent case, With mechanical indicator Terminal type Plug-in

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: I/O Modules RoHS:  Details Product: Accessories Brand: Omron Automation and Safety Product Type: I/O Modules Series: G7TC  Factory Pack Quantity: 1 Subcategory: I/O Modules Part # Aliases: G7TC-OC16-1DC24V G7TCOC161DC24V Unit Weight: 17 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Specification Value Size M18 Mounting type Shielded Sensing Distance 8 mm Output type PNP Operation mode NO Power supply 10 to 30 VDC. (including 10% ripple (p-p)) Connection method M12 connector Body Length Short body Body material Brass Differential travel 10% max. of sensing distance Detectable object Ferrous metal (The sensing distance decreases with non-ferrous metal.) Standard target 30 × 30 × 1 mm Response frequency 400 Hz Current consumption 10 mA max Indicator Operation indicator (Yellow LED) Protection circuit Output reverse polarity protection, Power source circuit reverse polarity protection, Surge suppressor, Short-circuit protection Ambient temperature range Operation and storage : -25 to 70ºC (with no icing or condensation) Ambient humidity Operating: 35% to 95%, Storage: 35% to 95% Temperature influence ±10% max. of sensing distance at 23ºC within temperature range of -10 to 55ºC ±15% max. of sensing distance at 23ºC within temperature range of -25 to 70ºC Voltage influence ±1% max. of sensing distance in 24 V ±15% Insulation resistance 50 MΩ min. (at 500 VDC) between current carry parts and case Dielectric strength 1,000 VAC at 50/60 Hz for 1 min between current carry parts and case Vibration resistance 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y and Z directions Shock resistance 1,000 m/s2, 10 times each in X, Y and Z directions Degree of protection IP67 Weight Approx. 60 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Photoelectric sensor standard, reliable assurance of 1 million units per year.· Industry's top class built-in amplifier: with detection range: Mutual interference prevention filter is available for transmission type (red light source type, detection distance 10 m) (sold separately).· Install mutual interference prevention function in various reflective type· Detection distance 30 m (response time 2ms) long distance transmission type is also available.· Guaranteed low-temperature operation that can be used in freezing warehouse: Enlarge the operating ambient temperature range to-40 to +55 °C (main model connector type).· Sensor I/O connector with high durability even in low temperature environment (PUR cable) was also made.· Improvement of coincidence between optical and mechanical axis: Since the deviation between the optical and the mechanical axis is kept within ±2.5° the optical axis aligns by simply fitting it to the mechanical axis (transmission type, regression reflection type).· Protection of sensor even if wiring mistake occurs output reverse protection function is carried (we add diode for reverse connection protection to output line).· In addition, we use burnable polyethylene wrapping paper.

Read more less

Product name: Photoelectric sensor switch Model: E3JK-R4M1 Output type: NO, NC, COM Detection distance: adjustment 7-30 CM Supply voltage: AC 24 ~ 240 V/DC 12 ~ 240 V Load Rating: 3 to 250 VAC Response time: <30 ms Size: 5 x 5 x 1.8 cm / 3.1 “x 3.1” x 0.7 (L * W * H) Cable Length: 1.2 m / 51.2 “ Indicator Light Color: Red Material: Plastic, Metal DELIVERY PERIOD : 1-2 WEEKS

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Safety Limit Switch, G1/2, 1-conduit, 1NC/1NO (snap-action), Plastic rod Actuator Plastic rod Operating mechanism Snap action Contact form 1NC/1NO Degree of protection IP67

Read more less

DELIVERY PERIOD : 1-2 WEEKS  The PYF14A-N is a 4-pole 14-pin Track Mounted Socket, DIN rail/screw mounting, easy labelling, quick connection with 3 coil terminals. Front connecting socket with standard, bifurcated contacts operation indicator, built-in diode, CR circuit, used with MY series general purpose relays. Finger protection Applications Industrial Technical Specifications No. of Pins 14Pins Voltage Rating 250VAC Current Rating 5A
