DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Sensor Fixings & Accessories Brand: Omron Automation and Safety Product Type: Sensor Hardware Factory Pack Quantity: 1 Subcategory: Sensors Part # Aliases: EE1017R1M

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Proximity Sensors RoHS:  Details REACH - SVHC: Details Sensing Method: Inductive Sensing Distance: 2 mm Mounting Style: Panel Output Configuration: NPN-NC Brand: Omron Automation and Safety Height: 15 mm Length: 37 mm Maximum Operating Temperature: + 70 C Minimum Operating Temperature: - 25 C Operating Supply Voltage: 30 V Product Type: Proximity Sensors Series: E2E Factory Pack Quantity: 1 Subcategory: Sensors Width: 15 mm Part # Aliases: E2EX2D2NQ E2EX2D2N Unit Weight: 215.460 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Physical Case/PackageModule ColorBlack MountDIN Rail Technical Data PolarityDC Forward Current15 mA Input Current15 mA Isolation Voltage4 kV

Read more less

DELIVERY PERIOD : 1-2 WEEKS Brand Omron  Supply Voltage 100 → 240V ac Mounting Type Panel Mount Mode of Operation Cumulative, Interval, ON/OFF Duty Adjustable Flicker, Power ON Delay, Repeat Cycle, Signal OFF Delay, Signal ON Delay, Stopwatch Time Range 0.001 s → 9999h Number of Contacts 1 Number of Timer Functions Multi Function Time Increment Hours, Seconds Switch Configuration SPDT Terminal Type Screw Power Supply External Width 48mm Length 48mm Series H5CX Maximum Operating Temperature +55°C Depth 78mm Minimum Operating Temperature -10°C Product details Ultra Compact Digital Timer - H5CX Series H5CX Series of ultra-compact digital timers provide advanced functions and security settings to suit your timing needs. Features and Benefits • 12 mm character height• Shorter body depth• Three-colour display value, red, green or orange• Up/Down keys for each digit• Twin timer and variable ON/OFF duty modes• Service life notification - the number of times that the control output turns ON is counted and an alarm is displayed when a preset count is exceeded• Setting upper limit prevents unwanted operation• Isolated power supply and input circuits (Prevent unwanted circuit paths) on 100-240 V ac versions• 0.0001 s to 9999 h, 10 ranges• Input NPN, PNP and contact

Read more less

DELIVERY PERIOD : 1-2 WEEKS Small general purpose power switching relay for industrial use.[Features]·A high-capacity version of Type MY, which is available in a wide variety of types including ones with operation indicator lights, surge absorbing elements, etc.· The contact structure is 1C, 2C, 3C and 4C.· The standard product is compliant with international UL, CSA, and SEV standards and the Product Safety of Electrical Appliances and Materials Act of Japan.· Equipped with an arc barrier for arc interruption. Withstand voltages up to 2,000 V.· New built-in diode and built-in CR circuit models are now available as part of the product series. The lineup also includes the types that are compliant with the international LR and VDE standards.[Applications]·Various control equipment at production sites where high reliability is required.· Used not only for electric, water, gas and other control systems, but also for most types of electrical machinery and equipment.

