DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Magnetic/Reed Switches RoHS: N Switch Type: Dry Reed Contact Form: SPST Color: Black Termination Style: Wire Lead Packaging: Bulk Brand: Omron Automation and Safety Illuminated: Non-Illuminated Product Type: Reed Switches Factory Pack Quantity: 1 Subcategory: Switches Part # Aliases: 660962 D40A1C5 Unit Weight: 272.160 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Usage/Application Industrial Automation Brand OMRON Output Voltage 12V Input Voltage 115V Design Smps Switch mode power supply - OMRON (S8FS-C) - Output 12V / (Output) 4.2A / 50W - with Overload protection + Automatic reset - input (input 115Vac) 0.97A / (input 230Vac) 0.59A

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Omron S8FS-C05005J Power Supply,Covered type,100 to 240 VAC, Power rating 50W, Output: 5VDC, 10A Terminal block facing forward (Screw terminal), Harmonic current emissions,Omron Smps,Industrial use for switch mode Power Supply Omron,Din Rail Power Suply Omron, Power rating Item                                       Output voltage 50 W 5 V 12 V 15 V 24 V 48 V Efficiency * 115 VAC input 79% typ. 83% typ. 84% typ. 86% typ. 87% typ. 230 VAC input 80% typ. 84% typ. 85% typ. 86% typ. 87% typ.           Input Voltage range * Single phase 85 to 264 VAC, 120 to 370 VDC (The L terminal for the DC input is the positive side and safety standards do not apply.) (Derating is required according to the input voltage. Refer to Derating Curves on page 18.) Frequency * 50 /60 Hz (47 to 450 Hz) Current * 115 VAC input 0.97 A typ. 230 VAC input 0.59 A typ. Power factor ---   Leakage current 115 VAC input 0.25 mA 0.25 mA 0.25 mA 0.25 mA 0.25 mA 230 VAC input 0.60 mA 0.55 mA 0.55 mA 0.55 mA 0.55 mA Inrush current * (for a cold start at 25°) 115 VAC input 16 A typ. 230 VAC input 32 A typ.             Output Rated Output Current 10 A 4.2 A 3.4 A 2.2 A 1.1 A Voltage adjustment range * -10% to 10% (with V. ADJ) Ripple & Noise voltage * 100 to 240 VAC input 80 mVp-p max. 110 mVp-p max. 100 mVp-p max. 100 mVp-p max. 120 mVp-p max. Input variation influence * 0.5% max. Load variation influence * 1.0% max. Temperature vari- ation influence 100 to 240 VAC input 0.03%/°C max. Startup time * 115 VAC input 730 ms typ. 730 ms typ. 710 ms typ. 710 ms typ. 770 ms typ. 230 VAC input 680 ms typ. 670 ms typ. 610 ms typ. 640 ms typ. 690 ms typ. Hold time * 115 VAC input 12 ms typ. 14 ms typ. 14 ms typ. 14 ms typ. 14 ms typ. 230 VAC input 71 ms typ. 77 ms typ. 78 ms typ. 77 ms typ. 80 ms typ.       Addi- tional func- tions Overload protection Yes, automatic reset Overvoltage protection * Yes, 115% or higher of rated output voltage, power shut off (shut off the input voltage and turn on the input again) Overheat protection No Series operation Yes (For up to 2 Power Supplies, external diodes are required.) Parallel operation No (However, backup operation is possible, external diodes are required.) Remote sensing No Remote control No Output indicator Yes (LED: Green)   Insula- tion   Withstand voltage 3 kVAC for 1 min. (between all input terminals and output terminals) current cutoff 20 mA 2 kVAC for 1 min. (between all input terminals and PE terminals) current cutoff 20 mA 1 kVAC for 1 min. (between all output terminals and PE terminals) current cutoff 20 mA Insulation resistance 100 MÙ min. (between all output terminals and all input terminals/PE terminals) at 500 VDC       Envi- ronment Ambient operating temperature -20 to 60°C (Derating is required according to the temperature. Refer to Derating Curves on page 17.) (with no condensation or icing) Storage temperature -40 to 85°C (with no condensation or icing) Ambient operating humidity 20% to 90% (Storage humidity: 10% to 95%) Vibration resistance 10 to 55 Hz, 0.375-mm half amplitude for 2 h each in X, Y, and Z directions 10 to 500 Hz, 0.26-mm half amplitude for 1 h each in X, Y, and Z directions Shock resistance 150 m/s2, 3 times each in ±X, ±Y, ±Z directions Reliabil- ity MTBF 135,000 hrs min. Life expectancy * 10 years min.   Con- struc- tion Dimensions (W´H´D) Refer to Dimensions on pages 20 and 24. Weight 300 g max. Cooling fan No Degree of protection ---             Stan- dards Harmonic current emissions Conforms to EN 61000-3-2, GB17625.1   EMI Conducted Emissions Conforms to EN 61204-3 Class B, EN 55011 Class B, GB9254 Radiated Emissions Conforms to EN 61204-3 Class B, EN 55011 Class B, GB9254 EMS Conforms to EN 61204-3 high severity levels     Safety Standards Approved Standards UL : cURus UL 60950-1 (Recognition) OVC II Pol2 CSA: cURus C22.2 No60950-1 CCC: GB4943 Conformed Standards EN: EN 60950-1 OVC II Pol2 Marine Standards No SEMI No