Read more less

DELIVERY PERIOD : 1-2 WEEKS Power rating 300 W Output voltage 24 VDC Efficiency 82 % typ. (at 100 VAC input)87 % typ. (at 200 VAC input)87 % typ. (at 230 VAC input) Input Rated input voltage 100 to 240 VAC Allowable input voltage variable range 85 to 264 VAC (Single-phase)120 to 370 VDC Frequency 50/60Hz (47 to 63 Hz) Rated input current 4.2 A typ. (at 100 VAC input)2.1 A typ. (at 200 VAC input) Power factor 0.9 min. Leakage current 0.5 mA max. (at 100 VAC input)1 mA max. (at 200 VAC input) Inrush current (cold start at 25 ℃) 14 A typ. (at 100 VAC input)28 A typ. (at 200 VAC input) Output Rated output current 14 A Output voltage variable range -10 to +15 % (With V.ADJ) Ripple 150 mV(p-p) max. Static input variation influence 0.5 % max. Static load variation influence 1.0 % max. Ambient temperature variation influence 0.05 %/℃ max. Start up time 1000 ms max. (at 100 VAC input)1000 ms max. (at 200 VAC input) Hold time 40 ms typ. (at 100 VAC input)40 ms typ. (at 200 VAC input) Additional functions Overload protection Yes, automatic reset Overvoltage protection Yes, Shut off the input voltage and turn on the input again Overheat protection Yes, Shut off the input voltage and turn on the input again Series operation Yes (Up to 2 Power Supplies with external diode) Parallel operation No (However, backup operation is possible, external diodes required.) Output indicator Yes (color: green) Insulation Dielectric strength Between all input terminals and all output terminals: 3 kVAC for 1 min, Cut-off current: 20 mABetween all input terminals and PE terminals: 2 kVAC for 1 min, Cut-off current: 20 mABetween all output terminals and PE terminals: 1 kVAC for 1 min, Cut-off current: 20 mA Insulation resistance Between all output terminals and all input terminals/PE terminals: 100 MΩ min., at 500 VDC Environment Vibration resistance 10 to 55 Hz, 4.5 G max., 0.375 mm single amplitude in each 3 directions for 2 hours Shock resistance 150 m/s2, in each 6 directions 3 times Altitude 3000 m max. Ambient temperature (Operating) -20 to 70 ℃ (with no freezing or condensation) Ambient temperature (Storage) -25 to 75 ℃ (with no freezing or condensation) Ambient humidity (Operating) 90 %RH max. Ambient humidity (Storage) 90 %RH max. Reliability Life expectancy 10 years min. (at rated input, a load rate of 50% load, under the temperature of 40 ℃ max., standard mounting) Construction Construction Covered type Connection Terminal blocks Terminal type Screw terminal Mounting DIN track mounting Cooling fan Cooling fan Yes Weight (Main) 700 g max. Note Do not use the Inverter output for the Power Supply. Inverters with an output frequency of 50/60 Hz are available, but the rise in the internal temperature of the Power Supply may result in ignition or burning.

Read more less

DELIVERY PERIOD : 1-2 WEEKS [Features]· Lead-use eliminated, safe for environment.·With different colors for AC and DC coil tapes, AC and DC specifications are easily identified.·Type MY(S) with a convenient latching lever for circuit check is now also available.·Wiring labor-hours can be shortened by 60% if combined with push-in plus socket Type PYF-□-PU (according to the manufacturer's measured data).·Terminal Shape: Socket / plug-in terminal, PCB terminal.[Applications]·Widely applicable to almost all types of electrical machines and devices. Product Specifications  Part Numbers Catalog Product Features of OMRON Industrial Relays Unit: mm Model of Industrial Relays Height Width Depth MY4 (Z) H 35 22 28.5 MYQ4 (Z) (N) 35.5 21.5 28 MY (excluding MY2N-CR AC24, MY2Z-CR, MY2ZN-CR, MY4N-CR AC24, MY□F, MY4ZF), MYK 36 21.5 28 MY□F, MY4ZF 36 22.5 44 MY2N-CR AC24, MY2Z-CR, MY2ZN-CR, MY4N-CR AC24 53 21.5 28 Model Configuration of OMRON Industrial Relays Category of Industrial Relays Number of Poles Contact Plug-in Terminal of Industrial Relays PCB Terminal Top Mount Type With Operation Indicator Without Operation Indicator With Latching Lever Standard Type(Electrical Appliance and Material Safety Law Compliant) 2 Single MY2N MY2 MY2IN(S) MY2-02 MY2F 2 Twin MY2ZN MY2Z ― ― ― 3 Single MY3N MY3 ― MY3-02 MY3F 4 Single MY4N MY4 MY4IN(S) MY4-02 MY4F 4 Twin MY4ZN MY4Z MY4ZIN(S) ― MY4ZF Built-in Diode for Coil Surge Absorption(Coil specification: DC only) 2 Single MY2N-D2 MY2-D MY2IN-D2(S) ― ― 2 Twin MY2ZN-D2 MY2Z-D ― 3 Single MY3N-D2 MY3-D ― 4 Single MY4N-D2 MY4-D MY4IN-D2(S) 4 Twin MY4ZN-D2 MY4Z-D MY4ZIN-D2(S) Built-in CR Circuit for Coil Surge Absorption(Coil specification: AC only) 2 Single MY2N-CR MY2-CR ― ― ― 4 Single MY4N-CR MY4-CR ― 4 Twin MY4ZN-CR MY4Z-CR ― High Contact Reliability 4 Twin MY4ZN-CBG MY4Z-CBG ― ― ― Plastic-Sealed Type 4 Single MYQ4N MYQ4 ― ― ― 4 Twin MYQ4ZN MYQ4Z ― ― Latching Type(Coil Latching) 2 Single ― MY2K ― MY2K-02 ― Hermetic Type 4 Single ― MY4H ― ― ― 4 Twin MY4ZH ― Dimensional Drawing of OMRON Industrial Relays Dimension diagram for MY2, MY2N, MY2-D, MY2N-D2, MY2-CR, MY2N-CR (Unit: mm) ※ The height for MY2N-CR AC24 is less than 53 mm. Terminal Layout/Internal Connection Diagram (BOTTOM VIEW) of OMRON Industrial Relays Model MY2N of of Industrial Relays DC Specification AC Specification No Coil Polarity No Coil Polarity Model MY2(AC/DC Specification)No Coil Polarity Model MY2-D(DC Specification Only)Coil Polarity Present Model MY2N-D2(DC Specification Only)Coil Polarity Present Model MY2-CR(AC Specification Only)No Coil Polarity Model MY2N-CR(AC Specification Only)No Coil Polarity Note 1: AC specifications include a self-diagnosis function for coil disconnection.Note 2: LED color is red for AC and green for DC.Note 3: The operation indicator shows power to the coil and is not based on contact operation.   ※ For types and model numbers not mentioned above, please refer to the manufacturer catalog. Catalog Product Information of OMRON Industrial Relays      *See the catalog for any types or model numbers other than those detailed above.

Read more less

DELIVERY PERIOD : 1-2 WEEKS Compact Photoelectric Sensor with Built-in Amplifier, Square type, Sensing distance: 100 mm to 4 m (when using the E39-R1S), PNP open collector, Pre-wired model, 2 m Sensing method Retro-reflective with M.S.R. function Sensing distance When using the E39-R1S: 100 mm to 4 mWhen using the E39-R1: 100 mm to 3 m Light source Red LED (660 nm) Connection method Pre-wired models

Read more less

Type Other Monitor screen TFT Monitor screen size 7 Maximum Compatible Resolution Other Display color Color (65,536 colors or more) Protection function (environmentally resistant) Available Representative Standard CUL Dimension height 148 Dimension width 202 Dimension depth 46 Ethernet Available Backlight LED Backlight RoHS 10 - - DELIVERY PERIOD : 1-2 WEEKS

Read more less

DELIVERY PERIOD : 1-2 WEEKS Product Attribute Attribute Value Select Attribute Manufacturer: Omron Product Category: Proximity Sensors RoHS:  Details Sensing Method: Magnetic Sensing Distance: 15 mm Mounting Style: Screw Output Configuration: SPST-NO Brand: Omron Automation and Safety Height: 14 mm Length: 50 mm Maximum Operating Temperature: + 60 C Minimum Operating Temperature: - 20 C Packaging: Bulk Series: GLS Factory Pack Quantity: 1 Subcategory: Sensors Width: 10 mm Part # Aliases: 1567289 GLSM1 Unit Weight: 25 g

Read more less

DELIVERY PERIOD : 1-2 WEEKS Omron E3Z-LS61 2M Photoelectric Sensor The Omron E3Z-LS61 2M photoelectric sensor is a precision distance-setting sensor designed for accurate object detection across a 20 to 200 mm sensing range. Using a red LED (670 nm), it adjusts to varying material types: white paper (100 × 100 mm) is detectable up to 200 mm, while black paper is detectable up to 160 mm. A 10% differential distance ensures high accuracy. The sensor supports selectable Light-ON/Dark-ON modes, powered by 12–24 V DC with 30 mA max current consumption. It outputs via an NPN open collector, with 1 V max residual voltage and built-in short-circuit and reverse polarity protection for safe operation. With a 1 ms response time and 5-turn endless sensitivity adjuster, the E3Z-LS61 offers fine-tuned detection performance. The IP67-rated PBT housing and denatured polyacrylate lens provide durability against dust, water, and tough conditions. A 2-meter pre-wired cable ensures easy system integration, making it a reliable, long-lasting choice for precision tasks in industrial automation.