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Brand Omron  Output Voltage 12V dc Output Current 4.2A Power Rating 50W Number of Outputs 1 Input Voltage 100 → 240V ac Series S8FS-C

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Type Enclosed Mounting method Direct mounting Phase Single Power output 35 W Efficiency 87 % Output voltage 24 V Rated output current 1.5 A Temperature range -20-60 °C Features Terminal block facing forward Terminal type Screw Communication port(s) None Alarm function - Number of output branches 1 Rated supply voltage at AC 50 Hz 100-240 V Allowable supply voltage AC 85-264 V Allowable supply voltage DC 120-370 V Product Width (unpacked) 97 mm Product Height (unpacked) 36 mm Product Depth (unpacked) 99 mm

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Technical Specifications of Omron Power Supply 15 W 24V S8FS-C01524J: Type: Metal framePower: 15WOutput: 24V, 0.7AInput: 100-240V AC or 120-370V DCEfficiency: 87%Temperature range: -20 to 60℃Compact designUpward-facing terminal.

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Type Book type Mounting method DIN rail Phase Single Power output 60 W Efficiency 88 % Output voltage 24 V Rated output current 2.5 A Power boost ratio 120 % Temperature range -40-70 °C Terminal Screw Communication port(s) None Alarm function - Number of output branches 1 Rated supply voltage at AC 50 Hz 100-240 V Allowable supply voltage AC 85-264 V Allowable supply voltage DC 90-350 V Width 32 mm Height 90 mm Depth 110 mm

Read more less

DELIVERY PERIOD : 1-2 WEEKS  Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Industrial Relays Delivery Restrictions:  Mouser does not sell this product in your region. RoHS:  Details Mounting Style: Through Hole Product: Relays Type: Slim Contact Termination: Plug In Relay Contact Form: 1 Form C (SPDT-NO, NC) Contact Current Rating: 6 A Coil Termination: Plug In Coil Type: Non-Latching Coil Voltage: 24 VDC Coil Current: 13.5 mA Switching Voltage: 400 VAC, 125 VDC Contact Material: Silver (Ag) Series: G2RV Length: 30.5 mm Width: 5.2 mm Height: 33 mm Brand: Omron Automation and Safety Contact Form: SPDT (1 Form C) Power Consumption: 300 mW Product Type: Industrial Relays Factory Pack Quantity: 1 Subcategory: Relays Part # Aliases: 1278668 G2RV1SDC21 Unit Weight: 17 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Relay Sockets & Fixings RoHS:  Details Product: Relay Sockets Associated Relay Series: G2R-1-S (S) Termination Style: Screw Brand: Omron Automation and Safety Mounting Style: PCB Mount Product Type: Relay Sockets & Hardware Series: G2R Factory Pack Quantity: 1 Subcategory: Relays Part # Aliases: P2RFZ05E

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Safety Relays RoHS:  Details Coil Voltage: 24 VDC Relay Contact Form: 2 Form A (DPST-NO) Contact Termination: Solder Pin Contact Rating: 6 A Brand: Omron Automation and Safety Coil Resistance: 1.6 kOhms Contact Form: DPST (2 Form A) Current Rating - Max: 6 A Product: Safety Relays Product Type: Safety Relays Factory Pack Quantity: 1 Subcategory: Relays Part # Aliases: 376123 G7SA2A2B24DC 1221753 G7SA2A2BDC24 Unit Weight: 22 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Manufacturer Part Number G9SA-EX301 Brand Omron Automation Series G9SA SERIES Mounting Type DIN Rail Mount Supply Voltage 100-240 VAC, 24 VAC, 24 VDc Alternate Mfr Part Number G9SAEX301 Function Expansion Unit Current Rating 5 A Contact Form 3PST-NO Overview G9SA-EX301 Expansion Unit: Power Requirements: The G9SA-EX301 connects to G9SA-301, G9SA-501, G9SA-321 or G9SA-TH301. Outputs: The G9SA-EX301 has 3 NO outputs to route power to the coils of power contacts, plus 1 NC auxiliary output for signaling purposes

Read more less

DELIVERY PERIOD : 1-2 WEEKS Technical Specifications Sensing Method Through Beam Supply Voltage Min 12VDC Supply Voltage Max 24VDC Sensor Case / Package Module Collector Current IC Max - IP Rating IP50 Operating Temperature Min -10°C Product Range - Sensing Distance / Slot Width 13mm Supply Voltage DC Min 12V Output Current 80mA Collector Emitter Voltage Max - Sensor Output Type NPN Open Collector Sensor Mounting Through Hole Operating Temperature Max 55°C Qualification

Read more less