Read more less

DELIVERY PERIOD : 1-2 WEEKS Specification Table of OMRON Relay Sockets Relay Sockets Model - Number of Relay Sockets   P2CF - 08   P2R - 05P(C) *The symbol with () at the end is the country of origin: Made in China OMRON Relay Sockets (Round) Relay Sockets shape PL (reverse connection) Solder Terminal Wrapping Terminal Printed circuit board terminals Relay Sockets 8-pin Model PL08 Model PL08-Q Model PLE08-0 Approx. 14g Approx. 15g Approx. 10.6g 11 pin Model PL11 Model PL11-Q Model PLE11-0 Approx. 15g Approx. 18.5g Approx. 10.8g 14 pin Relay Sockets Model PL15 - - Approx. 28g 20 pin Relay Sockets Model PL20 - - Approx. 17g shape PF (surface connection) P2CF (surface connection) PFA (surface connection) P3G (reverse connection) Relay Sockets 8-pin Model PF083A Model P2CF-08 Model 8PFA Model P3G-08 Approx. 34g Approx. 55g Approx. 57g Approx. 40 gNote: Finger protection is possible when used in conjunction with the terminal cover (Model Y92A-48G). Model PF083A-E* Model P2CF-08-E Model 8PFA1     Approx. 66g Relay Sockets Model PF085A - Approx. 40g 11 pin Model PF113A Model P2CF-11 Model 11PFA Model P3GA-11 Approx. 47g Approx. 70g Approx. 74g Approx. 47 gNote: Finger protection is possible when used in conjunction with the terminal cover (Model Y92A-48G). Relay Sockets Model PF113A-E* Relay Sockets Model P2CF-11-E -     14 pin - - Relay Sockets Model 14PFA - Approx. 104g 20 pin - - - - OMRON Relay Sockets (Square) shape P2RF (surface connection) P2R (reverse connection) P7TF(surface connection) Solder Terminal Printed circuit board terminals Relay Sockets 5 pin Model P2RF-05 Model P2RF-05-E* Model P2RF-05-S Model P2R-05A Model P2R-05P Model P2R-057P Model P7TF-05 Approx. 27g Approx. 38g Approx. 36g Approx. 5g Approx. 5g Approx. 5.5g Approx. 28g Relay Sockets 8-pin Model P2RF-08 Model P2RF-08-E* Model P2RF-08-S Model P2R-08A Model P2R-08P Model P2R-087P - Approx. 33g Approx. 38g Approx. 40g Approx. 5g Approx. 5g Approx. 5.5g shape PYF (surface connection) Relay Sockets 8-pin Model PYF08A Model PYF08A-E* Model PYF08M Model PYF08S Approx. 32g   Approx. 26g Approx. 46g 11 pin Model PYF11A - Approx. 43g Relay Sockets 14 pin Model PYF14A Model PYF14A-E* Model PYF14T Model PYF14S Approx. 49g   Approx. 53g Approx. 62g [ ! ]Note 1. The Relay Sockets -E type has a finger-protection structure. Round terminals cannot be used. Use Y-shaped terminals, etc.[ ! ]Note 2. To remove the Relay Sockets, pull the socket lever, place your finger on the part of the relay case opposite the lever, and rock it while pulling it out.[ ! ]For compatible Relay Sockets, refer to the "Compatible Relay Series (Omron)" column in the model number list.[ ! ]Use a No. 1 screwdriver to tighten the screws of this product.[ ! ]For types and model numbers other than those listed above, refer to the catalog.
